Lighting System (Except Sti): Removal & Installation Subaru Impreza GH

INSTALLATION

Install in the reverse order of removal.

1. Install in the reverse order of removal.
2. Before installing steering wheel, be sure to adjust the direction of roll connector with steering. Ref. to «ADJUSTMENT»(ref-357264-S32115370372010031100000) , Roll Connector.

REMOVAL

Scheme 65

1. Disconnect the ground cable from battery.
2. Remove the air intake duct. (When removing the headlight RH).
3. Remove the front bumper face. Ref. to «FRONT BUMPER FACE»(ref-357250-S33518905012010031100000) , REMOVAL, Front Bumper.
4. Disconnect harness connectors.
5. Remove the five bolts and clip to remove the headlight assembly.

Scheme 66

Install in the reverse order of removal.

Tightening torque

7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Install in the reverse order of removal.

1. When removing the turn signal light bulb, fully turn the steering wheels to opposite direction from the turn signal light bulb to remove.
2. Disconnect the ground cable from battery.
3. Turn the mud guard inward.
4. Turn socket (A) from the wheel arch, and remove the front turn signal light bulb.

Scheme 67

Install in the reverse order of removal.

1. When removing the clearance/parking light bulb, fully turn the steering wheels to opposite direction from the turn signal light bulb to remove.
2. Disconnect the ground cable from battery.
3. Turn the mud guard inward.
4. Turn socket (A) from the wheel arch, and remove the clearance/parking light bulb.

Install in the reverse order of removal.

Install in the reverse order of removal.

Tightening torque

7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Scheme 68

Scheme 69

1. Before checking the fog light beam level, be sure of the following: The area around the fog light has not sustained any accident, damage or other type of deformation. Vehicle is parked on a level surface. The inflation pressure of tires is correct. Vehicle's fuel tank is fully filled.
2. Bounce the vehicle several times to normalize the suspension.
3. Make certain that someone is seated in the driver's seat.
4. Disengage the two clips, and then turn over the mud guard.
5. Adjust the front fog light pattern by inserting a Phillips screwdriver to the adjusting hole.

DISTANCE SPECIFICATIONS

1. Disconnect the ground cable from battery.
2. Disengage the two clips, and then turn over the mud guard.
3. Disconnect the harness connector.
4. Rotate the bulb then detach the fog light bulb.

Scheme 70

Install in the reverse order of removal.

Install in the reverse order of removal.

Tightening torque

7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Install in the reverse order of removal.

Install in the reverse order of removal.

1. Disconnect the ground cable from battery.
2. Remove the rear gate trim. Ref. to «REMOVAL»(ref-357250-S23259431832010031100000) , Rear Gate Trim.
3. Disconnect the harness connector.
4. Remove the attachment nuts and remove the rear finisher light assembly.

Scheme 71

Install in the reverse order of removal.

Tightening torque

4.5 N.m (0.46 kgf-m, 3.3 ft-lb)

Install in the reverse order of removal.

Install in the reverse order of removal.

Install in the reverse order of removal.

Install in the reverse order of removal.

Install in the reverse order of removal.

Install in the reverse order of removal.

Install in the reverse order of removal.

1. Disconnect the ground cable from battery.
2. Remove the screws and remove the steering column cover lower.
3. Remove the three mounting screws of steering column cover upper.
4. Remove the instrument panel lower cover. Ref. to «REMOVAL»(ref-357250-S24911419492010031100000) , Instrument Panel Lower Cover.
5. Disconnect the ignition switch illumination connector (A).
6. Turn the ignition switch illumination connector to the left and remove it.

Scheme 72

Install in the reverse order of removal.

1. Remove the reflex reflector by pressing the claw of the reflex reflector from the backside of bumper.

Scheme 73

Install in the reverse order of removal.

Scheme 74

1. Disconnect the ground cable from the battery.
2. Remove the screw, and pull out the door switch.
3. Disconnect the harness connector.

Install in the reverse order of removal.
