Mechanism & Function -- Fuel Injection System (H4DOTC): Overview Subaru Forester SH

Fuel System 6 illustrations ~161 words

OPERATION

SI-DRIVE SELECTOR: It is possible to change modes by turning the knob on the console. Turn the knob counterclockwise for S (sport mode), turn clockwise for S# (sport sharp mode) and push the knob for I (intelligent mode). After turning the knob, it will return to its original position.

Scheme 25

Scheme 25: OPERATION
Scheme 25: OPERATION

Scheme 26

Scheme 26: MULTI-INFORMATION DISPLAY
Scheme 26: MULTI-INFORMATION DISPLAY

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Meter interrupt screen: When a mode change is performed, a mode change screen will be displayed for approximately 3 seconds, indicating which mode was selected. When displaying, a buzzer (blip) will sound.
  2. SI-DRIVE screen: By operating the control switch on the steering wheel, it is possible to display the SI-DRIVE screen. The SI-DRIVE screen will display a graph that changes according to the drive mode and accelerator opening.
  3. Mode display in screens other than SI-DRIVE: The driving mode will be displayed on the left side in screens other than SI-DRIVE.

Scheme 29

Scheme 29: CONTROLS
Scheme 29: CONTROLS

Scheme 30

Scheme 30
Scheme 30
