Washer System & Wiper System: Adjustments Subaru Forester SG рестайлинг

ADJUSTMENT

Operate the wiper once. Align the wiper blade to ceramic print point mark (A) of front window panel.

Scheme 8

1. Disconnect the ground cable from battery.
2. Remove the cowl panel. REMOVAL Cowl Panel. >
3. Disconnect the connector of motor.
4. Loosen the bolts and nuts to remove the wiper link.
5. Loosen the bolts and nuts to remove the motor.

Scheme 9

Scheme 10

1. Install the wiper link to the vehicle, then connect the motor connector.
2. Connect the ground cable to the battery.
3. To confirm that the motor is at the auto stop position, connect the harness to the motor and turn the wiper switch ON/OFF once.
4. Disconnect the ground cable from battery.
5. Tighten the nut where rod (A) and link plate (B) is aligned in a straight line.
6. Install in the reverse order of removal.

Tightening torque

Refer to " COMPONENT " of "General Description". FRONT WIPER COMPONENT, General Description. >

Scheme 11

Scheme 12

Scheme 13

1. When the battery is connected to the terminal of connectors as shown in the figure, confirm that the motor operates at low speed.
2. When the battery is connected to the terminal of connectors as shown in the figure, confirm that the wiper motor operates at high speed.
3. Connect the battery to terminals of the connector, and remove the terminal connection with motor rotating at low speed, and stop the wiper motor in mid-operation.
4. Connect the battery and confirm that the motor stops at the automatic stop position after the motor operates at low speed again.

Scheme 14

Note. It is not possible to adjust the ejection position of the washer liquid because it is the scatter nozzle.

Scheme 15

1. Detach the wiper arm cover (A).
2. Loosen the nut to remove the wiper arm.

Scheme 16

1. Operate the rear wiper once.
2. Align the blade to center of the rear defogger heat wire (A).

Scheme 17

1. Disconnect the ground cable from battery.
2. Remove the rear wiper arm.
3. Remove the cap (A), nut (B), and spacer (C) from rear wiper shaft.
4. Remove the rear gate lower trim. REMOVAL Rear Gate Trim. >
5. Unclip the clip of harness and disconnect connector of wiper motor.
6. Loosen the bolts to remove the wiper motor assembly (A).

Scheme 18

1. Turn the wiper switch to OFF position.
2. When the vehicle stops, adjust the washer liquid ejection position as shown in the figure.

In ejection position: A: 35 mm (1.38 in) B: 72°
