SPECIFICATION
| Headlight | Halogen type low beam | 12 V - 55 W | |
|---|---|---|---|
| Halogen type high beam | 12V - 60W | ||
| Front turn signal, parking, front side marker light | 12 V - 27/8 W | ||
| Front fog light | OUTBACK | 12V - 51 W | |
| Except for OUTBACK | 12 V - 55 W | ||
| Side turn signal light | 12 V - 2.7 W (LED) | ||
| Rear combination light | Stop/tail light | 12 V - 21/5 W | |
| Turn signal light | 12V - 21 W | ||
| Wagon | Rear side marker light | 12V - 5W | |
| Back-up light | Sedan | 12V - 16W | |
| Wagon | 12V - 16W | ||
| License plate light | 12V - 5W | ||
| High-mounted stop light | Sedan | 12V - 21 W | |
| Wagon | 12 V - 1.3 W (LED) | ||
| Room light | 12V - 8W | ||
| Spot map light | 12V - 8W | ||
| Luggage room light | 12V - 13W | ||
| Trunk room light | 12V - 5W | ||
| Glove box light | 12V - 1.4W | ||
| Door step light | 12 V - 3.5 W | ||
LIGHT SPECIFICATION
The parking light bulb is integrated into the front turn signal light bulb as a unit; therefore, refer to "Front Turn Signal Light Bulb" for the removal procedure. REMOVAL, Front Turn Signal Light Bulb .>
The front side marker light bulb is integrated into the front turn signal light bulb as a unit; therefore, refer to "Front Turn Signal Light Bulb" for the removal procedures. REMOVAL, Front Turn Signal Light Bulb .>
Scheme 4
Scheme 5
Scheme 6
- Disconnect the ground cable from the battery.
- Remove the front fog light cover (A).
- Disengage the two clips, and then turn over the lower mud guard.
- Disconnect the harness connector.
- Remove the mounting bolts, and pull and detach the fog light assembly.
Scheme 7
- Disconnect the ground cable from the battery.
- Disengage the two clips, and then turn over the lower mud guard.
- Disconnect the harness connector.
- Remove the mounting nuts and clips, and detach the fog light assembly by pulling it out.
