Wiper System & Washer System: Removal & Installation Subaru Forester SH рестайлинг

INSTALLATION

Install each part in the reverse order of removal.

Scheme 37

1. Operate the switches to check the continuity between terminals. TERMINAL REFERENCE CHART Switch position Terminal No. Standard Front OFF 7 and 16 Less than 1 ohms INT 7 and 16 Less than 1 ohms LO 7 and 17 Less than 1 ohms HI 8 and 17 Less than 1 ohms Washer ON 2 and 11 Less than 1 ohms Rear OFF 2 and 10 10 and 12 2 and 12 1 Mohms or more INT 2 and 13 Less than 1 ohms ON 2 and 10 Less than 1 ohms Washer ON 2 and 12 Less than 1 ohms
2. Replace the switch if the inspection result is not within the standard value.

Scheme 38

1. Check with Subaru Select Monitor When the front wiper switch is operated, check the input signal using the Subaru Select Monitor. Prepare the Subaru Select Monitor kit. Turn the ignition switch to ON. On << System Selection Menu >> display, select {Integ. unit mode}. Select the {Current Data Display & Save}. Check the input signal when the front wiper switch is set to LO or HI. Is the input signal normal? Yes --> Finish the diagnosis. No --> Check the harness. Check ACC input voltage of body integrated unit. Connector & terminal (B281) No. 5 (+) - Chassis ground (-): Replace the body integrated unit. < Ref. to «BODY INTEGRATED UNIT»(ref-465386-S28062750222012042000000) . >
2. Check the intermittent operation (inspection of the wiper switch alone) Set the voltage meter between terminal No. 7 (+) and No. 2 (-). Connect the battery to connector. (Terminal No. 17 (+), terminal No. 2 & 16 (-)) Turn the front wiper switch to INT. Connect the battery (+) to the terminal No. 16 for 5 seconds. Connect the battery (-) to the terminal No. 16, and check the voltage between terminal No. 7 - No. 2 when performing the intermittent operation. Perform step ( 1 ) to ( 5 ) above when intermittent control switch is in MIN or MAX, and replace the switch if the operation is not as specified. Intermittent stationary time MIN: Approx. 4 seconds MAX: Approx. 19 seconds

1. Install each part in the reverse order of removal.
2. Confirm that the clip is locked securely.

Install each part in the reverse order of removal.

Tightening torque

6.0 N.m (0.61 kgf-m, 4.4 ft-lb)

1. Install each part in the reverse order of removal.
2. Adjust the washer nozzle position. < Ref. to «ADJUSTMENT»(ref-465442-S37643891232012042000000) , Front Washer Nozzle . >

Install each part in the reverse order of removal.
