Lighting System (Except Sti): Adjustments Subaru Impreza GH

Exterior Lights 2 illustrations ~135 words

HEADLIGHT BEAM ADJUSTMENT

CAUTIONTurn off the light before adjusting the headlight beam level. If it is necessary to inspect the beam level, do not keep the light on for two minutes or more.

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59
  1. Before checking the headlight beam level, be sure of the following: The area around the headlight has not sustained any accident, damage or other type of deformation. Vehicle is parked on a level surface. The inflation pressure of tires is correct. Vehicle's fuel tank is fully filled.
  2. For vehicle with a manual leveler, set the headlight beam leveler switch to the "0" position.
  3. Bounce the vehicle several times to normalize the suspension.
  4. Make certain that someone is seated in the driver's seat.
  5. Measure the distance between the low beam bulb centers and the height of the bulb center.
  6. Turn the headlights on and then adjust the low beam pattern. Adjust the vertical beam level (A). Adjust the horizontal beam level (B).
W mm (in)H mm (in) at 3 m (10 ft)
1,160 (45.67)30 (1.18)

DISTANCE SPECIFICATIONS
