SPECIFICATIONS
| Item | Standard or remarks | |||
|---|---|---|---|---|
| ABS sensor | ABS sensor gap | Front | 0.3 - 0.8 mm (0.012 - 0.031 in) | |
| Rear | 0.44 - 0.94 mm (0.0173 - 0.0370 in) | |||
| ABS sensor resistance | 1.25 ± 0.25 kohms | |||
| Marks of the harness | Front LH | Except OUTBACK, PICKUP | Yellow | |
| OUTBACK, PICKUP | Brown | |||
| Front RH | Except OUTBACK, PICKUP | White | ||
| OUTBACK, PICKUP | Light blue | |||
| Rear LH | Yellow | |||
| Rear RH | White | |||
| G sensor | G sensor voltage | 2.3 ± 0.2 V | ||
| ABS control module and hydraulic control unit (ABSCM&H/U) marks | AT (Except OUTBACK, PICKUP) | CG | ||
| MT (Except OUTBACK, PICKUP) | CH | |||
| AT (OUTBACK, PICKUP) | CI | |||
| MT (OUTBACK, PICKUP) | CJ | |||
