Engine Cooling System (H4SO): Removal & Installation Subaru Outback BP

INSTALLATION

Install in the reverse order of removal.

Note. When the main fan motor assembly cannot be installed as is, loosen the sub fan motor assembly securing bolts to install it.

Scheme 76

1. Tightening torque: 4.9 N.m (0.50 kgf-m, 3.6 ft-lb)

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. Remove clip which holds motor connector onto shroud.
2. Remove nut which holds fan itself onto fan motor and shroud assembly.
3. Remove bolts which install fan motor onto shroud.

Install in the reverse order of removal.

1. Tightening torque: 4.9 N.m (0.50 kgf-m, 3.6 ft-lb)

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. Remove clip which holds motor harness onto shroud.
2. Remove nut which holds fan itself onto fan motor and shroud assembly.
3. Remove bolts which install fan motor onto shroud.

Install in the reverse order of removal.

1. Tightening torque: 4.9 N.m (0.50 kgf-m, 3.6 ft-lb)

Scheme 85
