HEADLIGHT BEAM ADJUSTMENT
| CAUTION | Turn off the light before adjusting the headlight beam level. If it is necessary to inspect the beam level, do not keep the light on for two minutes or more. |
Note. Before checking the headlight beam level, be sure of the following: Check the area around the headlight for any scratches, damage or other types of deformation. Make sure that the vehicle is parked on a level surface. Make sure that the inflation pressure of tires are correct. Make sure that the vehicle fuel tank is full.
- Bounce the vehicle two to three times to normalize the suspension.
- Make certain that someone is seated in the driver's seat.
- Measure the distance between the low beam bulb centers, and the height of the bulb center.
- Turn the headlights on and then adjust the low beam pattern.
Note. First adjust the vertical beam level (A), then the horizontal beam level (B).
Scheme 4
Scheme 5
| W mm (in) | H mm (in) when C is 3 m (10 ft) |
|---|---|
| 1,210 (47.64) | 30 (1.19) |
HEADLIGHT SPECIFICATION CHART
| CAUTION | Check the bulb center mark on the inner side of the lens since the low beam bulb center will differ according to bulb shape. |
