HEADLIGHT BEAM ADJUSTMENT
Note. The headlight can only be adjusted in the vertical direction but not the horizontal direction.
| CAUTION | Turn off the light before adjusting the headlight beam level. If it is necessary to inspect the beam level, do not keep the light on for two minutes or more. |
Note. Before checking the headlight beam level, be sure of the following: Check the area around the headlight for any scratches, damage or other types of deformation. Make sure that the vehicle is parked on a level surface. Make sure that the inflation pressure of tires are correct. Check that the vehicle fuel tank is full.
Scheme 8
Scheme 9
- Bounce the vehicle several times to normalize the suspension.
- Make certain that someone is seated in the driver's seat.
- Turn the headlights on and then adjust the low beam pattern. NOTE: Adjust the headlight beam level by turning the adjusting screw (A).
| Mm (in) at 3 m (10 ft) |
|---|
| 21 (0.83) |
HEADLIGHT BEAM REFERENCE CHART
