INSPECTION
| Symptom | Repair order |
|---|---|
| Display does not illuminate and no sound from speakers. | Check fuse and power supply for radio. Check radio ground. Remove radio for repair. |
| No sound from specific speaker. | Check speaker. Check output circuit between radio and speaker. |
| Radio generates noise with engine running. | Check radio ground. Check generator. Check ignition coil. Remove radio for repair. |
| Weak signal or noisy sound when receiving AM and FM. | Check antenna. Check antenna amplifier. Check radio ground. Remove radio for repair. |
SCHEMATIC CHART
Measure resistance between antenna terminal and each antenna wire.
If an antenna wire is OK, resistance will be Less than 1 ohm. If an antenna wire is broken, resistance will be More than 1 Mohm.
Note. When checking the continuity, wind a piece of aluminum foil around the tip of tester probe, and then press the aluminum foil against wire with your finger.
Scheme 4
To locate the broken point, move the probe along the antenna wire.
Scheme 5
Scheme 6
- Clean antenna wire and the surrounding area with a cloth dampened by alcohol.
- Paste a thin masking film (B) on glass along the broken wire.
- Deposit heat wire repair agent (C) (DUPONT NO. 4817) on the broken portion (A) with a drawing pen.
- Dry out the heat wire repair agent portion.
- After repair has been completed, measure resistance in the repaired wire.
Scheme 7
- Disconnect ground cable from battery.
- Remove rear pillar upper trim. Refer to «SEDAN»(ref-216282-S26653327772006011800000) , REMOVAL, Rear Quarter Trim.
- Disconnect harness connector and terminal.
- Remove mounting screw and detach antenna amplifier.
Scheme 8
- Disconnect ground cable from battery.
- Remove rear quarter lower trim. Refer to «WAGON»(ref-216282-S28165995782006011800000) , REMOVAL, Rear Quarter Trim.
- Disconnect harness connector and terminal.
- Remove mounting screw and detach antenna amplifier.
