Washer System & Wiper System: Removal & Installation Subaru Forester SG рестайлинг

INSTALLATION

Install in the reverse order of removal.

Scheme 25

1. Inspect the continuity between each connector terminal. TERMINALS REFERENCE Switch position Terminal No. Standard Front LO 7 and 17 Less than 1 ohms HI 8 and 17 Less than 1 ohms Washer ON 2 and 11 Less than 1 ohms Rear Washer ON 2 and 12 Less than 1 ohms OFF Between any two of following terminals: 2, 10, 12, 13 1 Mohms or more INT 2 and 13 Less than 1 ohms ON 2 and 10 Less than 1 ohms Washer ON 2 and 10 10 and 12 2 and 12 Less than 1 ohms If continuity is not as specified, replace the switch.
2. Intermittent operation inspection Inspect wiper switch separately

Scheme 26

1. Set the voltmeter between switch terminal No.7 (+) and No. 2 (-).
2. Connect the battery between switch terminal No. 17 (+) and No. 2 (-)
3. Turn the front wiper switch to INT.
4. Connect the battery (+) to switch terminal No. 16 for 5 seconds.
5. Connect battery (-) to switch terminal No. 16 and measure the voltage during intermittent operation. Terminals No. 7 - No. 2
6. Perform step 1) to 5) when intermittent control switch is in MIN or MAX. Intermittent stationary time: MIN: Approx. 2 sec. MAX: Approx. 16 sec.
7. If operation is not as specified, replace the switch.

REMOVAL

While pushing the locking clip (A) up, pull out the blade to the direction of the arrow and remove it from the wiper arm.

Scheme 27

1. Install in the reverse order of removal.
2. Confirm that the clip is locked securely.

Install in the reverse order of removal.

Tightening torque: 6.0 N.m (0.61 kgf-m, 4.4 ft-lb)

1. Open the front hood.
2. Remove the cap.
3. Loosen the nut to remove the arm.

Scheme 28

1. Install in the reverse order of removal.
2. Operate the wiper once.
3. Align the wiper blade to ceramic print point mark (A) of front window panel.

Scheme 29

Tightening torque

Refer to " COMPONENT " of "General Description". FRONT WIPER COMPONENT, General Description. >

1. Remove the washer hose from the washer nozzle.
2. Open the clips on the underside of the front hood with a thin screwdriver or other tool, and remove the washer nozzle.

Scheme 30

1. Install in the reverse order of removal.
2. Adjust the position of the washer liquid sprayer. ADJUSTMENT FRONT WASHER NOZZLE. >

1. Install in the reverse order of removal.
2. Operate the rear wiper once.
3. Align the blade to center of the rear defogger heat wire (A).

Scheme 31

Tightening torque

Refer to " COMPONENT " of "General Description". REAR WIPER COMPONENT, General Description. >

1. Install in the reverse order of removal.
2. Install the rear wiper cushion with the arrow mark facing up, as shown in the figure.

Scheme 32

Tightening torque

Refer to " COMPONENT " of "General Description". REAR WIPER COMPONENT, General Description. >

Scheme 33

Scheme 34

1. Connect the battery to the wiper motor connector and confirm that wiper motor operates.
2. Connect the battery to terminals of the connector, and remove the terminal connection with motor rotating, and stop the wiper motor in mid-operation.
3. Connect the battery and confirm that the motor stops at the automatic stop position after the motor operates at low speed again.

Scheme 35

1. Remove the rear gate upper trim. REMOVAL Rear Gate Trim. >
2. Remove the washer hose from the washer nozzle.
3. Push the anchor of the washer nozzle body with a flat tip screwdriver or equivalent, and remove the washer nozzle.

Scheme 36

1. Install in the reverse order of removal.
2. Adjust the position of the washer liquid sprayer. ADJUSTMENT REAR WASHER. >

1. Disconnect the ground cable from battery.
2. Remove the quarter lower trim RH. REMOVAL Rear Quarter Trim. >
3. Loosen the nut to remove the control unit.

Scheme 37

Install in the reverse order of removal.

Scheme 38

1. Disconnect the connector from the wiper control relay.
2. Connect the positive (+) probe from the battery to terminal 8 and the negative (-) probe to terminal 6. Connect the positive (+) probe from the voltage meter to terminal 3 and the negative (-) probe to the ground.
3. Measure the voltage when the wiper relay operates.

Scheme 39

If operation is not as specified, replace the switch.
