CAUTION

1. Connect the connectors and hoses securely during reassembly.
2. After reassembly, make sure that the each function operates normally.
3. Be careful with the airbag system wiring harness which passes near electrical parts and switches.
4. Yellow connectors and harnesses with yellow tapes around them are the connectors and harnesses for the airbag system. Using a tester above such circuits may cause malfunction of airbag system. Follow the cautions for the airbag system in this case. < Ref. to «CAUTION»(ref-465432-S09321667812012042000000) , General Description . >
5. Care must be taken when connecting the hose to the pipe so that no bending, jamming, etc. are caused.
6. If even a small amount of silicon oil or grease enters tank and washer fluid passages, an oil film will be formed on the glass and will cause the wiper to chatter and judder. Make sure that no oil comes into contact with the system.

GENERAL TOOL

GENERAL TOOL DESCRIPTION CHART

WIPER AND WASHER (FRONT)

Refer to "Front Wiper and Washer System" in the wiring diagram. < Ref. to WIPER/WASHER . >

WIPER AND WASHER (REAR)

Refer to "Rear Wiper and Washer System" in the wiring diagram. < Ref. to WIPER/WASHER . >

NOTE

For procedure of each component of the wiper and washer system, refer to the respective sections.

1. Combination switch (Wiper): < Ref. to «COMBINATION SWITCH (WIPER)»(ref-465442-S03495554882012042000000) . >
2. Wiper blade: < Ref. to «WIPER BLADE»(ref-465442-S23835223872012042000000) . >
3. Front wiper arm: < Ref. to «FRONT WIPER ARM»(ref-465442-S11426599002012042000000) . >
4. Front wiper motor and link: < Ref. to «FRONT WIPER MOTOR AND LINK»(ref-465442-S12762301242012042000000) . >
5. Rear wiper arm: < Ref. to «REAR WIPER ARM»(ref-465442-S07476907662012042000000) . >
6. Rear wiper motor: < Ref. to «REAR WIPER MOTOR»(ref-465442-S34171488642012042000000) . >
7. Washer tank and motor: < Ref. to «WASHER TANK AND MOTOR»(ref-465442-S20976677552012042000000) . >
8. Front washer nozzle: < Ref. to «FRONT WASHER NOZZLE»(ref-465442-S16734366692012042000000) . >
9. Rear washer nozzle: < Ref. to «REAR WASHER»(ref-465442-S15490481492012042000000) . >

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. Disconnect the ground cable from battery.
2. Remove the screws and remove the steering column cover lower.
3. Remove the harness cover lock.
4. Remove the screws and detach the knee protector.
5. Remove the mounting screws of steering column cover upper.
6. Disconnect the connector from wiper switch.
7. Remove the screws and then remove the wiper switch.

REAR WIPER

1. Check with Subaru Select Monitor DIAGNOSIS PROCEDURE Step Check Yes No 1 CHECK INPUT OF REAR WIPER SWITCH. Check the input from body integrated unit using the Subaru Select Monitor. Prepare the Subaru Select Monitor kit. Turn the ignition switch to ON. On << System Selection Menu >> display, select {Integ. unit mode}. Select the {Current Data Display & Save}. Check the input of the rear wiper switch. Is the input normal? Go to step 4. Go to step 2. 2 CHECK HARNESS. Disconnect the ground cable from battery. Disconnect the connector of body integrated unit. Disconnect the connector from wiper switch. Measure the resistance between body integrated unit and wiper switch. Connector & terminal (B281) No. 18 - (B70) No. 10: (B281) No. 27 - (B70) No. 13: (B281) No. 28 - (B70) No. 12: Is the resistance less than 10 ohms? Go to step 3. Repair the harness between the body integrated unit and wiper switch. 3 CHECK INPUT VOLTAGE OF BODY INTEGRATED UNIT. Connect the ground cable to battery. Turn the ignition switch to ACC. Check the input voltage of body integrated unit. Connector & terminal (B280) No. 7 (+) - Chassis ground (-): Is the voltage 10 V or more? Go to step 4. Check the harness and fuse. 4 CHECK OUTPUT OF BODY INTEGRATED UNIT. When the rear wiper switch is operated, check the output using the Subaru Select Monitor. Turn the ignition switch to ON. Operate the rear wiper switch and set to each position of ON and INT. At this time, check the body integrated unit output. When set to ON, is ON output continuous? When set to I NT, is ON/OFF output repeated? (INT OFF time (when vehicle parked): 12 seconds) Check the rear wiper motor circuit. Replace the body integrated unit. < Ref. to «BODY INTEGRATED UNIT»(ref-465386-S28062750222012042000000) . >
2. Check rear wiper motor circuit DIAGNOSIS PROCEDURE Step Check Yes No 1 CHECK POWER SUPPLY CIRCUIT OF THE REAR WIPER MOTOR. Disconnect the harness connector of the rear wiper motor. Turn the ignition switch to ACC. Measure the voltage between the rear wiper motor harness connector terminal and chassis ground. Connector & terminal (D43) No. 3 (+) - Chassis ground (-): Is the voltage 10 V or more? Go to step 2. Check the fuse (No. 23 in fuse & relay box). Check the fusible link (No. 7 in main fuse box). 2 CHECK GROUND CIRCUIT OF REAR WIPER MOTOR. Turn the ignition switch to OFF. Measure the resistance between the rear wiper motor harness connector terminal and chassis ground. Connector & terminal (D43) No. 4 - Chassis ground: Is the resistance less than 10 ohms? Go to step 3. Repair the open circuit of the rear wiper motor ground circuit. 3 CHECK HARNESS BETWEEN BODY INTEGRATED UNIT AND REAR WIPER MOTOR. Turn the ignition switch to OFF. Disconnect the harness connector of body integrated unit. Disconnect the harness connector of the rear wiper motor. Measure the resistance between the harness connector terminals of the body integrated unit and rear wiper motor. Connector & terminal (B279) No. 8 - (D43) No. 1: (B279) No. 9 - (D43) No. 2: Is the resistance less than 10 ohms? Go to step 4. Repair the open circuit of the harness between body integrated unit and rear wiper motor. 4 CHECK INPUT VOLTAGE OF BODY INTEGRATED UNIT. Turn the ignition switch to ACC. Check the input voltage of body integrated unit. Connector & terminal (B279) No. 21 (+) - Chassis ground (-): Is the voltage 10 V or more? Go to step 5. Check the harness and fuse. 5 CHECK OUTPUT OF BODY INTEGRATED UNIT. Connect the harness connector of body integrated unit. Disconnect the connector of the rear wiper motor. Turn the ignition switch to ACC. Measure the voltage between rear wiper motor connector and chassis ground. Connector & terminal (D43) No. 2 (+) - Chassis ground (-): Is the voltage less than 1.5 V when the rear wiper switch is OFF, and is the voltage 10 V or more when the rear wiper switch is ON? Go to step 6. Replace the body integrated unit. < Ref. to «BODY INTEGRATED UNIT»(ref-465386-S28062750222012042000000) . > 6 CHECK OPERATION OF REAR WIPER MOTOR. Remove the rear wiper motor. Check the rear wiper motor. < Ref. to «INSPECTION»(ref-465442-S32875840522012042000000) , Rear Wiper Motor . > Does the rear wiper motor rotate normally? End. Replace the rear wiper motor.

Scheme 45

1. Pull up locking clip (A), and push the arm into the blade assembly side. (Arrow 2)
2. While lifting the arm, pull out (Arrow 3), and remove the blade assembly from the arm.

REAR

Turn the blade in the direction of arrow (A) and remove it from arm.

Scheme 46

FRONT

Pull side (A) of the wiper rubber stopper and remove the rubber from the blade assembly.

Scheme 47

Pull the wiper rubber top slightly from stopper (A) and pull out completely.

Scheme 48

Scheme 49

Scheme 50

1. Insert the wiper rubber onto the blade so that the stopper is in the position shown in the illustration.
2. Make sure the wiper rubber is securely fastened to the pull stopper (A).

Scheme 51

Scheme 52

Scheme 53

Scheme 54

1. Insert the wiper rubber through claw (B).
2. Insert the wiper rubber until its top end protrudes approx. 20 mm (0.79 in) from stopper (D).
3. Insert the wiper rubber into claw (A).
