Lighting System: Diagnosis Subaru Forester SG рестайлинг

INSPECTION

Measure the combination switch resistance.

Scheme 4

1. Visually check the bulb for blow out.
2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
3. If NG, replace the bulb with a new one.

Scheme 5

1. Disconnect the ground cable from battery.
2. Remove the six clips holding the upper part of bumper face and turn over the upper part bumper face.
3. Turn the socket and remove the bulb.

1. Visually check the bulb for blow out.
2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
3. If NG, replace the bulb with a new one.

1. Visually check the bulb for blow out.
2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
3. If NG, replace the bulb with a new one.

Scheme 6

Scheme 7

1. Disconnect the ground cable from battery.
2. Remove the front bumper. REMOVAL Front Bumper. >
3. Remove the lower side bolt.
4. Remove the upper side clip, and then detach the fog light assembly.

1. Visually check the bulb for blow out.
2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
3. If NG, replace the bulb with a new one.

Scheme 8

Scheme 9

1. Disconnect the ground cable from battery.
2. Remove the two bolts, and then detach the rear combination light after disconnecting the connector.

1. Visually check the bulb for blow out.
2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
3. If NG, replace the bulb with a new one.

1. Visually check the bulb for blow out.
2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
3. If NG, replace the bulb with a new one.

Scheme 10

1. Remove the rear combination light assembly. REMOVAL REAR COMBINATION LIGHT ASSEMBLY. >
2. Turn the socket and remove the bulb.

1. Visually check the bulb for blow out.
2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
3. If NG, replace the bulb with a new one.

Scheme 11

1. Remove the license plate light mounting screw (A) and then remove the lens.
2. Remove the bulb.

1. Visually check the bulb for blow out.
2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
3. If NG, replace the bulb with a new one.

Scheme 12

1. Disconnect the ground cable from battery.
2. Remove the roof spoiler.
3. Unpeel the tape on the backside of the high-mounted stop light and remove the nuts, to remove the high-mounted stop light.

1. Visually check the bulb for blow out.
2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
3. If NG, replace the bulb with a new one.

1. Install the side turn signal light assembly and check that it blinks normally.
2. If it does not blink normally, replace the side turn signal light assembly with a new one.

Note. Since a LED (Light Emitting Diode) is used for the side turn signal light, replace the side turn signal light assembly if the LED does not turn on.

Scheme 13

Scheme 14

1. Disconnect the ground cable from battery.
2. Insert a flat tip screwdriver into the notch on the lens and remove it by prying.
3. Remove the spot map light mounting screw.
4. Disconnect the harness connectors and remove the spot map light.
