Engine Mechanical (Sti): Adjustments Subaru Impreza GH

ADJUSTMENT

Note. Adjustment of valve clearance should be performed while engine is cold.

Scheme 79

Scheme 80

1. Measure all the valve clearances. Refer to «INSPECTION»(ref-357079-S01120001152010030800000) , Valve Clearance. NOTE: Record each valve clearance after measurement.
2. Remove the camshaft. Refer to «REMOVAL»(ref-357079-S20234831832010030800000) , Camshaft.
3. Remove the valve lifter.
4. Measure the thickness of valve lifter using micrometer.
5. Select a valve lifter of suitable thickness from the following table using the measured valve clearance and valve lifter thickness, and install it. NOTE: Use a new valve lifter. VALVE LIFTER THICKNESS SPECIFICATION Unit: mm (in) Intake valve: S = (V + T) - 0.19 (0.0075) Exhaust valve: S = (V + T) - 0.35 (0.0138) S: Valve lifter thickness required V: Measured valve clearance T: Valve lifter thickness to be used THICKNESS SPECIFICATION Part No. Thickness mm (in) 13228 AB102 4.68 (0.1843) 13228 AB112 4.69 (0.1846) 13228 AB122 4.70 (0.1850) 13228 AB132 4.71 (0.1854) 13228 AB142 4.72 (0.1858) 13228 AB152 4.73 (0.1862) 13228 AB162 4.74 (0.1866) 13228 AB172 4.75 (0.1870) 13228 AB182 4.76 (0.1874) 13228 AB192 4.77 (0.1878) 13228 AB202 4.78 (0.1882) 13228 AB212 4.79 (0.1886) 13228 AB222 4.80 (0.1890) 13228 AB232 4.81 (0.1894) 13228 AB242 4.82 (0.1898) 13228 AB252 4.83 (0.1902) 13228 AB262 4.84 (0.1906) 13228 AB272 4.85 (0.1909) 13228 AB282 4.86 (0.1913) 13228 AB292 4.87 (0.1917) 13228 AB302 4.88 (0.1921) 13228 AB312 4.89 (0.1925) 13228 AB322 4.90 (0.1929) 13228 AB332 4.91 (0.1933) 13228 AB342 4.92 (0.1937) 13228 AB352 4.93 (0.1941) 13228 AB362 4.94 (0.1945) 13228 AB372 4.95 (0.1949) 13228 AB382 4.96 (0.1953) 13228 AB392 4.97 (0.1957) 13228 AB402 4.98 (0.1961) 13228 AB412 4.99 (0.1965) 13228 AB422 5.00 (0.1969) 13228 AB432 5.01 (0.1972) 13228 AB442 5.02 (0.1976) 13228 AB452 5.03 (0.1980) 13228 AB462 5.04 (0.1984) 13228 AB472 5.05 (0.1988) 13228 AB482 5.06 (0.1992) 13228 AB492 5.07 (0.1996) 13228 AB502 5.08 (0.2000) 13228 AB512 5.09 (0.2004) 13228 AB522 5.10 (0.2008) 13228 AB532 5.11 (0.2012) 13228 AB542 5.12 (0.2016) 13228 AB552 5.13 (0.2020) 13228 AB562 5.14 (0.2024) 13228 AB572 5.15 (0.2028) 13228 AB582 5.16 (0.2031) 13228 AB592 5.17 (0.2035) 13228 AB602 5.18 (0.2039) 13228 AB612 5.19 (0.2043) 13228 AB622 5.20 (0.2047) 13228 AB632 5.21 (0.2051) 13228 AB642 5.22 (0.2055) 13228 AB652 5.23 (0.2059) 13228 AB662 5.24 (0.2063) 13228 AB672 5.25 (0.2067) 13228 AB682 5.26 (0.2071) 13228 AB692 5.27 (0.2075) 13228 AB702 4.38 (0.1724) 13228 AB712 4.40 (0.1732) 13228 AB722 4.42 (0.1740) 13228 AB732 4.44 (0.1748) 13228 AB742 4.46 (0.1756) 13228 AB752 4.48 (0.1764) 13228 AB762 4.50 (0.1771) 13228 AB772 4.52 (0.1780) 13228 AB782 4.54 (0.1787) 13228 AB792 4.56 (0.1795) 13228 AB802 4.58 (0.1803) 13228 AB812 4.60 (0.1811) 13228 AB822 4.62 (0.1819) 13228 AB832 4.64 (0.1827) 13228 AB842 4.66 (0.1835) 13228 AB852 5.29 (0.2083) 13228 AB862 5.31 (0.2091) 13228 AB872 5.33 (0.2098) 13228 AB882 5.35 (0.2106) 13228 AB892 5.37 (0.2114) 13228 AB902 5.39 (0.2122) 13228 AB912 5.41 (0.2123) 13228 AB922 5.43 (0.2138) 13228 AB932 5.45 (0.2146) 13228 AB942 5.47 (0.2154) 13228 AB952 5.49 (0.2161) 13228 AB962 5.51 (0.2169) 13228 AB972 5.53 (0.2177) 13228 AB982 5.55 (0.2185) 13228 AB992 5.57 (0.2193) 13228 AC002 5.59 (0.2201) 13228 AC012 5.61 (0.2209) 13228 AC022 5.63 (0.2217) 13228 AC032 5.65 (0.2224)
6. Install the camshaft. Refer to «INSTALLATION»(ref-357079-S14967739122010030800000) , Camshaft.
7. Install the cam sprocket. Refer to «INSTALLATION»(ref-357079-S22743396672010030800000) , Cam Sprocket.
8. Install the timing belt. Refer to «TIMING BELT»(ref-357079-S11075278712010030800000) , INSTALLATION, Timing Belt.
9. Measure all valves for valve clearance again at this time. If the valve clearance is not within the adjustment value, repeat the procedure over again from the first step. Valve clearance (adjustment value): Intake 0.20 +0.01 -0.03 mm (0.0079 +0.0004 -0.0012 in) Exhaust 0.35±0.02 mm (0.0138±0.0008 in)
10. After measurement, install the related parts in the reverse order of removal. NOTE: Use a new rocker cover gasket. Use a new clamp for the PCV hose clamp, fit the cut out in the ST with the protrusion on the clamp as shown in the figure, and lock the clamp. ST 18353AA000 CLAMP PLIERS

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

1. Set the vehicle on a lift.
2. Change the bolt installation position from (A) to (B), then open the front hood completely. Tightening torque: 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
3. Remove the V-belt covers.
4. Collect the refrigerant from A/C system. Refer to «REFRIGERANT RECOVERY PROCEDURE»(ref-357089-S16759157862010030800000) .
5. Release the fuel pressure. Refer to «RELEASING OF FUEL PRESSURE»(ref-357081-S28704346012010030800000) , PROCEDURE, Fuel.
6. Remove the battery. Refer to «REMOVAL»(ref-357077-S20111493982010030800000) , Battery.
7. Open the fuel filler lid and remove the fuel filler cap.
8. Remove the air intake duct and air cleaner case. Refer to «REMOVAL»(ref-357076-S39226648372010030800000) , Air Intake Duct. Refer to «REMOVAL»(ref-357076-S26446360742010030800000) , Air Cleaner Case.
9. Remove the intercooler. Refer to «REMOVAL»(ref-357076-S27886545212010030800000) , Intercooler.
10. Remove the radiator. Refer to «REMOVAL»(ref-357080-S24531260732010030800000) , Radiator.
11. Remove the coolant filler tank. Refer to «REMOVAL»(ref-357080-S03290971542010030800000) , Coolant Filler Tank.
12. Disconnect the A/C pressure hoses from A/C compressor. Refer to «REMOVAL»(ref-357089-S24382232332010030800000) , Hose and Pipe.
13. Disconnect the bulkhead harness connectors from the engine harness connectors.
14. Remove the engine harness connector from the engine harness bracket.
15. Disconnect the following connectors and terminals. Generator connector and terminal A/C compressor connector Secondary air pump connector
16. Disconnect the following hoses. Brake booster vacuum hose (A) and pressure regulator vacuum hose (B) Heater inlet hose and heater outlet hose
17. Remove the power steering pump. Remove the front side belts. Refer to «FRONT SIDE BELT»(ref-357079-S07069179612010030800000) , REMOVAL, V-belt. Disconnect the power steering pump switch connector. Remove the power steering pump from the engine. Place the power steering pump on the right side wheel apron.
18. Remove the center exhaust pipe. Refer to «REMOVAL»(ref-357090-S31053857072010030800000) , Center Exhaust Pipe.
19. Remove the turbocharger. Refer to «REMOVAL»(ref-357076-S13293859742010030800000) , Turbocharger.
20. Remove the joint pipe and front exhaust pipe. Refer to «REMOVAL»(ref-357090-S32880893652010030800000) , Joint Pipe. Refer to «REMOVAL»(ref-357090-S41456640022010030800000) , Front Exhaust Pipe.
21. Disconnect the ground cable on the engine side.
22. Remove the bolts and nuts which hold the lower side of transmission to the engine.
23. Remove the nuts which secure the engine mounting to the front crossmember.
24. Lower the vehicle.
25. Separate the clutch release fork from the release bearing. Remove the clutch operating cylinder from the transmission. Remove the plug using a hexagon wrench (10 mm). Screw-in the 6 mm dia. bolt into the release fork shaft to remove. Raise the release fork, unlock the release bearing tab, then remove the release fork. NOTE: Step (4) is required to avoid interference with the engine when removing the engine from the transmission.
26. Remove the pitching stopper.
27. Disconnect the fuel delivery hose, fuel return hose and evaporation hose. Disconnect the quick connector of the fuel delivery hose and fuel return hose by pushing the ST in the direction of the arrow. ST 42099AE000 QUICK CONNECTOR RELEASE Remove the clip and disconnect the evaporation hose from the fuel pipe. CAUTION: Be careful not to spill fuel. Catch the fuel from hoses using a container or cloth.
28. Support the engine with a lifting device and wire ropes.
29. Support the transmission with a garage jack. CAUTION: Be sure to perform this procedure to prevent the transmission from lowering by its own weight.
30. Separation of engine and transmission CAUTION: Before removing the engine away from transmission, check to be sure no work has been overlooked. Remove the starter. Refer to «REMOVAL»(ref-357077-S32401516152010030800000) , Starter. Remove the bolts which hold the upper side of the transmission to the engine.
31. Remove the engine from vehicle. Slightly raise the engine. Raise the transmission with garage jack. Move the engine horizontally until main shaft is withdrawn from clutch cover. Slowly move the engine away from engine compartment. NOTE: Be careful not to damage adjacent parts or body panels with crank pulley, oil level gauge, etc.
32. Remove the turbocharger and joint pipe from the engine.
33. Remove the engine mounting from the engine.

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. Install the clutch release fork and bearing to the transmission. Using a flat tip screwdriver, remove the release bearing from the clutch cover. Attach the release bearing to the transmission. Install the release fork into the release bearing tab. Apply grease to the specified areas. Grease: Spline part NICHIMOLY N-130 or equivalent Shaft part KOPR-KOTE or equivalent Insert the release shaft to release fork. NOTE: Allow the cutout portion of release shaft to come into contact with the spring pin. Tighten the plugs. Tightening torque: 44 N.m (4.5 kgf-m, 32.5 ft-lb)
2. Install the engine mounting onto the engine. Tightening torque: 35 N.m (3.6 kgf-m, 25.8 ft-lb)
3. Apply a small amount of grease to splines of main shaft. Grease: NICHIMOLY N-130 or equivalent
4. Position the engine in engine compartment and align it with transmission. NOTE: Be careful not to damage adjacent parts or body panels with crank pulley, oil level gauge, etc.
5. Tighten the bolts which hold upper side of transmission to engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)
6. Remove the lifting device and wire ropes.
7. Remove the garage jack.
8. Install the pitching stopper. Tightening torque: T1: 50 N.m (5.1 kgf-m, 36.9 ft-lb) T2: 58 N.m (5.9 kgf-m, 42.8 ft-lb)
9. Install the starter. Refer to «INSTALLATION»(ref-357077-S19270135712010030800000) , Starter.
10. Install the power steering pump onto the engine. Install the power steering pump. Tightening torque: Refer to «COMPONENT»(ref-357095-S16873537652010030800000) , General Description. Connect the power steering pump switch connector. Install and adjust the front side belt. Refer to «FRONT SIDE BELT»(ref-357079-S07069179612010030800000) , INSTALLATION, V-belt.
11. Lift up the vehicle.
12. Install the bolts and nuts which hold lower side of the transmission to engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)
13. Install the nuts which hold the engine mounting to the crossmember. Tightening torque: 85 N.m (8.7 kgf-m, 62.7 ft-lb)
14. Connect the ground cable. Tightening torque: 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
15. Install the joint pipe and front exhaust pipe. Refer to «INSTALLATION»(ref-357090-S25927101752010030800000) , Front Exhaust Pipe. Refer to «INSTALLATION»(ref-357090-S09375217082010030800000) , Joint Pipe.
16. Install the turbocharger. Refer to «INSTALLATION»(ref-357076-S37098492532010030800000) , Turbocharger.
17. Install the center exhaust pipe. Refer to «INSTALLATION»(ref-357090-S07931192752010030800000) , Center Exhaust Pipe.
18. Connect the following hoses. Fuel delivery hose, fuel return hose and evaporation hose Heater inlet hose and heater outlet hose Brake booster vacuum hose and pressure regulator vacuum hose
19. Connect the following connectors and terminals. Generator connector and terminal Tightening torque: 15 N.m (1.5 kgf-m, 11.1 ft-lb) A/C compressor connector Secondary air pump connector
20. Install the engine harness connector to engine harness bracket, then connect the bulkhead harness connector to the engine harness connector.
21. Install the intercooler. Refer to «INSTALLATION»(ref-357076-S13206454512010030800000) , Intercooler.
22. Install the A/C pressure hoses to A/C compressor. Refer to «INSTALLATION»(ref-357089-S00117269392010030800000) , Hose and Pipe.
23. Install the radiator. Refer to «INSTALLATION»(ref-357080-S12847411072010030800000) , Radiator.
24. Install the coolant filler tank. Refer to «INSTALLATION»(ref-357080-S21184242762010030800000) , Coolant Filler Tank.
25. Install the air cleaner case and air intake duct. Refer to «INSTALLATION»(ref-357076-S31089472502010030800000) , Air Cleaner Case. Refer to «INSTALLATION»(ref-357076-S03008514172010030800000) , Air Intake Duct.
26. Install the battery. Refer to «INSTALLATION»(ref-357077-S36403440202010030800000) , Battery.
27. Fill engine coolant. Refer to «FILLING OF ENGINE COOLANT»(ref-357080-S19402554772010030800000) , REPLACEMENT, Engine Coolant.
28. Charge the A/C system with refrigerant. Refer to «PROCEDURE»(ref-357089-S21530875792010030800000) , Refrigerant Charging Procedure.
29. Install the V-belt cover. Tightening torque: 13 N.m (1.3 kgf-m, 9.6 ft-lb)
30. Change the bolt installation position from (B) to (A), then close the front hood. Tightening torque: 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
