STARTER SPECIFICATIONS
| Application | Specification | ||
|---|---|---|---|
| Carbon Brushes | |||
| Minimum Length | .45" (11.5 mm) | ||
| Standard Length | .67" (17.0 mm) | ||
| Commutator | |||
| Runout | |||
| Limit | .0039" (.100 mm) | ||
| Standard | .0020" (.050 mm) | ||
| Mica Depth (Standard) | .020" (.50 mm) | ||
| Load Test | |||
| Torque | |||
| A/T | 7.2 Ft. Lbs. (9.8 N.m) | ||
| M/T | 6.3 Ft. Lbs. (8.5 N.m) | ||
| Maximum Amps | |||
| A/T | 300 Amps | ||
| M/T | 280 Amps | ||
| Minimum RPM | |||
| A/T | 1000 RPM | ||
| M/T | 980 RPM | ||
| Voltage Drop (Minimum) | |||
| A/T | 7.7 Volts | ||
| M/T | 7.5 Volts | ||
| Lock Test | |||
| Minimum Voltage | |||
| A/T | 3.5 Volts | ||
| M/T | 4 Volts | ||
| Maximum Amps | |||
| A/T | 940 Amps | ||
| M/T | 780 Amps | ||
| Minimum Torque | |||
| A/T | 21 Ft. Lbs. (29 N.m) | ||
| M/T | 11.6 Ft. Lbs. (15.7 N.m) | ||
| No-Load Test | |||
| Maximum Amps | 90 Amps | ||
| Minimum RPM | |||
| A/T | 2400 RPM | ||
| M/T | 2800 RPM | ||
| Voltage Drop (Minimum) | 11 Volts | ||
STARTER SPECIFICATIONS (IMPREZA & FORESTER)
| Application | Specification | |||
|---|---|---|---|---|
| 4 Cylinder | ||||
| Carbon Brushes | ||||
| Minimum Length | 0.39" (10 mm) | |||
| Standard Length | 0.59" (15 mm) | |||
| Commutator | ||||
| Runout | ||||
| Limit | .0020" (.050 mm) | |||
| Standard | .0008" (.020 mm) | |||
| Mica Depth | ||||
| Limit | .008" (.20 mm) | |||
| Standard | .024" (.60 mm) | |||
| Load Test | ||||
| Load | ||||
| A/T | 10 Ft. Lbs. (14 N.m) | |||
| M/T | 7 Ft. Lbs. (10 N.m) | |||
| Maximum Amps | ||||
| A/T | 370 Amps | |||
| M/T | 280 Amps | |||
| Minimum RPM | ||||
| A/T | 880 RPM | |||
| M/T | 900 RPM | |||
| Voltage Drop (Minimum) | 8 Volts | |||
| Lock Test | ||||
| Minimum Voltage | 5 Volts | |||
| Maximum Amps | ||||
| A/T | 1050 Amps | |||
| M/T | 800 Amps | |||
| Minimum Torque | 20.3 Ft. Lbs. (27.5 N.m) | |||
| No-Load Test | ||||
| Maximum Amps | 90 Amps | |||
| Minimum RPM | ||||
| A/T | 2900 RPM | |||
| M/T | 3000 RPM | |||
| Voltage Drop (Minimum) | 11 Volts | |||
| 6 Cylinder | ||||
| Carbon Brushes | ||||
| Minimum Length | 0.45" (11.5 mm) | |||
| Maximum Length | 0.67" (17 mm) | |||
| Commutator | ||||
| Runout | ||||
| Limit | .0039" (.100 mm) | |||
| Standard | .0020" (.050 mm) | |||
| Mica Depth | ||||
| Limit | .008" (.20 mm) | |||
| Standard | .024" (.60 mm) | |||
| Load Test | ||||
| Load | 10 Ft. Lbs. (14 N.m) | |||
| Maximum Amps | 370 Amps | |||
| Minimum RPM | 880 RPM | |||
| Voltage Drop (Minimum) | 8 Volts | |||
| Lock Test | ||||
| Minimum Voltage | 5 Volts | |||
| Maximum Amps | 1050 Amps | |||
| Minimum Torque | 20.3 Ft. Lbs. (27.5 N.m) | |||
| No-Load Test | ||||
| Maximum Amps | 90 Amps | |||
| Minimum RPM | 2900 RPM | |||
| Voltage Drop (Minimum) | 11 Volts | |||
