Lighting System (Except Sti): Other Subaru Impreza GH

Exterior Lights 47 illustrations ~2092 words

CAUTION

  1. Before removing or installing parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
  2. Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
  3. Adjust parts to the given specifications.
  4. Connect the connectors securely during reassembly.
  5. After reassembly, make sure functional parts operate smoothly.
WARNINGThe airbag system wiring harness is routed near electrical parts and switches. Do not use electrical test devices on any airbag system wiring harnesses or connector circuits. Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches.

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance and voltage.

GENERAL TOOL REFERENCE CHART

HALOGEN TYPE HEADLIGHT

Refer to "Headlight System". Ref. to Headlights in SYSTEM WIRING DIAGRAMS .

HID TYPE HEADLIGHT

Refer to "Headlight System". Ref. to Headlights in SYSTEM WIRING DIAGRAMS .

CLEARANCE LIGHT AND ILLUMINATION LIGHT

Refer to "Clearance Light and Illumination Light System". Ref. to Appropriate Lighting Wiring Diagram in SYSTEM WIRING DIAGRAMS .

LIGHTING SWITCH

Measure the resistance between lighting switch terminals. LIGHTING SWITCH, INSPECTION, Combination Switch (Light).>

DIMMER & PASSING SWITCH

Measure the resistance between dimmer & passing switch terminals. DIMMER&PASSING SWITCH, INSPECTION, Combination Switch (Light).>

HEADLIGHT RELAY

Measure the headlight relay resistance between terminals when connecting terminal No. 4 to the battery positive terminal and terminal No. 3 to the battery ground terminal.

Scheme 76

Scheme 76: HEADLIGHT RELAY
Scheme 76: HEADLIGHT RELAY
ContinuityTerminal No.Standard
Yes1 and 2Less than 1 ohms
No1 Mohms or more

RESISTANCE REFERENCE CHART

TAIL AND ILLUMINATION RELAY

Measure the resistance between the tail and illumination relay terminals when connecting terminal No. 4 to the battery positive terminal and terminal No. 3 to the battery ground terminal.

ContinuityTerminal No.Standard
Yes1 and 2Less than 1 ohms
No1 Mohms or more

RESISTANCE REFERENCE CHART

DAYTIME RUNNING LIGHT MODULE CHECK

StepCheckYesNo
1 CHECK DTC. Connect the Subaru Select Monitor. Read the DTC of the integrated unit.Is DTC displayed?Perform the diagnosis according to DTC.Go to step 2.
2 CHECK INPUT SIGNAL. Display the current data of the integrated unit. Check the following input signals. Parking brake switch Shift position Light 2Is the input signal normal?Go to step 3.Check the defective part.
3 CHECK RELAY. Check the daytime running light relay.Is the relay OK?Go to step 4.Replace the relay.
4 CHECK HARNESS.Is harness normal?Replace the integrated unit.Repair the harness.

DAYTIME RUNNING LIGHT DIAGNOSTIC PROCEDURE

DAYTIME RUNNING LIGHT RELAY

Measure the resistance between the daytime running relay terminals when connecting terminal No. 3 to the battery positive terminal and terminal No. 5 to the battery ground terminal.

Scheme 77

Scheme 77: DAYTIME RUNNING LIGHT RELAY
Scheme 77: DAYTIME RUNNING LIGHT RELAY
ContinuityTerminal No.Standard
Yes7 and 6Less than 1 ohms
No1 Mohms or more
Yes7 and 41 Mohms or more
NoLess than 1 ohms

RESISTANCE REFERENCE CHART

FRONT FOG LIGHT SWITCH

Measure the resistance between front fog light switch terminals. FRONT FOG LIGHT SWITCH, INSPECTION, Combination Switch (Light).>

FRONT FOG LIGHT RELAY

Connect terminal No. 4 to battery positive terminal and terminal No. 3 to battery ground terminal, and measure the front fog light relay resistance between terminals.

ContinuityTerminal No.Standard
Yes1 and 2Less than 1 ohms
No1 Mohms or more

RESISTANCE REFERENCE CHART

TURN SIGNAL SWITCH

Measure the resistance between turn signal switch terminals. TURN SIGNAL SWITCH, INSPECTION, Combination Switch (Light).>

HAZARD SWITCH

Measure the resistance between hazard switch terminals.

Scheme 78

Scheme 78: HAZARD SWITCH
Scheme 78: HAZARD SWITCH
Switch positionTerminal No.Standard
OFF2 and 31 Mohms or more
ONLess than 1 ohms

RESISTANCE REFERENCE CHART

Replace the hazard switch if faulty.

TURN SIGNAL AND HAZARD MODULE

Connect the battery and turn signal light bulb to the module. The module is properly functioning if it blinks when power is supplied to the circuit.

Scheme 79

Scheme 79: TURN SIGNAL AND HAZARD MODULE
Scheme 79: TURN SIGNAL AND HAZARD MODULE

Replace the turn signal & hazard module if faulty.

BACK-UP LIGHT SWITCH (MT MODEL)

Measure the resistance between the back-up light switch terminals.

Scheme 80

Scheme 80: BACK-UP LIGHT SWITCH (MT MODEL)
Scheme 80: BACK-UP LIGHT SWITCH (MT MODEL)
Switch positionTerminal No.Standard
When shift lever is set in reverse positionLand 2Less than 1 ohms
Other positions1 Mohms or more

RESISTANCE REFERENCE CHART

Replace the back-up light switch if faulty.

INHIBITOR SWITCH (AT MODEL)

Measure the resistance between the inhibitor switch terminals.

Scheme 81

Scheme 81: INHIBITOR SWITCH (AT MODEL)
Scheme 81: INHIBITOR SWITCH (AT MODEL)
Switch positionTerminal No.Standard
When the selector lever is in the "R" range7 and 8Less than 1 ohms
Other positions1 Mohms or more

RESISTANCE REFERENCE CHART

Replace the inhibitor switch if faulty.

STOP LIGHT SWITCH

Measure the resistance between stop light switch terminals.

Scheme 82

Scheme 82: STOP LIGHT SWITCH
Scheme 82: STOP LIGHT SWITCH
  1. 5 door model
  2. 4 door model

Scheme 83

Scheme 83
Scheme 83
Switch positionTerminal No.Standard
When brake pedal is depressed5 door model: land 2 4 door model: 3 and 4Less than 1 ohms
When brake pedal is released1 Mohms or more

RESISTANCE REFERENCE CHART

Replace the stop light switch if faulty.

DOOR SWITCH

Measure the resistance between door switch terminals.

Scheme 84

Scheme 84: DOOR SWITCH
Scheme 84: DOOR SWITCH
Switch positionTerminal No.Standard
When door is opened1 and 3Less than 1 ohms
When door is closed1 Mohms or more

RESISTANCE REFERENCE CHART

Replace the door switch if faulty.

REAR GATE LATCH SWITCH

Measure the resistance between rear gate latch switch terminals.

Scheme 85

Scheme 85: REAR GATE LATCH SWITCH
Scheme 85: REAR GATE LATCH SWITCH
Switch positionTerminal No.Standard
When rear gate is opened3 and 4Less than 1 ohms
When rear gate is closed1 Mohms or more

RESISTANCE REFERENCE CHART

Replace the rear gate latch and actuator assembly if faulty.

TRUNK LID SWITCH

Measure the resistance between trunk lid switch terminals.

Scheme 86

Scheme 86: TRUNK LID SWITCH
Scheme 86: TRUNK LID SWITCH
Switch positionTerminal No.Standard
When trunk lid is opened1 and 3Less than 1 ohms
When trunk lid is closed1 Mohms or more

RESISTANCE REFERENCE CHART

Replace the trunk lid latch and actuator assembly if faulty.

Scheme 87

Scheme 87: REMOVAL
Scheme 87: REMOVAL

Scheme 88

Scheme 88
Scheme 88

Scheme 89

Scheme 89
Scheme 89
  1. Disconnect the ground cable from battery.
  2. Remove the screws and remove the steering column cover lower.
  3. Remove the three mounting screws of steering column cover upper.
  4. Disconnect the connector from combination switch.
  5. Remove the three screws, and pull out the combination base switch assembly.
  6. Remove the screws which secure the switch, then remove the combination switch.

Scheme 90

Scheme 90
Scheme 90
Switch positionTerminal No.Standard
OFF1 Mohms or more
Tail14 and 16Less than 1 ohms
Head13, 14 and 16Less than 1 ohms

RESISTANCE REFERENCE CHART

Replace the combination switch (light) if faulty.

Switch positionTerminal No.Standard
Passing7, 8 and 16Less than 1 ohms
High beam7 and 16Less than 1 ohms

RESISTANCE REFERENCE CHART

Replace the combination switch (light) if faulty.

Switch positionTerminal No.Standard
Left1 and 2Less than 1 ohms
Neutral1 Mohms or more
Right3 and 2Less than 1 ohms

RESISTANCE REFERENCE CHART

Replace the combination switch (light) if faulty.

Switch positionTerminal No.Standard
OFF11 and 101 Mohms or more
ONLess than 1 ohms

RESISTANCE REFERENCE CHART

Replace the combination switch (light) if faulty.

Scheme 91

Scheme 91: REMOVAL
Scheme 91: REMOVAL

Scheme 92

Scheme 92
Scheme 92
  1. Remove the driver's airbag module. Ref. to «REMOVAL»(ref-357264-S20493109892010031100000) , Driver's Airbag Module.
  2. Remove the steering wheel. Ref. to «REMOVAL»(ref-357258-S09754233232010031100000) , Steering Wheel.
  3. Remove the combination switch. REMOVAL, Combination Switch (Light).> Ref. to «REMOVAL»(ref-357288-S11109972232010031100000) , Combination Switch (Wiper).
  4. Remove the four screws and remove the roll connector.
  5. Remove the three screws.
  6. Disconnect the harness connector and remove the combination base switch assembly.

HID HEADLIGHT BALLAST

CAUTIONDo not perform work with wet hands. The HID headlight uses very high voltages for the lighting circuit. Make sure that the power is turned OFF before working. Do not leave the headlight without the ballast for a long time. Dust, moisture, etc. entering the headlight may affect its performance.

Scheme 93

Scheme 93
Scheme 93

Scheme 94

Scheme 94
Scheme 94

Scheme 95

Scheme 95
Scheme 95
  1. Disconnect the ground cable from battery.
  2. Remove the headlight assembly. REMOVAL, Headlight Assembly.>
  3. Remove the back cover.
  4. Disconnect the harness connector.
  5. Remove the harness connector and screws to pull out the ballast.
  6. Remove the harness connector and screws on the back to remove the headlight ballast.

Scheme 96

Scheme 96
Scheme 96
CAUTIONWhen installing the ballast cover, be sure to install the gasket. After installing the ballast to the vehicle, be sure to perform beam adjustment.

Install in the reverse order of removal.

Tightening torque

1.3 N.m (0.13 kgf-m, 0.96 ft-lb)

Note. Adjust the projector lens to near the center of the extension opening before installing the ballast. This makes the beam adjustment work easier.

HIGH BEAM & HALOGEN TYPE LOW BEAM

CAUTIONBecause the halogen bulb operates at a high temperature, dirt and oil on the bulb surface reduces the bulb's service life. Hold the flange portion when replacing the bulb. Never touch the glass portion. Do not leave the headlight without a bulb for a long time. Dust, moisture, etc. entering the headlight may affect its performance.

Scheme 97

Scheme 97
Scheme 97
  1. Disconnect the ground cable from battery.
  2. Remove the air intake duct. (When removing the headlight bulb RH).
  3. Remove the battery cover. (When removing the headlight bulb LH)
  4. Tilt the washer tank filler neck. (When removing the headlight bulb LH)
  5. Disconnect the harness connector.
  6. Remove the bulb assembly (A) then remove the high beam. To remove the low beam, remove the back cover (B), and then go to step 7.
  7. Disconnect the harness connector, and remove the bulb.

Scheme 98

Scheme 98
Scheme 98

HID TYPE LOW BEAM

CAUTIONDo not work with wet hands. Because the lighting circuit uses high voltage, be sure to confirm that the power supply is turned off before operation. When replacing the bulb, hold the flange portion, and never touch the glass. Do not leave the headlight without a bulb for a long time. Dust, moisture, etc. entering the headlight may affect its performance.
  1. Disconnect the ground cable from the battery.
  2. Remove the headlight assembly. REMOVAL, Headlight Assembly.>
  3. Remove the back cover.
  4. Disconnect the harness connector.
  5. Remove the light bulb retaining spring, and remove the bulb.

Scheme 99

Scheme 99
Scheme 99

HALOGEN TYPE

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION, General Description.>
  3. If NG, replace the bulb with a new part.

HID TYPE

CAUTIONDo not perform work with wet hands. When lit (lighting switch is ON), do not touch the harness, light internals, or metal parts of the light. When performing a lighting test, make sure that the headlight is mounted on the vehicle, and the power supply is connected to the connector on the vehicle's side.
  1. Check the bulb specification. SPECIFICATION, General Description.>
  2. Install the factory HID bulb to check whether it lights properly.
  3. If it does not light properly, replace with a new bulb.
  4. inspect the HID ballast. Inspect the ballast in the following manner, and determine whether or not to reuse. Perform cold starts (light the headlight after turning off for 10 minutes or more), and hot starts (light the headlight for 15 minutes or more, then turn off for 1 minute and relight) several times, to make sure that the headlight lights properly. Monitor the lighting condition right after a cold start up to a stable state (approx. 5 min.), to see if there are any unstable conditions such as flickering. Install bulbs with the same number of operating hours on both headlights, and light for approximately 30 minutes. Check for whether there is a difference in brightness on the right and left sides.
  5. If there is a malfunction, replace with a new ballast.

4 DOOR MODEL

  1. Disconnect the ground cable from battery.
  2. Remove the trunk room side trim. Ref. to «REMOVAL»(ref-357250-S39514977662010031100000) , Trunk Room Trim.
  3. Remove the harness connector and four nuts, and remove the rear combination light.

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101: 5 DOOR MODEL
Scheme 101: 5 DOOR MODEL
  1. Disconnect the ground cable from the battery.
  2. Remove the two bolts, and then detach the rear combination light by pulling it to the rear side of vehicle.
  3. Disconnect the harness connector and rear combination light.
  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION, General Description.>
  3. If NG, replace the bulb with a new part.

5 DOOR MODEL

  1. Install the rear combination light assembly and check that it blinks normally.
  2. If it does not blink normally, replace the rear combination light assembly with a new part.

Note. Since LED (Light Emitting Diode) is used for the tail light/stop light bulb, replace the rear combination light assembly if the LED burns out.

  1. Disconnect the ground cable from battery.
  2. Remove the trunk room side trim cover. Ref. to «REMOVAL»(ref-357250-S39514977662010031100000) , Trunk Room Trim.
  3. Turn the socket and remove the bulb.

Scheme 102

Scheme 102
Scheme 102

Since LED (Light Emitting Diode) is used for the tail light/stop light bulb, they can not removed.

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION, General Description.>
  3. If NG, replace the bulb with a new part.
  1. Install the rear combination light assembly and check that it blinks normally.
  2. If it does not blink normally, replace the rear combination light assembly with a new part.

Note. Since LED (Light Emitting Diode) is used for the tail light/stop light bulb, replace the rear combination light assembly if the LED burns out.

  1. Disconnect the ground cable from battery.
  2. Remove the trunk room side trim cover. Ref. to «REMOVAL»(ref-357250-S39514977662010031100000) , Trunk Room Trim.
  3. Turn the socket and remove the bulb.

Scheme 103

Scheme 103
Scheme 103
  1. Remove the rear combination light assembly. 5 DOOR MODEL, REMOVAL, Rear Combination Light Assembly.>
  2. Turn the socket and remove the bulb.

Scheme 104

Scheme 104
Scheme 104
  1. Disconnect the ground cable from battery.
  2. Remove the trunk room side trim cover. Ref. to «REMOVAL»(ref-357250-S39514977662010031100000) , Trunk Room Trim.
  3. Turn the socket and remove the bulb.

Scheme 105

Scheme 105
Scheme 105

Note. For models with a rear fog light, the back-up light is installed on the passenger's side.

  1. Disconnect the ground cable from battery.
  2. Remove the bulb inspection cover of the rear gate trim.
  3. Turn the socket and remove the bulb.

Scheme 106

Scheme 106
Scheme 106

4 DOOR MODEL (STANDARD TYPE)

  1. Disconnect the ground cable from the battery.
  2. Disconnect the connector of the high-mounted stop light from the body harness.
  3. Remove the bolt, then remove the high-mounted stop light assembly.

Scheme 107

Scheme 107
Scheme 107

4 DOOR MODEL (WITH BUILT-IN REAR SPOILER)

  1. Disconnect the ground cable from the battery.
  2. Remove the rear spoiler. Ref. to «REMOVAL»(ref-357250-S32706162292010031100000) , Rear Spoiler.
  3. Remove the caps and screws, then detach the high-mounted stop light.

Scheme 108

Scheme 108
Scheme 108

5 DOOR MODEL (WITH BUILT-IN SMALL TYPE ROOF SPOILER)

  1. Disconnect the ground cable from the battery.
  2. Remove the roof spoiler. Ref. to «REMOVAL»(ref-357250-S06565692842010031100000) , Roof Spoiler.
  3. Remove the nuts, then detach the high-mounted stop light.

Scheme 109

Scheme 109
Scheme 109

5 DOOR MODEL (WITH BUILT-IN LARGE TYPE ROOF SPOILER)

  1. Disconnect the ground cable from battery.
  2. Remove the roof spoiler. Ref. to «REMOVAL»(ref-357250-S06565692842010031100000) , Roof Spoiler.
  3. Remove the caps and screws, then detach the high-mounted stop light.

Scheme 110

Scheme 110
Scheme 110
  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION, General Description.>
  3. If NG, replace the bulb with a new part.

EXCEPT FOR 4 DOOR MODEL (STANDARD TYPE)

  1. Install the high-mounted stop light to test if it illuminates normally.
  2. If the high-mounted stop light does not illuminate, replace it with a new part.

Note. Since LED (Light Emitting Diode) is used for the high-mounted stop light, replace the high-mounted stop light assembly if the LED burns out.

Scheme 111

Scheme 111: REMOVAL
Scheme 111: REMOVAL

Scheme 112

Scheme 112
Scheme 112

Scheme 113

Scheme 113
Scheme 113

Scheme 114

Scheme 114
Scheme 114
  1. Disconnect the ground cable from battery.
  2. Remove the lens (A) and spot map light mounting screws (B). Model without sunroof Model with sunroof
  3. Disconnect the harness connectors and remove the spot map light.

SPOT MAP LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION, General Description.>
  3. If NG, replace the bulb with a new part.

SPOT MAP LIGHT SWITCH

Measure the spot map light resistance.

Scheme 115

Scheme 115: SPOT MAP LIGHT SWITCH
Scheme 115: SPOT MAP LIGHT SWITCH
Switch positionTerminal No.Standard
OFF1 and 21 Mohms or more
ON1 and 218±5.4ohms

RESISTANCE REFERENCE CHART

Replace the spot map light if faulty.

Scheme 116

Scheme 116: REMOVAL
Scheme 116: REMOVAL

Scheme 117

Scheme 117
Scheme 117
  1. Disconnect the ground cable from the battery.
  2. Remove the lens (A) and mounting screws (B).
  3. Disconnect the harness connector and remove the room light.

ROOM LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION, General Description.>
  3. If NG, replace the bulb with a new part.

ROOM LIGHT SWITCH

Measure the resistance between room light switch terminals.

Scheme 118

Scheme 118: ROOM LIGHT SWITCH
Scheme 118: ROOM LIGHT SWITCH
Switch positionTerminal No.Standard
OFF1 Mohms or more
ON1 and 31.5±0.5ohms
DOOR2 and 31.5±0.5ohms

RESISTANCE REFERENCE CHART

Replace the room light if faulty.

Scheme 119

Scheme 119: REMOVAL
Scheme 119: REMOVAL
  1. Disconnect the ground cable from battery.
  2. Insert a flat tip screwdriver into the edge of the luggage room light body to remove the luggage room light.
  3. Disconnect the harness connector and remove the lens.

LUGGAGE ROOM LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION, General Description.>
  3. If NG, replace the bulb with a new part.

LUGGAGE ROOM LIGHT SWITCH

Measure the resistance between luggage room light switch terminals.

Scheme 120

Scheme 120: LUGGAGE ROOM LIGHT SWITCH
Scheme 120: LUGGAGE ROOM LIGHT SWITCH
Switch positionTerminal No.Standard
OFF1 and 21 Mohms or more
ONLess than 1 ohms

RESISTANCE REFERENCE CHART

Replace the luggage room light if faulty.

Scheme 121

Scheme 121: REMOVAL
Scheme 121: REMOVAL
  1. Disconnect the ground cable from the battery.
  2. Turn the trunk room light counterclockwise 60° to remove it and disconnect the harness connector.
  3. Remove bulb (A).

Scheme 122

Scheme 122
Scheme 122

TRUNK ROOM LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION, General Description.>
  3. If NG, replace the bulb with a new part.

More articles — Lighting System (Except Sti)
