Ignition (H6DO): Removal & Installation Subaru Outback BP

REMOVAL

Spark plug

1. NGK: PLFR6A-11

Scheme 32

Scheme 33

Scheme 34

1. Disconnect battery ground cable.
2. Remove air cleaner lower case. Refer to «REMOVAL»(ref-208384-S32437817092005120700000) , Air Cleaner.
3. Disconnect connector from ignition coil.
4. Remove ignition coil.
5. Remove spark plugs with the spark plug socket.

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. Disconnect battery cables and then remove battery and battery carrier.
2. Disconnect washer motor connector.
3. Remove the two bolts which hold the wash tank, then take the tank away from the working area.
4. Disconnect connector from ignition coil.
5. Remove ignition coil.
6. Remove spark plug with the spark plugs socket.

Direct ignition type is adopted.

For the order of removal, refer to the REMOVAL of Spark Plugs.

INSTALLATION

Install in the reverse order of removal.

Tightening torque

1. 16 N-m (1.6 kgf-m, 12 ft-lb)
