Starter 3.0L: Other Subaru Outback BH

Starter 7 illustrations ~308 words

PRECAUTIONS

  1. Wear working clothing, including a cap, protective goggles, and protective shoes during operation.
  2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
  3. Keep the disassembled parts in order and protect them from dust or dirt.
  4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly, and replacement.
  5. Be careful not to burn your hands, because each part in the vehicle is hot after running.
  6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
  7. Place shop jacks or safety stands at the specified points.
  8. Before disconnecting electrical connectors of sensors or units, be sure to disconnect negative battery terminal.

Scheme 33

Scheme 33: REMOVAL
Scheme 33: REMOVAL

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Disconnect battery ground cable. (Scheme 33): Disconnecting Battery Ground Cable
  2. Remove air intake chamber. See «REMOVAL»(ref-178475-S24827067472005061500000), Air Intake Chamber.
  3. Disconnect connector and terminal from starter. (Scheme 34): Disconnecting Connector & Terminal From Starter
  4. Remove starter from transmission. (Scheme 35): Removing Starter From Transmission

YOKE

Make sure pole is set in position.

Making Sure Pole Is Set In Position. Scheme 36

Scheme 36: Making Sure Pole Is Set In Position
Scheme 36: Making Sure Pole Is Set In Position

OVERRUNNING CLUTCH

Inspect teeth of pinion for wear and damage. Replace if it is damaged. Rotate pinion in direction of rotation (clockwise). It should rotate smoothly. But in opposite direction, it should be locked.

CAUTIONDo not clean overrunning clutch with oil to prevent grease from flowing out.

Inspecting Pinion For Wear & Damage. Scheme 37

Scheme 37: Inspecting Pinion For Wear & Damage
Scheme 37: Inspecting Pinion For Wear & Damage

Scheme 38

Scheme 38: BRUSH AND BRUSH HOLDER
Scheme 38: BRUSH AND BRUSH HOLDER

Scheme 39

Scheme 39
Scheme 39
  1. Brush length Measure the brush length and replace if it exceeds the service limit. Replace if abnormal wear or cracks are noticed. Brush length: Standard: 17.0 mm (0.669 in) Service limit: 11.5 mm (0.453 in) (Scheme 38): Measuring Brush Length
  2. Brush movement Be sure brush moves smoothly inside brush holder.
  3. Insulation resistance of brush holder Be sure there is no continuity between brush holder and its plate. (Scheme 39): Making Sure No Continuity Is Between Brush Holder & Its Plate

MAGNETIC SWITCH

CAUTIONThe following magnetic switch tests should be performed with specified voltage applied. Each test should be conducted within 3 to 5 seconds. Power to be furnished should be one-half the rated voltage.
