PROCEDURE
| CAUTION | Subaru Select Monitor is required for reading DTC, performing diagnosis and reading current data. Remove foreign matter (dust, water, oil, etc.) from the body integrated unit connector during removal and installation. For model with immobilizer, registration of immobilizer may be needed after the replacement of controller etc. For details, refer to the PC application help for Subaru Select Monitor. |
Note. To check harness for open or short circuits, shake the suspected trouble spot or connector. Check List for Interview < Ref. to CHECK LIST FOR INTERVIEW . >
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK PRE-INSPECTION. Ask the customer when and how the trouble occurred using the interview check list. < Ref. to CHECK LIST FOR INTERVIEW . > | Did you interview the customer? | Go to step 2. | Interview the customer. |
| 2 BASIC INSPECTION. Check components which might affect body control. < Ref. to INSPECTION , General Description. > | Is the component that might influence the body control problem normal? | Go to step 3. | Repair or replace each component. |
| 3 CHECK DTC. Read the DTC. < Ref. to READ DIAGNOSTIC TROUBLE CODE (DTC) . > NOTE: If the communication function of the Subaru Select Monitor cannot be executed properly, check the communication circuit. < Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor. > Record all DTCs and freeze frame data. | Is DTC displayed on Subaru Select Monitor? | Go to step 5. | Go to step 4 . |
| 4 PERFORM GENERAL DIAGNOSTICS. Inspect using "General Diagnostics Table". < Ref. to GENERAL DIAGNOSTIC TABLE . > | Is result of inspection OK? | LAN system is normal. | Go to step 5 . |
| 5 PERFORM DIAGNOSIS. Correct the cause of trouble. Perform the Clear Memory Mode. < Ref. to CLEAR MEMORY MODE . > Read the DTC. < Ref. to READ DIAGNOSTIC TROUBLE CODE (DTC) . > | Is DTC displayed on Subaru Select Monitor? | Repeat step 5 until DTC is not shown. | Finish the diagnosis. |
| NOTE |
|---|
| If the communication function of the Subaru Select Monitor cannot be executed properly, check the communication circuit. < Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor. > |
DIAGNOSTIC PROCEDURE CHART
CHECK
Inspect the following item about the vehicle's state.
Scheme 24
Scheme 25
Scheme 26
SUPPLEMENTAL RESTRAINT SYSTEM "AIRBAG"
Airbag system wiring harness is routed near the body integrated unit and twisted pair line.
| CAUTION | Do not use electric test equipment on any wiring harnesses and connectors [2-9] airbag system. Be careful not to damage the airbag system wiring harness when servicing the body integrated unit and LAN system. |
Scheme 27
Scheme 28
- Bus line of LAN system is twisted pair line. Be careful not to bypass or partly unbind the twisted pair line.
- Do not make clearance between bus lines (CAN High, CAN Low).
- Difference of bus line length should be within 10 cm (3.94 in).
- Fray near the connector should be within 8 cm (3.14 in).
- If the characteristics of the twisted pair line are changed, it may extremely weaken against noise.
- When repairing the harness, connect the wires using soldering and protect it with insulating tape etc.
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance, voltage and current. |
GENERAL TOOL DESCRIPTION CHART
Scheme 29
Scheme 30
Scheme 31
| Contents | Terminal No. | Standard | Measuring condition |
|---|---|---|---|
| BAT (control) | B6 <--> chassis ground | 9 - 16 V | Always |
| BAT (backup) | C2 <--> chassis ground | 9 - 16 V | Always |
| BAT (door lock) | A34 <--> chassis ground | 9 - 16 V | Always |
| BAT (shift lock/key lock) | D22 <--> chassis ground | 9 - 16 V | Always |
| ACC (rear wiper) | D21 <--> chassis ground | Less than 1.5 V --> 9 - 16 V | ACC OFF --> ACC ON |
| Ground | A28 <--> chassis ground | Less than 1.5 V | Always |
| Ground | B17 <--> chassis ground | Less than 1.5 V | Always |
| Ground | C20 <--> chassis ground | Less than 1.5 V | Always |
| Ground | D27 <--> chassis ground | Less than 1.5 V | Always |
| Key warning switch | D2 <--> chassis ground | Less than 1.5 V --> 9 - 16 V | With key removed --> inserted |
| ACC | B7 <--> chassis ground | Less than 1.5 V --> 9 - 16 V | ACC OFF --> ACC ON |
| IGN | B1 <--> chassis ground | Less than 1.5 V --> 9 - 16 V | IGN OFF --> IGN ON |
| P range switch | C4 <--> chassis ground | Less than 1.5 V --> 8 V or more | P range --> other than P range |
| Stop light switch | B2 <--> chassis ground | Less than 1.5 V --> 8 V or more | With brake pedal released --> depressed |
| Door switch, driver's seat | A19 <--> chassis ground | 8 V or more --> less than 1.5 V | With driver's door closed --> opened |
| Door switch, passenger's seat | A32 <--> chassis ground | 8 V or more --> less than 1.5 V | With passenger's door closed --> opened |
| Door switch, rear RH seat | A6 <--> chassis ground | 8 V or more --> less than 1.5 V | With rear RH seat door closed --> opened |
| Door switch, rear LH seat | A20 <--> chassis ground | 8 V or more --> less than 1.5 V | With rear LH seat door closed --> opened |
| Door switch, trunk/rear gate | A33 <--> chassis ground | 8 V or more --> less than 1.5 V | With rear gate closed --> opened |
| Rear gate opener button | C24 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Manual switch (LOCK) | A15 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Manual switch (UNLOCK) | A29 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Delivery (test) mode connector | A17 <--> chassis ground | 8 V or more --> less than 1.5 V | When delivery (test) mode connector is connected |
| Front wiper input RTN | C5 <--> chassis ground | 8 V or more --> less than 1.5 V | When front wiper is reversed |
| Rear wiper switch ON | C18 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Rear wiper switch (INT) | C27 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Rear wiper switch, washer | C28 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Lighting 1 switch | B11 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Lighting II switch | C8 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| D6 <--> chassis ground | 8 V or more --> less than 1.5 V | Key warning switch ON and lighting switch OFF --> ON | |
| Dimmer switch, Hi beam | B12 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Dimmer switch, passing | B22 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Front fog light switch | B24 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| MT reverse switch | B18 <--> chassis ground | Less than 1.5 V --> 8 V or more | Other than reverse --> reverse |
| Parking brake switch | C15 <--> chassis ground | 8 V or more --> less than 1.5 V | With parking brake not operated --> operated |
| Bright switch | A14 <--> chassis ground | Less than 1.5 V --> 8 V or more | Switch OFF --> ON |
| Illumination (Vi1) | A12 <--> chassis ground | Approx. 5 V | Always |
| Illumination (Vi2) | A3 <--> chassis ground | 0.5 V - approx. 5 V | Always |
| Illumination (Vi3) | A26 <--> chassis ground | Less than 1.5 V | Always |
| Fuel level sensor | C7 <--> chassis ground | Approx. 2 - 96 ohms | Ignition ON |
| Wiper deicer & rear defogger switch | A16 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Seat belt switch (driver's seat) | C16 <--> chassis ground | Less than 1.5 V --> 8 V or more | With seat belt unbuckled --> buckled |
| Seat belt switch (Passenger's seat) | C26 <--> chassis ground | Less than 1.5 V --> 8 V or more | With seat belt unbuckled --> buckled |
| Impact sensor | B8 <--> chassis ground | Less than 1.5 V --> 8 V or more | When a shock is applied |
| Key lock solenoid output | D11 <--> chassis ground | Less than 1.5 V --> 6 V or more | While key is inserted in other than P range |
| Shift lock solenoid output | D12 <--> chassis ground | Less than 1 V --> 9 V or more | When vehicle stopped, IGN ON, other than P range, brake pedal depressed |
| Rear wiper output ON | D9 <--> chassis ground | Less than 1 V --> 9 V or more | When rear wiper operates |
| Rear wiper output RTN | D8 <--> chassis ground | Less than 1 V --> 9 V or more | When rear wiper reversed |
| Door lock output | A7 <--> A8 | Less than 1 V --> 9 V or more | During lock output |
| Door unlock output | A8 <--> A7 | Less than 1 V --> 9 V or more | While unlock output |
| Driver's side door unlock output | A23 <--> A7 | Less than 1 V --> 9 V or more | While unlock output |
| Trunk/rear gate UNLOCK output | A22 <--> chassis ground | Less than 1 V --> 9 V or more | While rear gate UNLOCK output |
| Lighting power supply | C1 <--> chassis ground | Less than 1 V --> 9 V or more | "With back-up fuse inserted, ACC ON or IGN ON" or "When key warning switch is ON" |
| D1 <--> chassis ground | |||
| Clearance light relay output | D19 <--> chassis ground | 9 V or more --> less than 1 V | Small light ON |
| Lo beam relay output | C3 <--> chassis ground | 9 V or more --> less than 1 V | Headlight switch ON |
| D7 <--> chassis ground | 9 V or more --> less than 1 V | Headlight switch ON | |
| Hi beam relay output | D20 <--> chassis ground | 9 V or more --> less than 1 V | Headlight switch ON and Hi beam ON or Passing switch ON |
| Front fog light relay output | D17 <--> chassis ground | 9 V or more --> less than 1 V | Headlight switch ON, and front fog light switch ON |
| DRL cancel output | D18 <--> chassis ground | 9 V or more --> less than 1 V | When Hi beam 100 % illuminates |
| Room light output | D5 | Pulse control | Illumination is adjusted through PWM control |
| Key ring illumination output | C23 | Pulse control | Illumination is adjusted through PWM control |
| Illumination output | A2 | Pulse control | Illumination is adjusted through PWM control |
| Map light output (model with sunroof) | D4 | Pulse control | Illumination is adjusted through PWM control |
| Rear defogger relay output | D16 <--> chassis ground | 9 V or more --> less than 1 V | While rear defogger output |
| Wiper deicer relay output | D15 <--> chassis ground | 9 V or more --> less than 1 V | While wiper deicer output |
| Seat belt warning light passenger's seat | A25 <--> chassis ground | 9 V or more --> less than 1 V | Indicator go off --> illuminate |
| Buzzer sound output | D24 <--> chassis ground | Less than 1 V --> 9 V or more | Door lock --> unlock with keyless entry system |
| Turn & hazard output | C22 <--> chassis ground | 9 V or more --> less than 1 V | Door lock or unlock with keyless entry system |
| Horn relay output | D29 <--> chassis ground | 9 V or more --> less than 1 V | During security alarm operation |
| Security indicator output | A10 <--> chassis ground | 9 V or more --> less than 1 V | While indicator in combination meter blinks |
| Immobilizer antenna 1 | B26 <--> B25 | 30 - +30 V | While key secret code is verified |
| Immobilizer antenna 2 | B25 <--> B26 | ||
| Immobilizer communication_1 | B4 | Can not be measured because of digital communication | Serial communication line |
| Immobilizer communication_2 | B15 | Can not be measured because of digital communication | Serial communication line |
| Keyless entry module communication | A24 | Can not be measured because of digital communication | Serial communication line |
| SSM communication (K line) | B20 | Can not be measured because of digital communication | Serial communication line |
| Body system CAN_Hi | A1 <--> chassis ground | Can not be measured because of digital communication | Serial communication line |
| Body system CAN_Lo | A9 <--> chassis ground | Can not be measured because of digital communication | Serial communication line |
| Driving system CAN_Hi | B3 <--> chassis ground | Can not be measured because of digital communication | Serial communication line |
| Driving system CAN_Lo | B9 <--> chassis ground | Can not be measured because of digital communication | Serial communication line |
CONTROL MODULE CONNECTOR TERMINALS REFERENCE CHART
DETECTING CONDITION
Defective harness connector
LIST
| Items to be displayed | Unit of measure | Remarks | Note |
|---|---|---|---|
| BATT voltage (control) | 9 - 16 V | Body integrated unit input value | Always |
| BATT voltage (BACKUP) | 9 - 16 V | Body integrated unit input value | Always |
| IG power supply voltage | 9 - 16 V | Body integrated unit input value | Ignition switch ON |
| ACC voltage | 9 - 16 V | Body integrated unit input value | Ignition switch ACC |
| Illumination VR Voltage | 0 - 5 V | Body integrated unit input value | Input value from illumination volume |
| Illumi. output d-ratio | 0 - 100% | Body integrated unit output value | Small light ON Illumination volume is other than bright. |
| Ambient Temperature | 40 - 87.5°C | CAN data input value | Ignition switch ON |
| Fuel level voltage | 0 - 10 V | Body integrated unit input value | Ignition switch ON |
| Fuel level resistance | 0 - 102.3 ohms | Body integrated unit input value | Ignition switch ON |
| Key-lock solenoid V | 6 - 15 V | Body integrated unit output value | Key warning switch ON, other than parking range Ignition ON |
| Number of regist. | 0 - 4 | Number of keyless key registered | Number of transmitter registered is displayed |
| Front Wheel Speed | Km/h | CAN data input value | Reception from VDC module |
| VDC/ABS latest f-code | DTC display (Temporarily) | CAN data input value | It is normal when DTC is not been input even if this code is displayed. Received from VDC (displayed by hexadecimal number system) |
| Blower Fan Steps | 0 - 2 levels | CAN data input value | 0: OFF, 1: Low, 2: 2 levels or more Reception from air conditioner ECM |
| Fuel level resistance 2 | 0 - 102.3 ohms | CAN data output value | Reception from body integrated unit |
| Fuel consumption | Cc/s | CAN data input value | Reception from ECM and transmission to center monitor |
| Coolant Temp. | 40 - 130°C | CAN data input value | Reception from ECM |
| Vehicle longitudinal G | M/s 2 | CAN data input value | Reception from VDC module |
| SPORT Shift Stages | 0 - 7 levels | CAN data input value | (0: Light OFF; 1 - 5: Gear display; 6: Fail; 7: ATF temperature High/Low) Reception from TCM |
| Shift Position | 0 - 7 levels | CAN data input value | 0: 1, 1: 2, 2: 3, 3: 4, 4: D, 5: N, 6: R, 7: P shift position (8 indicates no input) 8 is displayed in manual mode Reception from TCM |
| VDC/ABS condition | 0 - 4 | CAN data input value | Reception from VDC module |
| Destination Code | 0 - 16 | CAN data input value | Reception from combination meter |
| Touch SW | 0 - 64 | CAN data input value | Reception from navigation module |
| Key-lock warning SW | ON/OFF | Body integrated unit input value | ON when ignition key inserted |
| Stop Light Switch | ON/OFF | Body integrated unit input value | ON when brake pedal is depressed |
| Front fog lamp SW input | ON/OFF | Body integrated unit input value | When front fog light switch is ON |
| Driver's door SW input | ON/OFF | Body integrated unit input value | ON when driver's door is open |
| P-door SW input | ON/OFF | Body integrated unit input value | ON when passenger's door is open |
| Rear right door SW input | ON/OFF | Body integrated unit input value | ON when rear right door is open |
| Rear left door SW input | ON/OFF | Body integrated unit input value | ON when rear left door is open |
| R Gate SW input | ON/OFF | Body integrated unit input value | ON when rear gate/trunk open |
| Manual lock SW input | ON/OFF | Body integrated unit input value | Manual lock switch ON |
| Manual unlock SW input | ON/OFF | Body integrated unit input value | Manual unlock switch ON |
| Bright SW input | ON/OFF | Body integrated unit input value | ON when bright switch is ON |
| PSW | ON/OFF | Body integrated unit input value | ON when shift range is in parking Shift lever P switch signal |
| MT Reverse Switch | ON/OFF | Body integrated unit input value | Shift lever is at reverse position |
| R wiper ON SW input | ON/OFF | Body integrated unit input value | Rear wiper switch ON |
| R wiper INT SW input | ON/OFF | Body integrated unit input value | Rear wiper switch (INT ON) |
| R washer SW input | ON/OFF | Body integrated unit input value | Rear washer switch ON |
| Wiper deicer SW input | ON/OFF | Body integrated unit input value | Rear defogger switch ON |
| Rear Defogger SW | ON/OFF | Body integrated unit input value | |
| Driver's Seat SW input | ON/OFF | Body integrated unit input value | Driver's seat buckle switch ON |
| P seatbelt SW input | ON/OFF | Body integrated unit input value | Passenger's seat occupied and buckle switch ON |
| Fr wiper input | ON/OFF | Body integrated unit input value | ON when front wiper is operating |
| Parking Brake Switch Input | ON/OFF | Body integrated unit input value | ON when parking brake locked |
| R gate lock status SW input | ON/OFF | Body integrated unit inner memory value | Displays door lock/unlock state, ON when locked |
| R Gate Release SW input | ON/OFF | Body integrated unit input value | When rear gate opener button is ON |
| Rr Defogger output | ON/OFF | Body integrated unit output value | ON when rear defogger relay is operating |
| Lock actuat. LOCK output | ON/OFF | Body integrated unit output value | ON when LOCK signal is output |
| All seat UNLOCK output | ON/OFF | Body integrated unit output value | ON when unlock signal is output |
| D-seat UNLOCK output | ON/OFF | Body integrated unit output value | ON when unlock signal is output |
| R gate/trunk UNLK output | ON/OFF | Body integrated unit output value | ON when rear gate/trunk unlock signal is output |
| R wiper output | ON/OFF | Body integrated unit output value | ON when rear wiper motor is operating |
| Shift Lock Solenoid | ON/OFF | Body integrated unit output value | ON when shift lock solenoid is operating (only AT) |
| Key locking output | ON/OFF | Body integrated unit output value | With ignition switch ON and in other than the shift P range, with key in switch ON |
| Wiper deicer output | ON/OFF | Body integrated unit output value | ON when wiper deicer relay is operating |
| Hazard Output | ON/OFF | Body integrated unit output value | ON when answer-back signal is received or when emergency light (answer-back) is operating |
| Keyless Buzzer Output | ON/OFF | Body integrated unit output value | ON when lock/unlock signal is received |
| Horn Output | ON/OFF | Body integrated unit output value | ON when security warning is operating |
| D-belt warning light O/P | ON/OFF | CAN data output value | ON when ignition switch is turned to ON, and buckle switch is turned off |
| P-belt warning light O/P | ON/OFF | Body integrated unit output value | ON when ignition switch is turned to ON, occupant is seated, and buckle switch is turned off |
| Illumination lamp O/P | ON/OFF | Body integrated unit output value | ON when illumination is illuminated |
| Room lamp output | ON/OFF | Body integrated unit output value | When one of the doors is open |
| Key illumi. lamp o/p | ON/OFF | Body integrated unit output value | ON when key illumination light is illuminated |
| Immobilizer lamp output | ON/OFF | Body integrated unit output value | ON when immobilizer pilot light blinks |
| Keyless operation 1 | Regis L/Normal | Body integrated unit input value | When keyless is registered |
| Keyless operation 2 | Deletion/Normal | Body integrated unit input value | When keyless registration is deleted |
| CC Main Lamp | ON/OFF | CAN data input value | Cruise control switch ON Reception from ECM and transmission to combination meter |
| CC Set Lamp | ON/OFF | CAN data input value | ON when cruise control vehicle speed is set Reception from ECM and transmission to combination meter |
| SPORT Lamp | ON/OFF | CAN data input value | SPORT mode switch ON Reception from TCM and transmission to combination meter (only AT) |
| SPORT Blink | Blink/OFF | CAN data input value | Blinks when there is an AT failure Reception from TCM and transmission to combination meter (only AT) |
| ATF Temperature Lamp | ON/OFF | CAN data input value | When ATF temperature rise (only AT) |
| ATF Blink | Blink/OFF | CAN data input value | Blinks when there is an AT failure Reception from TCM and transmission to combination meter (only AT) |
| ECO Lamp (AT) | ON/OFF | CAN data input value | Not applicable |
| ECO Lamp (MT) | ON/OFF | CAN data input value | Not applicable |
| Tire diameter abnormal 1 | ON/OFF | CAN data input value | Lit when FWD fuse is connected (4AT only) |
| Tire diameter abnormal 2 | Blink/OFF | CAN data input value | Blinks when the difference in rotation between front and rear wheels is 4% or more Reception from TCM and transmission to combination meter (only AT) |
| Shift Up Indication | UP/OFF | CAN data input value | ON when shift lever up-operation is possible (only AT) |
| Shift Down Indication | DOWN/OFF | CAN data input value | ON when shift lever down-operation is possible (only AT) |
| SPORT Shift (buzzer 1) | ON/OFF | CAN data input value | ON while the shift change prohibited warning buzzer is operating Reception from TCM and transmission to combination meter (only AT) |
| SPORT Shift (buzzer 2) | ON/OFF | CAN data input value | ON when the ATF high temperature warning buzzer is operating Reception from TCM and transmission to combination meter (only AT) |
| ABS/VDC Judging | ABS/VDC | CAN data input value | Transmission from vehicle dynamic control (VDC) to high speed control module |
| Small Light SW | ON/OFF | CAN data output value | ON when small light is illuminated |
| Headlamp | ON/OFF | CAN data output value | When headlight LO is ON |
| High Beam | ON/OFF | CAN data output value | When headlight HI is ON |
| Km/mile display | Mile/km | CAN data input value | Unit of distance received from meter |
| Large diameter tire | Large Tire/Others | CAN data output value | Large tire when the standard tire is 18 in Reception from combination meter |
| Number of cylinders | 4 Cylinder/6 Cylinder | CAN data input value | Display engine equipped |
| Cam shaft specification | SOHC/DOHC | CAN data input value | Display engine equipped |
| Turbo | Turbo/Non-turbo | CAN data input value | Display engine equipped |
| E/G displacement (2.5L) | 2.5 L/OFF | CAN data input value | Display engine equipped |
| E/G displacement (3.0L) | 3.0 L/OFF | CAN data input value | Display engine equipped |
| AT Vehicle ID Signal | ON/OFF | CAN data input value | Display transmission equipped |
| Blower fan information | ON/OFF | CAN data input value | ON when blower fan is operating (always OFF for auto A/C equipped models) |
| Smart judging flag | Smart/other than Smart | CAN data output value | Smart when integrated unit judges as a model with Smart |
| Diesel judging flag | Diesel/other than diesel | CAN data output value | Display diesel/other than diesel |
| Turbo judging flag | Non-turbo/Turbo | CAN data output value | Display engine equipped |
| AT type judging flag | 4AT/5AT | CAN data output value | Display transmission equipped |
| CVT judging flag | CVT/other than CVT | CAN data output value | Display CVT judging |
| Center display failure | OK/NG | CAN data input value | NG when there is a center display failure Reception from center display (NAVI monitor) |
| NAVI Failure | OK/NG | CAN data input value | NG when there is a navigation system failure Reception from Center Display |
| IE Bus failure | Can not use | CAN data input value | Reception from Center Display |
| Auto A/C failure | OK/NG | CAN data input value | NG when there is a failure in auto air conditioning system Reception from auto A/C module |
| EBD Warning Light | ON/OFF | CAN data input value | OK when EBD warning light is illuminated Reception from VDC/ABS and transmission to combination meter |
| ABS Warning Light | ON/OFF | CAN data input value | OK when ABS warning light is illuminated Reception from VDC/ABS and transmission to combination meter |
| VDC OFF flag | ON/OFF | CAN data input value | Vehicle dynamics control OFF SW is ON Reception from VDC/ABS and transmission to combination meter |
| VDC/ABS OK B | OK/NG | CAN data input value | NG when there is an error in VDC/ABS system Reception from VDC/ABS |
| Lighting 1 Switch Input | ON/OFF | Body integrated unit input value | ON when lighting switch illumination is ON |
| Lighting II Switch Input | ON/OFF | Body integrated unit input value | ON when lighting switch, headlight is ON |
| Dimmer Hi Switch Input | ON/OFF | Body integrated unit input value | ON when dimmer switch is Hi beam position |
| Dimmer Pass Switch Input | ON/OFF | Body integrated unit input value | ON when dimmer switch is passing position |
| Lighting 1 Lamp Output | ON/OFF | Body integrated unit output value | ON when small light is illuminated |
| Lighting II Lamp Output | ON/OFF | Body integrated unit output value | ON when headlight is illuminated |
| Lighting Hi Lamp Output | ON/OFF | Body integrated unit output value | ON when Hi beam is illuminated |
| Front Fog Lamp Output | ON/OFF | Body integrated unit output value | ON when front fog light is ON. |
| DRL Cancel Output | ON/OFF | Body integrated unit output value | ON when lighting switch is "Headlight ON" and dimmer switch is "Hi beam" or "Passing" position |
| Power Supply Tr | ON/OFF | Body integrated unit output value | ON when lighting switch is "Head" position without inserting key in key cylinder |
| Spot map lamp output | ON/OFF | Body integrated unit output value | ON when one of the doors is open (except for tail gate) |
| Echo switch information | ON/OFF | CAN data output value | Not applicable |
| Off delay time | OFF, Short, Normal, Long | Body integrated unit setting items | Customize setting |
| Rr Defogger op. mode | Continuous/Normal | Body integrated unit setting items | Customize setting |
| Security Alarm Setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Impact Sensor Setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Alarm delay setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Lockout prevention | ON/OFF | Body integrated unit setting items | Customize setting |
| Impact sensor | ON/OFF | Body integrated unit setting items | Customize setting |
| Buzzer beeping setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Emergency light setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Buzzer setting | ON/OFF | Body integrated unit setting items | Customize setting |
| Auto locking | ON/OFF | Body integrated unit setting items | Customize setting |
| Passive Alarm | ON/OFF | Body integrated unit setting items | Customize setting |
| Door open warning | ON/OFF | Body integrated unit setting items | Customize setting |
| Dome Light Alarm Setting | ON/OFF | Body integrated unit setting items | Customize setting |
| Map Light Setting | ON/OFF | Body integrated unit setting items | Customize setting |
| Belt Warning Switch | ON/OFF | Body integrated unit setting items | Customize setting |
| Map lamp 30 sec off record | ON/OFF | Body integrated unit setting items | Customize setting |
| A/C ECM setting | ON/OFF | Body integrated unit setting items | Customize setting |
| Wiperdeicer | ON/OFF | Body integrated unit setting items | Customize setting |
| Sedan/Wagon Setting | Sedan/wagon | Body integrated unit setting items | Customize setting |
| MT/AT Setting | MT/AT | Body integrated unit setting items | Customize setting |
| 6MT Setting | 6MT/Other than 6MT | Body integrated unit setting items | Customize setting |
| Destination Setting | 0 - 16 | Body integrated unit setting items | |
| Factory initial setting | Factory/Market | Body integrated unit setting items | Customize setting |
CURRENT DATA CHART
Note. For detailed operation procedures, refer to PC application help for Subaru Select Monitor.
CONFIRMATION OF CURRENT SETTING
- On << Main Menu >> display, select {Each System Check}.
- On << System Selection Menu >> display, select {Integ. unit mode}.
- On << Integ. unit mode failure diag. >> display, select {Current Data Display & Save}.
- Using the scroll key, scroll the display screen up or down until the desired data is shown.
- Display the following item and record the settings.
Required items for new registration (Except for system not equipped)
| Item | Item to confirm | Remarks | |||
|---|---|---|---|---|---|
| Number of regist. | 1 | 2 | 3 | 4 | Registered ID type |
| Off delay time | OFF | Long | Normal | Short | Setting for lighting off time |
| Rr Defogger op. mode | Normal | Continuous | |||
| Security Alarm Setup | ON | OFF | |||
| Impact Sensor Setup | ON | OFF | Option setting | ||
| Alarm delay setup | ON | OFF | |||
| Lockout prevention | ON | OFF | |||
| Impact sensor | Support | No support | Option setting | ||
| Buzzer beeping setup | ON | OFF | |||
| Emergency light setup | ON | OFF | |||
| Buzzer setting | Support | No support | |||
| Passive Alarm | ON | OFF | |||
| Door open warning | Support | No support | |||
| Dome Light Alarm Setting | ON | OFF | |||
| Map Light Setting | ON | OFF | |||
| Belt Warning Switch | ON | OFF | Switch the belt warning lighting and the buzzer sound. | ||
| Map lamp 30 sec off record | Support | No support | |||
| A/C ECM setting | Support | No support | Model with auto A/C | ||
| Wiperdeicer | Support | No support | Option setting | ||
| Sedan/Wagon Setting | Sedan | Wagon | |||
| MT/AT Setting | AT | MT | |||
| 6MT Setting | 6MT | Other than 6MT | |||
| Factory initial setting | Factory | Market | Do not change to factory mode. | ||
REGISTRATION ITEMS REFERENCE CHART
REGISTRATION BODY INTEGRATED UNIT (FUNCTION SETTING)
| CAUTION | Body integrated unit is core of LAN system, and also can select the function of all vehicle system control. It is possible to control the original functions of vehicle when registrations of body integrated unit and function setting are corresponded to vehicle equipment. If registrations and function setting are different from vehicle equipment, vehicle system does not operate normally and diagnosis cannot be performed correctly. Pay attention to following item. Be sure to correspond registrations and function settings to vehicle equipment. Do not change the settings of vehicle improperly. Confirm key illumination does not blink when ignition key is turned ON, or "Factory initial setting" of body integrated unit registrations is set to "Market". If "Factory initial setting" is set to "Factory", key illumination blinks when ignition key is turned ON, to notify that the settings are unconfirmed. Key illumination does not blink with ignition switch turned to ON and go off with door closed. Be sure to register immobilizer if body integrated unit is replaced with a new part, (model with immobilizer) Make a registration of immobilizer when the parts related to immobilizer have been replaced. Refer to the PC application help for Subaru Select Monitor. |
- On << Main Menu >> display, select {Each System Check}.
- On << System Selection Menu >> display, select {Integ. unit mode}.
- Click the [OK] button after the control module name {Integ. Unit} is displayed.
- On << Integ. unit mode failure diag. >> display, select {Integ. Unit customizing}.
- Change the setting with UP/DOWN key. List of body integrated unit registration item NOTE: Setting is different depending on the grade of vehicle. BODY INTEGRATED UNIT REGISTRATION ITEM REFERENCE CHART Data Initial setting Registration Remarks Map lamp 30 sec off record OFF ON Set to "OFF" for models with door interlock switch in map light, "ON" for models without door interlock switch. OFF A/C ECM setting OFF ON Set to "ON" in case of model with auto A/C. Set to "OFF" in case of model without auto A/C. OFF wiperdeicer (Manufacturer option) OFF ON ON signal does not output with operation of wiper deicer switch if wiper deicer is set to "OFF" in models with a wiper deicer. OFF Sedan/Wagon Setting Wagon Wagon Door lock/unlock control by Wagon Sedan Door lock/unlock control by Sedan MT/AT Setting AT MT No control of shift lock solenoid, key-lock solenoid AT Control of shift lock solenoid, key-lock solenoid 6MT Setting Other than 6MT 6MT Set to "6MT" for 6MT model, and set to "Other than 6MT" for AT/5AT model. Other than 6MT Factory initial setting Factory Factory Be sure to set to "Market". After setting change, turn the ignition switch to OFF and settle the changed settings. Market (Confirmed) CAUTION: To perform normal operation of vehicle and diagnosis, the above settings must match the actual vehicle equipment. When body integrated unit is a new part or "Factory" mode, key illumination blinks to show equipment settings have not been completed. Check the detailed procedures of function setting. Be sure not to change Factory initial setting except when installing a new body integrated unit. NOTE: "Factory" mode: Body integrated unit has not been set yet. It can be recognized by key illumination blinking with ignition switch turned to ON. All replacement body integrated units are set to "Factory" mode. When replacing a body integrated unit, be sure to perform the registration operation. "Market" mode: Each settings have been set. It can be recognized by key ring illumination coming on in concocting with room light and going off with ignition switch turned to ON.
- Perform the Factory initial setting. On the << Integ. Unit customizing >> display screen of Subaru Select Monitor, select the {Factory initial setting}.
- Change the mode from Factory to Market.
- Turn the ignition switch to OFF to settle the setting.
- Change the Subaru Select Monitor system selection to << Immobilizer >> to register the immobilizer key.
- Perform the operation according to the "PC application help for Subaru Select Monitor".
- When key registration is completed, "Do you want to register remote engine start?" is displayed. Perform registration only for equipped models.
- Perform the User Customizing. < Ref. to «OPERATION»(ref-465425-S34719743222012042000000) , User Customizing. > NOTE: For detailed operation procedures, refer to PC application help for Subaru Select Monitor.
| DTC | Item | Content of diagnosis | Note |
|---|---|---|---|
| B1100 | Integ. Unit System Error | Memory read out error in body integrated unit | < Ref. to DTC B1100 INTEG. UNIT SYSTEM ERROR , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| B1101 | BATT p/supply malfunction cont. | Open or short in battery power supply control circuit Voltage malfunction caused by poor contact | < Ref. to DTC B1101 BATT P/SUPPLY MALFUNCTION CONT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| B1102 | BATT p/supply malfunction backup | Battery power supply backup circuit is open or shorted. Voltage malfunction caused by poor contact | < Ref. to DTC B1102 BATT P/SUPPLY MALFUNCTION BACKUP , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| B1103 | Ignition power failure | IGN power supply circuit is open or shorted. Voltage malfunction caused by poor contact | < Ref. to DTC B1103 IGNITION POWER FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| B1104 | ACC power failure | ACC power supply circuit is open or shorted. Voltage malfunction caused by poor contact | < Ref. to DTC B1104 ACC POWER FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| B1105 | Key interlock circuit abnormal | GND-output short of key interlock circuit | < Ref. to DTC B1105 KEY INTERLOCK CIRCUIT ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| B1106 | Shift lock circuit Failure | Open or power supply-output short, GND-output short in shift lock circuit | < Ref. to DTC B1106 SHIFT LOCK CIRCUIT FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1201 | CAN-HS counter abnormal | Communication is unstable because of high speed CAN communication error. | < Ref. to DTC U1201 CAN-HS COUNTER ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1202 | CAN-HS bus off | Integrated unit communication is shut down because of high speed CAN communication error. | < Ref. to DTC U1202 CAN-HS BUS OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1211 | CAN-HS ECM data abnormal | Received error data from ECM. | < Ref. to DTC U1211 CAN-HS ECM DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1212 | CAN-HS TCM data abnormal | Received error data from TCM. | < Ref. to DTC U1212 CAN-HS TCM DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1213 | CAN-HS VDC/ABS data abnormal | Received error data from VDC/ABS module. | < Ref. to DTC U1213 CAN-HS VDC/ABS DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1221 | CAN-HS ECM no-receive data | Not received data from ECM. | < Ref. to DTC U1221 CAN-HS ECM NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1222 | CAN-HS TCM no-receive Data | Not received data from TCM. | < Ref. to DTC U1222 CAN-HS TCM NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1223 | CAN-HS VDC/ABS no-receive data | Not received data from VDC/ABS CM. | < Ref. to DTC U1223 CAN-HS VDC/ABS NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1300 | CAN-LS malfunction | CAN-LS circuit is open or shorted. | < Ref. to DTC U1300 CAN-LS MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1301 | CAN-LS counter abnormal | Communication is unstable because of low speed CAN communication error. | < Ref. to DTC U1301 CAN-LS COUNTER ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1302 | CAN-LS bus off | Integrated unit communication is shut down because of low speed CAN communication error. | < Ref. to DTC U1302 CAN-LS BUS OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1311 | CAN-LS meter unit data abnormal | Received error data from meter. | < Ref. to DTC U1311 CAN-LS METER UNIT DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| U1321 | CAN-LS meter no-receive data | Not received data from meter. | < Ref. to DTC U1321 CAN-LS METER NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| B1401 | M Collation NG | Malfunction related immobilizer | < Ref. to DTC B1401 M COLLATION NG , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| B1402 | Immobilizer Key Collation NG | Malfunction related immobilizer | < Ref. to DTC B1402 IMMOBILIZER KEY COLLATION NG , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| B1403 | E/G request NG | Malfunction related immobilizer | < Ref. to DTC B1403 E/G REQUEST NG , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
| B1500 | Keyless UART com. Malfunction | Open or short circuit in keyless UART circuit | < Ref. to DTC B1500 KEYLESS UART COM. MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC). > |
DIAGNOSTIC TROUBLE CODE CHART
