ABS: Diagnosis Subaru Outback BP

INSPECTION

Visually check tone wheels teeth (44 pieces) for cracks or dents. If necessary, replace tone wheel with a new one.

Note. Replace BJ assembly with new one as a single unit if there are any defects found on tone wheel is unitized with BJ assembly of drive shaft.

Visually check tone wheels teeth (44 pieces) for cracks or dents. If necessary, replace tone wheel with a new one.

Note. Replace BJ assembly with new one as a single unit if there are any defects found on tone wheel is unitized with BJ assembly of drive shaft.

Scheme 34

Scheme 35

1. Disconnect ground cable from battery.
2. Remove console cover. Refer to «REMOVAL»(ref-216282-S15871558132006011800000) , Console Box.
3. Disconnect connector from G sensor.
4. Remove G sensor from body. CAUTION: Do not drop or bump G sensor.

Scheme 36

1. Install in the reverse order of removal. NOTE: Do not install G sensor in the wrong direction. There is an arrow mark on the sensor showing which side faces the vehicle front.

Scheme 37
