Entertainment: Removal & Installation Subaru Outback BP

Entertainment Systems 4 illustrations ~200 words

INSTALLATION

Install in the reverse order of removal.

Scheme 9

Scheme 9: REMOVAL
Scheme 9: REMOVAL
  1. Disconnect ground cable from battery.
  2. Remove front door trim. Refer to «REMOVAL»(ref-216282-S37673199612006011800000) , Front Door Trim.
  3. Remove front speaker mounting screws.
  4. Disconnect harness connector and remove front speaker.

Install in the reverse order of removal.

Scheme 10

Scheme 10: REMOVAL
Scheme 10: REMOVAL
  1. Disconnect ground cable from battery.
  2. Remove gusset cover.
  3. Disconnect harness connector and remove tweeter.

Install in the reverse order of removal.

Scheme 11

Scheme 11: REMOVAL
Scheme 11: REMOVAL
  1. Disconnect ground cable from battery.
  2. Remove rear door trim. Refer to «REMOVAL»(ref-216282-S37673199612006011800000) , Rear Door Trim.
  3. Remove rear speaker mounting screws.
  4. Disconnect harness connector and remove rear speaker.

Install in the reverse order of removal.

REMOVAL

  1. Disconnect ground cable from battery.
  2. Remove rear door trim. Refer to «REMOVAL»(ref-216282-S10404784952006011800000) , Rear Door Trim.
  3. Remove tweeter mounting screws.
  4. Disconnect harness connector and remove tweeter.

Install in the reverse order of removal.

Install in the reverse order of removal.

Scheme 12

Scheme 12: REMOVAL
Scheme 12: REMOVAL
  1. Disconnect ground cable from battery.
  2. Remove passenger's seat. .
  3. Disconnect harness connector.
  4. Remove mounting nuts, and then detach speaker amplifier.

Install in the reverse order of removal.

Install in the reverse order of removal.

Install in the reverse order of removal.

Install in the reverse order of removal.
