Onstar ® (Diagnostics): Overview Subaru Outback BP

Communication Devices 6 illustrations ~144 words

OPERATION

Note. Output mode activates lock and unlock of door, security, horn and headlight.

Scheme 15

Scheme 15: OPERATION
Scheme 15: OPERATION

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. Within 3 seconds after reading DTC, turn the ignition to OFF. When no DTC is stored When DTC of former trouble is stored When DTC of current trouble is stored

Scheme 18

Scheme 18: OPERATION
Scheme 18: OPERATION
  1. Within 3 seconds after reading DTC, turn the OnStar(R) button On and OFF.

Scheme 19

Scheme 19: LED ILLUMINATES GREEN.
Scheme 19: LED ILLUMINATES GREEN.
  1. There is some trouble in electrical system, when OnStar(R) LED does not come on.
  2. Repair OnStar(R) LED circuit or diagnostic circuit, when OnStar(R) LED remains always OFF. Refer to «ONSTAR (R) LED DOES NOT OPERATE»(ref-216292-S37678735312006011800000) , Diagnosis for Each Symptom.

Scheme 20

Scheme 20: LED ILLUMINATES RED.
Scheme 20: LED ILLUMINATES RED.

When OnStar(R) LED illuminates in red, it means some trouble exist in OnStar(R) system. In such a cases read DTC and repair. Refer to OPERATION , Read Diagnostic Trouble Code (DTC).
