CAUTION

  1. Before disassembling or reassembling parts, always disconnect battery ground cable. When replacing radio, control module, and other parts provided with memory functions, record memory contents before disconnecting the battery ground cable. Otherwise, the memory will be erased.
  2. Reassemble in reverse order of disassembly, unless otherwise indicated.
  3. Adjust parts to the given specifications.
  4. Connect connectors and hoses securely during reassembly.
  5. After reassembly, make sure functional parts operate smoothly.

GENERAL TOOLS

TOOL NAMEREMARKS
Circuit TesterUsed for measuring resistance and voltage.
Heat wire repairing agent (DUPONT NO. 4817 or equivalent)Used for repairing antenna wire.

TOOL NAME

AUDIO SYSTEM

Refer to RADIO , Audio Systems.

SEDAN

  1. Disconnect ground cable from battery.
  2. Remove rear shelf trim. Refer to «REMOVAL»(ref-216282-S05976635102006011800000) , Rear Shelf Trim.
  3. Remove woofer mounting screws.
  4. Disconnect harness connector, and then remove woofer.

Scheme 15

Scheme 15: WAGON

Scheme 16

Scheme 16
  1. Disconnect ground cable from battery.
  2. Remove hook (A) and then remove trim of woofer.
  3. Remove woofer mounting screws.
  4. Disconnect harness connector, and then remove woofer.

PILLAR ANTENNA

  1. Remove the mounting screws and detach the antenna.
  2. Remove the antenna plug.

Scheme 17

Scheme 17: ROOF ANTENNA

Scheme 18

Scheme 18
  1. Remove the roof trim. Refer to «WAGON»(ref-216282-S01100787072006011800000) , REMOVAL, Roof Trim.
  2. Disconnect the harness connector, and remove the nut (A).
  3. Pull the antenna out from roof.

Measure antenna amplifier resistance.

Scheme 19

Scheme 19: SEDAN
Terminal No.Standard
1-a and Amplifier bodyMore than 100 kohm
1-b and Amplifier bodyLess than 1 ohm
2 and Amplifier bodyMore than 100 kohm
3 and Amplifier bodyMore than 100 kohm
4 and Amplifier bodyMore than 100 kohm
5 and Amplifier bodyMore than 100 kohm
1 and 3Less than 1 ohm

RESISTANCE SPECIFICATION CHART

WAGON

Measure antenna amplifier resistance.

Scheme 20

Scheme 20: WAGON
Terminal No.Standard
1 and Amplifier bodyMore than 100 kohm
2 and Amplifier bodyMore than 100 kohm
3 and Amplifier bodyMore than 100 kohm
4 and Amplifier bodyMore than 100 kohm

RESISTANCE SPECIFICATION CHART

Scheme 21

Scheme 21: REMOVAL
  1. Disconnect ground cable from battery.
  2. Remove center panel. Refer to «REMOVAL»(ref-216277-S40645579962006011800000) , Radio.
  3. Disconnect harness connectors and remove front accessory power socket.
