Ignition (H4SO): Adjustments Subaru Outback BP

ADJUSTMENT

Correct it if the spark plug gap is measured with a gap gauge, and it is necessary.

Scheme 3

1. Spark plug gap: L 1.0 - 1.1 mm (0.039 - 0.043 in)

Note. Replace with new spark plug if this area is worn to "ball" (A) shape.

Scheme 4

Scheme 5

Scheme 6

1. Disconnect ground cable from battery.
2. Disconnect spark plug cords from ignition coil and ignitor assembly.
3. Disconnect connector from ignition coil and ignitor assembly.
4. Remove ignition coil and ignitor assembly.

Scheme 7

1. Install in the reverse order of removal. Tightening torque: 6.4 N-m (0.65 kgf-m, 4.7 ft-lb) CAUTION: Be sure to connect spark plug cords to their proper positions. Failure to do so will damage unit.
