Engine Cooling System (H6DO): Overhaul Subaru Outback BP

ASSEMBLY

Assemble in the reverse order of disassembly.

Tightening torque

1. 4.4 N.m (0.45 kgf-m, 3.3 ft-lb)

Scheme 176

Tightening torque

1. 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Scheme 177

Scheme 178

1. Connect battery as shown in the figure. Terminal No. 1 (+) - No. 4 (-): Low speed No. 2 (+) - No. 4 (-): Middle speed No. 3 (+) - No. 4 (-): High speed
2. Make sure the main fan motor operates properly. Replace it if it doesn't.

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

1. Disconnect battery ground cable.
2. Lift-up the vehicle.
3. Remove under cover.
4. Disconnect connector of sub fan motor.
5. Lower the vehicle.
6. Remove air intake duct.
7. Remove bolts which hold sub fan shroud to radiator.
8. Remove radiator sub fan shroud through the under side of vehicle.

Assemble in the reverse order of disassembly.

Tightening torque

Scheme 184

1. 4.4 N.m (0.45 kgf-m, 3.3 ft-lb)

Tightening torque

Scheme 185

1. 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Scheme 186

1. Connect battery as shown in the figure. Terminal No. 1 (+) - No. 4 (-): Low speed No. 2 (+) - No. 4 (-): Middle speed No. 3 (+) - No. 4 (-): High speed
2. Make sure the sub-fan motor operates properly. Replace it if it doesn't.

Scheme 187

1. Disconnect over flow hose from radiator filler neck position.
2. Remove bolts which install reservoir tank onto radiator main fan shroud.
3. Remove reservoir tank.
