Lighting System: Other Subaru Forester SH

Exterior Lights 20 illustrations ~1592 words

CAUTION

  1. Before removing or installing parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
  2. Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
  3. Adjust parts to the given specifications.
  4. Connect the connectors securely during reassembly.
  5. After reassembly, make sure functional parts operate smoothly.
WARNINGThe airbag system wiring harness is routed near electrical parts and switches. Do not use electrical test equipment on any airbag system wiring harnesses or connector circuits. Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches.

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance and voltage.

GENERAL TOOL DESCRIPTION CHART

HALOGEN TYPE HEADLIGHT

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Headlight System .

HID TYPE HEADLIGHT

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Headlight System .

CLEARANCE LIGHT AND ILLUMINATION LIGHT

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Clearance Light and Illumination Light System .

HEADLIGHT SWITCH

Refer to INSPECTION , Combination Switch (Light) .

HEADLIGHT RELAY

Measure the headlight relay resistance between terminals when connecting terminal No. 4 to the battery positive terminal and terminal No. 3 to the battery ground terminal.

Scheme 27

Scheme 27: HEADLIGHT RELAY
Scheme 27: HEADLIGHT RELAY
ContinuityTerminal No.Standard
Yes1 and 2Less than 1 ohms
No1 Mohms or more

TERMINAL CONTINUITY REFERENCE CHART

TAIL AND ILLUMINATION RELAY

Measure the resistance between the tail and illumination relay terminals when connecting terminal No. 4 to the battery positive terminal and terminal No. 3 to the battery ground terminal.

ContinuityTerminal No.Standard
Yes1 and 2Less than 1 ohms
No1 Mohms or more

TERMINAL CONTINUITY REFERENCE CHART

DAYTIME RUNNING LIGHT MODULE CHECK

StepCheckYesNo
1 CHECK DTC . Connect the Subaru Select Monitor. Read the DTC of the body integrated unit.Is DTC displayed?Perform the diagnosis according to DTC.Go to step 2 .
2 CHECK INPUT SIGNAL . Display the current data of the body integrated unit. Check the following input signals. Parking brake switch Shift position Light 2Is the input signal normal?Go to step 3 .Check the defective part.
3 CHECK RELAY . Check the daytime running light relay.Is the relay OK?Go to step 4 .Replace the relay.
4 CHECK HARNESS .Is the harness OK?Replace the body integrated unit. Refer to REMOVAL , Body Integrated Unit .Repair the harness.

DIAGNOSTIC PROCEDURE

DAYTIME RUNNING LIGHT RELAY

Measure the resistance between the daytime running relay terminals when connecting terminal No. 3 to the battery positive terminal and terminal No. 5 to the battery ground terminal.

Scheme 28

Scheme 28: DAYTIME RUNNING LIGHT RELAY
Scheme 28: DAYTIME RUNNING LIGHT RELAY
ContinuityTerminal No.Standard
Yes7 and 6Less than 1 ohms
No1 Mohms or more
Yes7 and 41 Mohms or more
NoLess than 1 ohms

TERMINAL CONTINUITY REFERENCE CHART

FRONT FOG LIGHT

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Front Fog Light System .

FRONT FOG LIGHT SWITCH

Measure the resistance between front fog light switch terminals.

Refer to INSPECTION , Combination Switch (Light) .

FRONT FOG LIGHT RELAY

Connect terminal No. 4 to battery positive terminal and terminal No. 3 to battery ground terminal, and measure the front fog light relay resistance between terminals.

ContinuityTerminal No.Standard
Yes1 and 2Less than 1 ohms
No1 Mohms or more

TERMINAL CONTINUITY REFERENCE CHART

TURN SIGNAL LIGHT AND HAZARD LIGHT

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Turn Signal Light and Hazard Light System .

TURN SIGNAL SWITCH

Refer to INSPECTION , Combination Switch (Light) .

HAZARD SWITCH

Measure the resistance between hazard switch terminals.

Scheme 29

Scheme 29: HAZARD SWITCH
Scheme 29: HAZARD SWITCH
Switch positionTerminal No.Standard
OFF2 and 31 Mohms or more
ONLess than 1 ohms

TERMINAL SWITCH REFERENCE CHART

TURN SIGNAL AND HAZARD MODULE

Connect the battery and turn signal light bulb to the module. The module is properly functioning if it blinks when power is supplied to the circuit.

Scheme 30

Scheme 30: TURN SIGNAL AND HAZARD MODULE
Scheme 30: TURN SIGNAL AND HAZARD MODULE

BACK-UP LIGHT

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Back-up Light System .

BACK-UP LIGHT SWITCH (MT MODEL)

Measure the resistance between the back-up light switch terminals.

Scheme 31

Scheme 31: BACK-UP LIGHT SWITCH (MT MODEL)
Scheme 31: BACK-UP LIGHT SWITCH (MT MODEL)
Switch positionTerminal No.Standard
When shift lever is set in reverse position1 and 2Less than 1 ohms
Other positions1 Mohms or more

TERMINAL SWITCH REFERENCE CHART

INHIBITOR SWITCH (AT MODEL)

Measure the resistance between the inhibitor switch terminals.

Scheme 32

Scheme 32: INHIBITOR SWITCH (AT MODEL)
Scheme 32: INHIBITOR SWITCH (AT MODEL)
Switch positionTerminal No.Standard
When the selector lever is in the "R" range7 and 8Less than 1 ohms
Other positions1 Mohms or more

TERMINAL SWITCH REFERENCE CHART

STOPLIGHT

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Stop Light System .

STOP LIGHT SWITCH

Measure the resistance between stop light switch terminals.

Scheme 33

Scheme 33: STOP LIGHT SWITCH
Scheme 33: STOP LIGHT SWITCH
Switch positionTerminal No.Standard
When brake pedal is depressed2 and 3Less than 1 ohms
When brake pedal is released1 Mohms or more

TERMINAL SWITCH REFERENCE CHART

ROOM LIGHT

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior Light System .

DOOR SWITCH

Measure the resistance between door switch terminals.

Scheme 34

Scheme 34: DOOR SWITCH
Scheme 34: DOOR SWITCH
Switch positionTerminal No.Standard
When door is opened1 and 3Less than 1 ohms
When door is closed1 M ohms or more

TERMINAL SWITCH REFERENCE CHART

REAR GATE LATCH SWITCH

Measure the resistance between rear gate latch switch terminals.

Scheme 35

Scheme 35: REAR GATE LATCH SWITCH
Scheme 35: REAR GATE LATCH SWITCH
Switch positionTerminal No.Standard
When rear gate is opened3 and 4Less than 1 ohms
When rear gate is closed1 Mohms or more

TERMINAL SWITCH REFERENCE CHART

LIGHTING SWITCH

Switch positionTerminal No.Standard
OFF1 Mohms or more
Tail14 and 16Less than 1 ohms
Head13,14 and 16Less than 1 ohms

TERMINAL SWITCH REFERENCE CHART

DIMMER & PASSING SWITCH

Switch positionTerminal No.Standard
Passing7, 8 and 16Less than 1 ohms
High beam7 and 16Less than 1 ohms

TERMINAL SWITCH REFERENCE CHART

Switch positionTerminal No.Standard
Left1 and 2Less than 1 ohms
Neutral1 Mohms or more
Right3 and 2Less than 1 ohms

TERMINAL SWITCH REFERENCE CHART

Switch positionTerminal No.Standard
OFF11 and 101 Mohms or more
ONLess than 1 ohms

TERMINAL SWITCH REFERENCE CHART

PROCEDURE

When parts related to the auto headlight beam leveling system are removed or replaced, perform the following procedures to initialize or reinitialize.

Note. Before performing initialization or reinitialization, check the following: Vehicle is parked on a level surface. The inflation pressure of tires is correct. Unload any cargo from the vehicle. Vehicle's fuel tank is fully filled. When determining whether to perform initialization or reinitialization, refer to the following

InitializationWhen the headlight leveler control module has been replaced with a new part.
ReinitializationWhen the headlight leveler control module has been replaced with a part from a different vehicle. When suspension parts have been removed or replaced. (Crossmember, transverse link, lateral link, strut) When the vehicle height sensor has been replaced or removed.

INITIALIZATION OR REINITIALIZATION REFERENCE CHART

INITIALIZATION

  1. Confirm that the indicator in the meter is repeatedly flashing twice.
  2. Bounce the vehicle several times to normalize the suspension.
  3. Make certain that someone is seated in the driver's seat.
  4. Turn the ignition ON, and within a period over 1.5 seconds and under 20 seconds, repeat headlight switch OFF ON 3 times or more.
  5. Confirm that the indicator in the meter flashes 3 times and turns OFF, completing the initialization. (At this time, the headlight beam adjustment is lowered, and then returns to the original position).
  6. Perform beam adjustment for the headlight. Refer to «ADJUSTMENT»(ref-325323-S02475391542009071800000) , Headlight Assembly .

REINITIALIZATION

  1. Bounce the vehicle several times to normalize the suspension.
  2. Make certain that someone is seated in the driver's seat.
  3. Turn the ignition ON, and within a period over 1.5 seconds and under 10 seconds, repeat headlight switch OFF ON 5 times or more.
  4. Check that the headlight beam drops once, then returns to normal.
  5. After confirming 4), turn the ignition switch to OFF within 30 seconds.
  6. Turn the ignition switch to ON again, and within a period over 1.5 seconds and under 10 seconds, repeat headlight switch OFF ON 5 times or more.
  7. Confirm that the indicator in the meter flashes 3 times and turns OFF, completing the reinitialization. (At this time, the headlight beam adjustment is lowered, and then returns to the original position).
  8. Perform beam adjustment for the headlight. Refer to «ADJUSTMENT»(ref-325323-S02475391542009071800000) , Headlight Assembly .
CAUTIONIf the indicator does not flash 3 times or the headlight beam does not operate, there is a possibility of an open circuit or faulty connection in the harness between the headlight leveler control module, front and rear vehicle height sensors and headlight assembly. Perform inspection and repair according to the inspection results, then perform initialization/reinitialization again. Refer to INSPECTION , Auto Headlight Beam Leveler System . Refer to PROCEDURE , Auto Headlight Beam Leveler System .

HID HEADLIGHT BALLAST

CAUTIONDo not work with wet hands. Because the lighting circuit on the HID headlights uses high voltage, be sure to confirm that the power supply is turned off before operation. Do not leave the headlight without a ballast for extended periods of time. Dust, moisture, etc. entering the headlight may affect its performance.
  1. Disconnect the ground cable from the battery.
  2. Remove the headlight assembly. Refer to «REMOVAL»(ref-325323-S03837004962009071800000) , Headlight Assembly .
  3. Remove the back cover.
  4. Disconnect the harness connector.
  5. Disconnect the harness connector, loosen the screws, and remove the headlight ballast.
  6. Disconnect the connector from the headlight ballast.

Scheme 36

Scheme 36
Scheme 36

Install in the reverse order of removal.

Tightening torque

1.3 N.m (0.13 kgf-m, 0.96 ft-lb)

CAUTIONWhen installing the ballast cover, be sure to install the gasket. After installing the ballast to the vehicle, be sure to perform beam adjustment

Note. Adjust the projector lens to near the center of the extension opening before installing the ballast. This makes the beam adjustment work easier.

HIGH BEAM & HALOGEN TYPE LOW BEAM

CAUTIONBecause the halogen bulb operates at a high temperature, dirt and oil on the bulb surface reduces the bulb's service life. Hold the flange portion when replacing the bulb. Never touch the glass portion. Do not leave the headlight without a bulb for a long time. Dust, moisture, etc. entering the headlight may affect its performance.
  1. Disconnect the ground cable from the battery.
  2. Remove the air intake duct (rear). (When removing the headlight bulb RH).
  3. Disconnect the harness connector.
  4. Remove the bulb assembly (A) then remove the high beam. To remove the low beam, remove the back cover (B), and then go to Step 5.
  5. Disconnect the connector, and remove the bulb.

Scheme 37

Scheme 37
Scheme 37

HID TYPE LOW BEAM

CAUTIONDo not work with wet hands. Because the lighting circuit uses high voltage, be sure to confirm that the power supply is turned off before operation. When replacing the bulb, hold the flange portion, and never touch the glass. Do not leave the headlight without a bulb for a long time. Dust, moisture, etc. entering the headlight may affect its performance.
  1. Disconnect the ground cable from the battery.
  2. Remove the headlight assembly. Refer to «REMOVAL»(ref-325323-S03837004962009071800000) , Headlight Assembly .
  3. Remove the back cover.
  4. Disconnect the harness connector.
  5. Remove the light bulb retaining spring, and remove the bulb.

Scheme 38

Scheme 38
Scheme 38

HALOGEN TYPE

  1. Visually check the bulb for blow out.
  2. Check the bulb specification.
  3. If NG, replace the bulb with a new part.

HID TYPE

CAUTIONDo not work with wet hands. Do not touch the harness, inner headlight, or any metallic portion of the headlight when the light is illuminated (when the lighting switch is turned on). When performing a lighting test, make sure that the headlight is mounted on the vehicle, and that the power supply is connected to the connector on the vehicle side.
  1. Check the bulb specification.
  2. Install a SUBARU genuine HID bulb to test whether it lights properly.
  3. If the headlight does not illuminate, replace the bulb with a new part.
  4. Check the HID ballast. Check the ballast in the following methods, and judge whether or not it can be reused. Perform the cold start (turning on the lights after the headlights have been off for 10 minutes or more) and hot start (turning on the headlights for 15 minutes or more --> turning off the lights for one minute --> turning on the lights again) several times and check if the headlights illuminate properly. Check the lighting condition immediately after the cold start until stable (approx. 5 min.), to make sure that an unstable condition (flicker etc.) does not occur. Attach two bulbs with equal amounts of operating hours to the right and left headlights, and light the headlights for approx. 30 minutes. Check to make sure that there is no difference in brightness between the right and left headlights.
  5. If NG, replace the ballast with a new part.

FOG LIGHT AIMING

Note. Before checking the fog light beam level, make sure the following

  1. The area around the fog light has not sustained any accident, damage or other type of deformation.
  2. Make sure that the vehicle is parked on a level surface.
  3. Make sure that the inflation pressure of tires are correct.
  4. Make sure that the vehicle fuel tank is full.
  1. Bounce the vehicle two to three times to normalize the suspension.
  2. Make certain that someone is seated in the driver's seat.
  3. Disengage the three clips, and then turn over the mud guard.
  4. Adjust the front fog light pattern by inserting a Phillips screwdriver to the adjusting hole.

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40
H mm (in) at 3 m (10 ft)
60 (2.38)

HEADLIGHT SPECIFICATION CHART

SPOT MAP LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. Refer to «SPECIFICATION»(ref-325323-S12568870952009071800000) , General Description .
  3. If NG, replace the bulb with a new part.

SPOT MAP LIGHT SWITCH

Measure the spot map light resistance.

Scheme 41

Scheme 41: SPOT MAP LIGHT SWITCH
Scheme 41: SPOT MAP LIGHT SWITCH
Switch positionTerminal No.Standard
OFF1 M ohms or more
ON1 and 21.5 ± 0.5 ohms
DOOR2 and 31.5 ± 0.5 ohms

TERMINAL SWITCH REFERENCE CHART

OVERHEAD CONSOLE ILLUMINATION LIGHT BULB

Note. Since LEDs (Light Emitting Diode) are used for the overhead console illumination light bulb, replace the overhead console assembly if the LED burns out.

Scheme 42

Scheme 42: REMOVAL
Scheme 42: REMOVAL

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44
  1. Disconnect the ground cable from the battery.
  2. Remove the lens (A) and mounting screws (B). Model without sunroof Model with sunroof
  3. Disconnect the harness connector and remove the room light.

ROOM LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. Refer to «SPECIFICATION»(ref-325323-S12568870952009071800000) , General Description .
  3. If NG, replace the bulb with a new part.

ROOM LIGHT SWITCH

Measure the resistance between room light switch terminals.

Scheme 45

Scheme 45: ROOM LIGHT SWITCH
Scheme 45: ROOM LIGHT SWITCH
Switch positionTerminal No.Standard
OFF1 Mohms or more
ON1 and 31.5 ± 0.5 ohms
DOOR2 and 3: Model without sunroof 1 and 2: Model with sunroof1.5 ± 0.5 ohms

TERMINAL SWITCH REFERENCE CHART

LUGGAGE ROOM LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. Refer to «SPECIFICATION»(ref-325323-S12568870952009071800000) , General Description .
  3. If NG, replace the bulb with a new part.

LUGGAGE ROOM LIGHT SWITCH

Measure the resistance between luggage room light switch terminals.

Scheme 46

Scheme 46: LUGGAGE ROOM LIGHT SWITCH
Scheme 46: LUGGAGE ROOM LIGHT SWITCH
Switch positionTerminal No.Standard
OFF1 M ohms or more
ON1 and 2Less than 1 ohms
DOOR2 and 3Less than 1 ohms

TERMINAL SWITCH REFERENCE CHART

More articles — Lighting System
