Wiper System & Washer System: Adjustments Subaru Forester SH рестайлинг

ADJUSTMENT

Operate the wiper once. Align the wiper blade to ceramic print point mark (A) of front window panel.

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. Disconnect the ground cable from the battery.
2. Remove the cowl panel. < Ref. to «REMOVAL»(ref-465406-S11113567742012042000000) , Cowl Panel . >
3. Disconnect the connector of motor.
4. Remove the bolt, and remove the wiper link.
5. Remove the TORX® bolt and nuts, and remove the wiper motor assembly.

Scheme 8

Scheme 9

Scheme 10

1. Connect the battery ground terminal.
2. To confirm that the motor is at the auto stop position, connect the harness to the motor and turn the wiper switch to ON/OFF once.
3. Disconnect the ground cable from battery.
4. Install the wiper motor assembly. Tightening torque: Refer to "COMPONENT" of "General Description". < Ref. to «FRONT WIPER»(ref-465442-S12348526532012042000000) , COMPONENT, General Description . >
5. Tighten the nut of the link plate and motor assembly. CAUTION: Tighten the nut where rod (A) and link plate (B) is aligned in a straight line. Tightening torque: Tighten to 8.5 N.m (0.87 kgf-m, 6.3 ft-lb) by 115°.
6. Install each part in the reverse order of removal. Tightening torque: Refer to "COMPONENT" of "General Description". < Ref. to «FRONT WIPER»(ref-465442-S12348526532012042000000) , COMPONENT, General Description . >

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Check that the wiper motor operates at low speed when the battery is connected to the connectors terminal as shown in the illustration.
2. Check that the wiper motor operates at high speed when the battery is connected to the connectors terminal as shown in the illustration.
3. Connect the battery to the terminals to the connector, run the motor at low speed, and then disconnect the terminal to stop the wiper motor in mid motion.
4. Connect the battery and confirm that the motor stops at the automatic stop position after the motor operates at low speed.

Scheme 15

1. Remove the cowl panel. < Ref. to «REMOVAL»(ref-465406-S11113567742012042000000) , Cowl Panel . >
2. Remove the washer hose from the washer nozzle.
3. Using a driver with a narrow tip, etc, remove the washer nozzle from the cowl panel.
