Fuel Injection System (H4SO): Maintenance Subaru Forester SH

DRAINING FUEL (WITH SUBARU SELECT MONITOR)

Note. If the fuel pump cannot be actuated, refer to DRAINING FUEL (THROUGH THE FUEL FILLER HOSE). Refer to DRAINING FUEL (THROUGH THE FUEL FILLER HOSE) , PROCEDURE, Fuel . Be careful not to let the battery run-out.

1. Release the fuel pressure. Refer to «RELEASING OF FUEL PRESSURE»(ref-325305-S19314969582009071800000) , PROCEDURE, Fuel .
2. Attach ST to the fuel delivery pipe and push ST in the direction of arrow mark to disconnect the fuel delivery hose. ST 42099AE000 QUICK CONNECTOR RELEASE CAUTION: Be careful not to spill fuel. Catch the fuel from hoses using a container or cloth.
3. Connect ST to the fuel delivery hose. ST 18471AA000 FUEL PIPE ADAPTER
4. Connect the gasoline proof hose to ST and put the end of the hose in the container.
5. Drive the fuel pump and drain the fuel using Subaru Select Monitor. Refer to «FUEL PUMP CONTROL (ON/OFF DRIVE)»(ref-325319-S33473455862009071800000) , OPERATION, System Operation Check Mode .

DRAINING FUEL (THROUGH THE FUEL FILLER HOSE)

Scheme 168

1. Set the vehicle on a lift.
2. Lift up the vehicle.
3. Remove the rear exhaust pipe and muffler. Refer to «REMOVAL»(ref-325320-S35059142112009071800000) , Rear Exhaust Pipe . Refer to «REMOVAL»(ref-325320-S22382758332009071800000) , Muffler .
4. Open the fuel filler lid, and remove the fuel filler cap.
5. Drain the fuel from the fuel filler pipe through the fill opening using the gasoline proof pump and the gasoline proof hose (010 or less).
6. Disconnect the fuel filler hose from the fuel filler pipe assembly. CAUTION: Be careful not to spill fuel. Catch the fuel from hoses using a container or cloth.
7. Set the container under the vehicle and insert the gasoline proof hose (010 or less) into the fuel filler hose to drain the fuel.
