DISASSEMBLY
To detect the real cause of trouble, inspect the following items before disassembling.
- Tooth contact and backlash between hypoid driven gear and drive pinion
- Hypoid driven gear runout on its back surface
- Total preload of drive pinion
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Scheme 39
- Set the ST on vise and install the differential assembly to ST. ST 398217700 ATTACHMENT SET
- Remove the drain plug and filler plug, and drain the gear oil.
- Remove the air breather cap. NOTE: Do not attempt to replace the air breather cap unless necessary. Whenever the air breather cap is removed, replace it with a new part.
- Remove the bolts, and then remove the rear cover.
- Remove the side retainer attachment bolts, set the ST to differential case, and extract the side retainers RH and LH with a puller. NOTE: Side retainer shim of each side should be kept together with its mating retainer. Keep the side retainers separate by attaching tags or in similar ways to make it possible to identify RH and LH sides. ST 398457700 ATTACHMENT
- Pull out the differential case assembly from the differential carrier. NOTE: Be careful not to hit the teeth of hypoid driven gear against the differential carrier.
- When replacing the side bearing, remove the bearing cup from the side retainer using ST. ST 398527700 PULLER ASSY
- Using the ST, remove the bearing cone. NOTE: Do not attempt to disassemble the parts unless necessary. Set the puller so that its claws catch the edge of the bearing cone. Never mix up the RH and LH bearing races and cones. ST 18759AA000 PULLER ASSY
- Remove the hypoid driven gear by loosening hypoid driven gear bolts.
- Remove the pinion shaft lock pin from driven gear side using ST. ST 899904100 STRAIGHT PIN REMOVER
- Draw out the pinion mate shaft and remove pinion mate gears, side gears and thrust washers. NOTE: The gears should be marked or kept separated right and left, and front and rear as well as thrust washers.
- Remove the self-locking nut while holding the companion flange with ST. ST 498427200 FLANGE WRENCH
- Extract the companion flange with a puller.
- Press the end of drive pinion shaft by using the ST, and remove the drive pinion shaft, rear bearing cone, preload adjusting spacer and washer. NOTE: Hold the drive pinion so as not to drop it. ST 398467700 DRIFT
- Remove the rear bearing cone from drive pinion by supporting the cone with ST. NOTE: Place the replacer so that its center-recessed side faces the pinion gear. ST 398517700 REPLACER
- Remove the front oil seal from differential carrier using ST. ST 398527700 PULLER ASSY
- Remove the pilot bearing together with the front bearing cone and spacer using the ST. ST 398467700 DRIFT
- When replacing the bearings, use a brass bar to tap out the front bearing cup and rear bearing cup (in this order).
ASSEMBLY
Note. Assemble in the reverse order of disassembly. Check and adjust each part during assembly. Keep the shims and washers in order, so that they are not improperly installed. Thoroughly clean the surfaces on which the shims, washers and bearings are to be installed. Apply differential gear oil when installing the bearings and thrust washers. Be careful not to mix up the RH and LH bearing races. Use a new O-ring and gasket. Replace the oil seal with a new part at every disassembly. Apply differential gear oil to the lips when installing the oil seal.
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
Scheme 60
Scheme 61
Scheme 62
Scheme 63
Scheme 64
Scheme 65
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 71
Scheme 72
- Adjusting preload for front and rear bearings NOTE: Adjust the bearing preload between front and rear bearings with spacer and washer. Pinion height adjusting washer is not affected by this adjustment. The adjustment must not be carried out with oil seal inserted. Install the rear bearing race into the differential carrier using ST1 and ST2. ST1 398477701 HANDLE ST2 398477703 DRIFT 2 Install the front bearing race to the differential carrier using ST1 and ST2. ST1 398477701 HANDLE ST2 398477702 DRIFT Insert the ST1 into carrier with the pinion height adjusting washer and rear bearing cone fitted onto it. NOTE: If tooth contact (drive pinion, hypoid driven gear) is normal in the inspection before disassembling, verify that the washer is not deformed, and then reuse the used washer. Use new rear bearing cone. Install the preload adjusting spacer and washer, front bearing cone, ST2, companion flange and self-locking nut. ST1 398507702 DUMMY SHAFT ST2 398507703 DUMMY COLLAR Turn the ST1 by hand to smooth the bearing, and tighten the self-locking nut while measuring the initial load or initial torque with a spring scale or torque wrench. Select the preload adjusting washer and spacer so that the specified preload is obtained when nut is tightened to the specified torque. NOTE: Use a new self-locking nut. Measure the preload in direction of tangent to the flange. Be careful not to give excessive preload. When tightening the self-locking nut, lock ST1 with ST2 as shown in the illustration. ST1 398507702 DUMMY SHAFT ST2 398507704 BLOCK Tightening torque: 181.5 N.m (18.5 kgf-m, 133.9 ft-lb) Initial load: 18.1 - 38.8 N (1.8 - 4.0 kgf, 4.1 - 8.7 lb) Initial torque: 0.69 - 1.47 N.m (0.07 - 0.15 kgf-m, 0.51 - 1.08 ft-lb) PARTS THICKNESS CHART Preload adjusting washer Part No. Thickness mm (in) 383705200 2.59 (0.1020) 383715200 2.57 (0.1012) 383725200 2.55 (0.1004) 383735200 2.53 (0.0996) 383745200 2.51 (0.0988) 383755200 2.49 (0.0980) 383765200 2.47 (0.0972) 383775200 2.45 (0.0965) 383785200 2.43 (0.0957) 383795200 2.41 (0.0949) 383805200 2.39 (0.0941) 383815200 2.37 (0.0933) 383825200 2.35 (0.0925) 383835200 2.33 (0.0917) 383845200 2.31 (0.0909) PARTS SPECIFICATION CHART Preload adjusting spacer Part No. Length mm (in) 383695201 56.2 (2.213) 383695202 56.4 (2.220) 383695203 56.6 (2.228) 383695204 56.8 (2.236) 383695205 57.0 (2.244) 383695206 57.2 (2.252)
- Adjusting drive pinion height: Adjust the drive pinion height with washer installed between the rear bearing cone and the back of pinion gear. Attach the ST2. NOTE: At this time, install a provisionally selected or previously used pinion height adjusting washer. Measure and record the thickness. ST1 398507702 DUMMY SHAFT ST2 398507701 DIFFERENTIAL CARRIER GAUGE ST3 398507703 DUMMY COLLAR Measure the clearance "N" between the end of ST2 and the end surface of ST1 by using a thickness gauge. NOTE: Make sure there is no clearance between the case and ST2. ST1 398507702 DUMMY SHAFT ST2 398507701 DIFFERENTIAL CARRIER GAUGE Obtain the thickness of pinion height adjusting washer to be inserted from the following formula, and replace the temporarily installed washer with this one. T = To N+ - (H x 0.01) - 0.20 mm (0.0079 in) NOTE: Use copies of this page. PARTS THICKNESS CHART T Thickness of pinion height adjusting washer mm (in) To Thickness of washer temporarily inserted mm (in) N Clearance of thickness gauge mm (in) H illustration marked on drive pinion head Memo: (Example of calculation) To = 3.39 mm (0.1335 in) N = 0.24 mm (0.0094 in) H = + 1 T = 3.39 mm (0.1335 in) + 0.24 mm (0.0094 in) - 0.01 mm (0.0004 in) - 0.20 mm (0.0079 in) = 3.42 mm (0.1346 in) Result: Thickness = 3.42 mm (0.1346 in) Therefore use washer 383605200. PARTS THICKNESS CHART Pinion height adjusting washer Part No. Thickness mm (in) 383495200 3.09 (0.1217) 383505200 3.12 (0.1228) 383515200 3.15 (0.1240) 383525200 3.18 (0.1252) 383535200 3.21 (0.1264) 383545200 3.24 (0.1276) 383555200 3.27 (0.1287) 383565200 3.30 (0.1299) 383575200 3.33 (0.1311) 383585200 3.36 (0.1323) 383595200 3.39 (0.1335) 383605200 3.42 (0.1346) 383615200 3.45 (0.1358) 383625200 3.48 (0.1370) 383635200 3.51 (0.1382) 383645200 3.54 (0.1394) 383655200 3.57 (0.1406) 383665200 3.60 (0.1417) 383675200 3.63 (0.1429) 383685200 3.66 (0.1441)
- Install the selected pinion height adjusting washer on drive pinion, and press the rear bearing cone into position with ST. ST 398177700 INSTALLER
- Insert the drive pinion into the differential carrier, and install the preselected preload adjusting spacer and washer.
- Press-fit the front bearing cone into case with ST1, ST2 and ST3. ST1 398507703 DUMMY COLLAR ST2 399780104 WEIGHT ST3 899580100 INSTALLER
- Insert the spacer, then press-fit the pilot bearing with ST1 and ST2. ST1 399780104 WEIGHT ST2 899580100 INSTALLER
- Using the ST, install the oil seal. NOTE: Use a new oil seal. Press-fit until the oil seal end comes 1 mm (0.04 in) inward from end of carrier. Apply differential gear oil to the oil seal lips. ST 498447120 INSTALLER
- Press-fit the companion flange with ST1 and ST2. NOTE: Be careful not to damage the bearing. ST1 899874100 INSTALLER ST2 399780104 WEIGHT
- Apply seal material on the drive pinion shaft thread and new self-locking nut seat. Seal material: THREE BOND 1324 (Part No. 004403042) or equivalent
- Attach the new self-locking nut and use the ST to fix the companion flange in place, then tighten the self-locking nut. Tightening torque: 181.5 N.m (18.5 kgf-m, 133.9 ft-lb) ST 498427200 FLANGE WRENCH
- Check the initial torque or initial load. Initial load: 18.1 - 38.8 N (1.8 - 4.0 kgf, 4.1 - 8.7 lbf) Initial torque: 0.67 - 7.47 N.m (0.07 - 0.15 kgf-m, 0.49 - 1.08 ft-lb)
- Assembling differential case Install the side gears and pinion mate gears, with their thrust washers, pinion mate gear washer, and pinion mate shaft, into the differential case. NOTE: Apply gear oil on both sides of the washer and on the side gear shaft before installing. Insert the pinion mate shaft into the differential case by aligning the lock pin holes. Measure the side gear backlash. Side gear backlash: 0.10 - 0.20 mm (0.004 - 0.008 in) Adjust the backlash as specified by selecting side gear thrust washer. PARTS THICKNESS CHART Side gear thrust washer Part No. Thickness mm (in) 383445201 0.75 - 0.80 (0.0295 - 0.0315) 383445202 0.80 - 0.85 (0.0315 - 0.0335) 383445203 0.85 - 0.90 (0.0335 - 0.0354) Check the condition of rotation after applying differential gear oil to the gear tooth surfaces and thrust washer surfaces. Drive the pinion shaft lock pin into the differential case.
- Install the driven gear to the differential case. NOTE: Before installing bolts, apply seal material to bolt threads. Seal material: THREE BOND 1324 (Part No. 004403042) or equivalent Make sure there is no clearance between the differential case and driven gear. Tighten opposing bolts in order. Tightening torque: 103 N.m (10.5 kgf-m, 76.0 ft-lb)
- Using the ST, press-fit the side bearing cone to the differential case. ST 398487700 DRIFT
- Assembling side retainer Using the ST, press-fit the side bearing race to the side retainer. ST 398417700 DRIFT Install the oil seal. < Ref. to «REPLACEMENT»(ref-465435-S30908390662012042000000) , Rear Differential Side Oil Seal . >
- Side retainer shim adjustment The hypoid driven gear backlash and side bearing preload can be adjusted by the side retainer shim thickness. Install the differential case assembly into differential carrier in the reverse order of disassembly. NOTE: Be careful not to hit the teeth of hypoid driven gear against the differential carrier. Install the side retainer shim and O-ring. NOTE: Use new O-rings. Be careful not to mix up the side retainer shim RH and LH. Replace broken or corroded side retainer shims with a new part of the same thickness. PARTS THICKNESS CHART Side retainer shim Part No. Thickness mm (in) 383475201 0.20 (0.0079) 383475202 0.25 (0.0098) 383475203 0.30 (0.0118) 383475204 0.40 (0.0157) 383475205 0.50 (0.0197) Align the arrow mark on the differential carrier with the arrow mark on the side retainer when installing the side retainer. NOTE: Be careful that the side bearing outer race is not damaged by the bearing roller. Tighten the side retainer bolts. Tightening torque: 10.5 N.m (1.1 kgf-m, 7.7 ft-lb) Measure the hypoid driven gear to drive pinion backlash. Set the magnet base on differential carrier. Align the contact point of dial gauge with tooth face of hypoid driven gear, and move hypoid driven gear while holding drive pinion still. Read the value indicated on dial gauge. If the backlash is outside the standard range, adjust the side retainer shim by the following method. When backlash is less than 0.1 mm (0.004 in): Reduce the thickness of shim on the back side of the hypoid driven gear and increase the thickness of shims on the teeth side of the hypoid driven gear. When backlash exceeds 0.2 mm (0.008 in): Increase the thickness of shim on the back side of the hypoid driven gear and reduce the thickness of shims on the teeth side of the hypoid driven gear. Backlash: 0.10 - 0.20 mm (0.004 - 0.008 in) Measure the total preload of the drive pinion. If the total preload is not within specification, adjust the thickness of side retainer shims, increasing/reducing both shims by an even amount at a time. Total preload: 20.7 - 54.4 N (2.1 - 5.5 kgf, 4.7 - 12.2 lbf)
- Recheck the hypoid driven gear to drive pinion backlash. Backlash: 0.10 - 0.20 mm (0.004 - 0.008 in)
- Check the runout on the back side of the hypoid driven gear, and make sure that the pinion and hypoid driven gears rotate smoothly. If the runout on the back side of the hypoid driven gear exceeds the specification, check for any foreign material between the hypoid driven gear and differential case, and for any deformation of the case or gear. Hypoid driven gear back surface runout: 0.05 mm (0.002 in)
- Checking and adjusting the tooth contact of hypoid driven gear Apply lead-free red dye evenly on the both sides of three to four teeth of the hypoid driven gear. Check the contact pattern after rotating the hypoid driven gear several revolutions back and forth until a definite contact pattern appears on the hypoid driven gear. When the contact pattern is not correct, adjust. NOTE: Be sure to wipe off the lead-free red dye completely after the adjustment is completed. Correct tooth contact Check item: Tooth contact pattern is slightly shifted toward toe side under no-load rotation. (When driving, it moves towards the heel side.) Face contact Check item: Backlash is too large. Contact pattern Corrective action: Reduce the thickness of pinion height adjusting washer according to the procedure for bringing drive pinion away from hypoid driven gear. Flank contact Check item: Backlash is too small. Contact pattern Corrective action: Increase thickness of pinion height adjusting washer according to the procedure for bringing drive pinion close to hypoid driven gear side. Toe contact (inside contact) Check item: Teeth contact area is too small. Contact pattern Corrective action: Reduce the thickness of pinion height adjusting washer according to the procedure for bringing drive pinion away from hypoid driven gear. Heel contact (outside end contact) Check item: Teeth contact area is too small. Contact pattern Corrective action: Increase thickness of pinion height adjusting washer according to the procedure for bringing drive pinion close to hypoid driven gear side.
- If proper tooth contact is not obtained, adjust the tooth contact area by changing the thickness of RH and LH side retainer shims and the pinion height adjusting washers. After adjustment, check the hypoid gear backlash and readjust the tooth contact area as necessary. Drive pinion height ST1 398507702 DUMMY SHAFT ST2 398507701 DIFFERENTIAL CARRIER GAUGE T = To + N - (H x 0.01) - 0.20 mm (0.008 in) PARTS THICKNESS CHART T Thickness of pinion height adjusting washer mm (in) To Thickness of washer temporarily inserted mm (in) N Clearance of thickness gauge mm (in) H illustration marked on drive pinion head Hypoid gear backlash Backlash: 0.10 - 0.20 mm (0.004 - 0.008 in)
- Remove the RH and LH side retainers.
- Install the O-ring to left and right side retainers. NOTE: Use new O-rings.
- Install the oil seal to the side retainer of both sides. < Ref. to «REPLACEMENT»(ref-465435-S30908390662012042000000) , Rear Differential Side Oil Seal . >
- Align the arrow mark on the differential carrier with the arrow mark on the side retainer when installing the side retainer.
- Apply liquid gasket to the bolts indicated by arrows, and tighten the bolts to the specified torque. Liquid gasket: THREE BOND 1110B (Part No. K0879Y0020) or equivalent Tightening torque: 10.5 N.m (1.1 kgf-m, 7.7 ft-lb)
- Install the gasket and rear cover, and tighten the bolts to specified torque. NOTE: Use a new gasket. Tightening torque: 29.5 N.m (3.0 kgf-m, 21.8 ft-lb)
- Install the air breather cap. NOTE: When installing the air breather cap, do not tap section (A). Be sure to tap section (B) to install.
- Install the drain plug. NOTE: Apply liquid gasket to the drain plug. Liquid gasket: THREE BOND 1105 (Part No. 004403010) or equivalent Tightening torque: 49 N.m (5.0 kgf-m, 36.1 ft-lb)
- Install the filler plug.
