Onstar ®: Removal & Installation Subaru Outback BP

INSTALLATION

Install in the reverse order of removal.

Tightening torque

2.2 N.m (0.22 kgf-m, 1.6 ft-lb)

Note. When changing VIU, consult the OnStar (R) call center and request setup.

Scheme 10

1. Disconnect the ground cable from battery.
2. Remove meter visor. Refer to «REMOVAL»(ref-216280-S26729346242006011800000) , Combination Meter Assembly.
3. Remove audio body. Refer to «REMOVAL»(ref-216277-S40645579962006011800000) , Radio.
4. Remove VIU from the audio body.

Install in the reverse order of removal.

Tightening torque

4.6 N.m (0.47 kgf-m, 3.4 ft-lb)

Note. When changing VIU, consult the OnStar(R) call center and request setup

Scheme 11

1. Disconnect the ground cable from battery.
2. Remove meter visor. Refer to «REMOVAL»(ref-216280-S26729346242006011800000) , Combination Meter Assembly.
3. Remove audio body. Refer to «REMOVAL»(ref-216277-S40645579962006011800000) , Radio.
4. Remove VIU from the audio body.

Install in the reverse order of removal.

Tightening torque

4.6 N.m (0.47 kgf-m, 3.4 ft-lb)

Scheme 12

1. Disconnect the ground cable from battery.
2. Remove microphone.

Install in the reverse order of removal.

Scheme 13

1. Disconnect the ground cable from battery.
2. Remove roof trim. Refer to «REMOVAL»(ref-216282-S23188312562006011800000) , Roof Trim.
3. Disconnect connector.
4. Remove nut fixing antenna.

Install in the reverse order of removal.

Tightening torque

4.4 N.m (0.45 kgf-m, 3.3 ft-lb)
