Glass - Window - Mirrors: Removal & Installation Subaru Forester SG рестайлинг

INSTALLATION

Install in the reverse order of removal.

Scheme 45

1. Check to ensure that the outer mirror moves properly when the battery voltage is applied to terminals. SWITCH POSITION TERMINAL REFERENCE Switch position Terminal No. OFF - UP 6 (+) and 3 (-) or 8 (-) DOWN 3 (+) or 8 (+) and 6 (-) LEFT 7(+) and 3(-) or 8(-) RIGHT 3 (+) or 8 (+) and 7 (-)
2. Replace the mirror if defective.

Scheme 46

1. Check to ensure that the outer mirror moves properly when the battery voltage is applied to terminals. SWITCH POSITION TERMINAL REFERENCE Switch position Terminal No. OFF - UP 7 (+) and 3 (-) or 9 (-) DOWN 3 (+) or 9 (+) and 7 (-) LEFT 8 (+) and 3 (-) or 9 (-) RIGHT 3 (+) or 9 (+) and 8 (-)
2. Replace the mirror if defective.

Scheme 47

1. Check to ensure that the outer mirror moves properly when the battery voltage is applied to terminals. SWITCH POSITION TERMINAL REFERENCE Switch position Terminal No. OFF - UP 1 (+) and 3 (-) DOWN 3 (+) and 1 (-) LEFT 2 (+) and 3 (-) RIGHT 3 (+) and 2 (-)
2. Replace the mirror if defective.

Scheme 48

1. Check to ensure that the outer mirror moves properly when the battery voltage is applied to terminals. SWITCH POSITION TERMINAL REFERENCE Switch position Terminal No. OFF - UP 2 (+) and 4 (-) DOWN 4 (+) and 2 (-) LEFT 3 (+) and 4 (-) RIGHT 4 (+) and 3 (-)
2. Replace the mirror if defective.

Scheme 49

1. Remove the outer mirror assembly. REMOVAL OUTER MIRROR ASSEMBLY. >
2. Warm the area around the mirror holder (1) with a hair drier until the edges of the mirror holder become soft (about 2 or 3 minutes with a 1,000 W drier.)
3. Use a flat-bladed screwdriver without sharp edges to lift the mirror out of the mirror holder (1). (Also, for model with mirror heater, disconnect the mirror heater connector from rear side of the mirror.)
4. When installing the mirror, warm the area around the mirror holder with a hair drier until the edges of the mirror holder become soft (about 2 or 3 minutes with a 1,000 W drier.)
5. For model with mirror heater, connect the mirror heater connector from rear side of the mirror.
6. Peel the backing paper on the new double-sided tape and affix the tape to the mirror for installation. NOTE: Unless the mirror holder is warmed sufficiently, the mirror holder edges may be damaged or the mirror cracked.

REMOVAL

Refer to Power Window Control Switch because the remote control mirror switch is unitized with the power window control switch. REMOVAL POWER WINDOW CONTROL SWITCH. >

Refer to Power Window Control Switch because the remote control mirror switch is unitized with the power window control switch. INSTALLATION POWER WINDOW CONTROL SWITCH. >

1. Install in the reverse order of removal. CAUTION: Make sure that glass holder (front), holder guide, and slider of the regulator are placed securely in sash.
2. Adjust the front door glass. ADJUSTMENT FRONT DOOR GLASS. > Tightening torque: Refer to " «COMPONENT»(ref-274200-S04408867982007121400000) " of "General Description". FRONT DOOR GLASS COMPONENT, General Description. >

1. Install in the reverse order of removal.
2. Adjust the front door glass. ADJUSTMENT FRONT DOOR GLASS. > Tightening torque: Refer to " «COMPONENT»(ref-274200-S04408867982007121400000) " of "General Description". FRONT DOOR GLASS COMPONENT, General Description. >

1. Install in the reverse order of removal. CAUTION: Make sure that glass holder (front) and holder (rear) are placed securely in sash.
2. Adjust the rear door glass. ADJUSTMENT REAR DOOR GLASS. > Tightening torque: Refer to " «COMPONENT»(ref-274200-S39362204882007121400000) " of "General Description". REAR DOOR GLASS COMPONENT, General Description. >

1. Install in the reverse order of removal.
2. Adjust the rear door glass. ADJUSTMENT REAR DOOR GLASS. > Tightening torque: Refer to " «COMPONENT»(ref-274200-S39362204882007121400000) " of "General Description". REAR DOOR GLASS COMPONENT, General Description. >

Note. Never reuse the spring. Prepare a new spring before removal.

Scheme 50

Scheme 51

1. Turn the mirror base 90° clockwise or counterclockwise to remove it.
2. Remove the spring from the mirror base. CAUTION: Be careful not to damage the mirror surface.
3. When the mirror base is damaged, use the piano wire or spatula to remove. CAUTION: Be careful not to damage the windshield glass.

1. When the mirror base is removed, clean the old adhesive, and align the windshield glass mark to install. Adhesive: REPAIR KIT IN MR (Part No. 65029FC000)
2. Make sure the mirror base is securely attached and then install the spring to it.
3. Install in the reverse order of removal.

1. Remove the rear gate garnish. REMOVAL Rear Gate Garnish. >
2. Disconnect the electrical connectors from rear defogger terminal.
3. Remove the glass in the same procedure as for windshield glass. REMOVAL WINDSHIELD GLASS. >

Note. The locating pin is adhered to the corner portion on the vehicle's indoor side of the glass. Use the piano wire to cut each pin.

Scheme 52

Scheme 53

Scheme 54

1. Install a new rubber strip (A) in position with the edge (B) of the rear gate glass.
2. Install the glass in the same procedure as for windshield glass.
3. About one hour after installation, inspect for leaks.
4. After completion of ail work, allow the vehicle to stand for about 24 hours. NOTE: When door is opened/closed after glass is bonded, always lower the door glass first, and then open/close it carefully. Move the vehicle slowly. For minimum drying time and vehicle standing time before driving after bonding, follow instructions or instruction manual from the adhesive manufacturer. When a vehicle is returned to the user, tell him or her that the vehicle should not be subjected to heavy impact for at least three days.
5. Connect the rear defogger terminals.
6. Install the rear gate garnish. INSTALLATION Rear Gate Garnish. >

Remove the glass in the same procedure as for windshield glass. REMOVAL WINDSHIELD GLASS. >

Scheme 55

Scheme 56

1. Cut off the nozzle tip as shown in the figure.
2. Install the glass in the same procedure as for windshield glass. INSTALLATION WINDSHIELD GLASS. >
3. After completion of all work, allow the vehicle to stand for about 24 hours. NOTE: When door is opened/closed after glass is bonded, always lower the door glass first, and then open/close it carefully. Move the vehicle slowly. For minimum drying time and vehicle standing time before driving after bonding, follow instructions or instruction manual from the adhesive manufacturer.
4. After curing of adhesive, pour the water on external surface of vehicle to check that there are no water leaks. NOTE: When a vehicle is returned to the user, tell him or her that the vehicle should not be subjected to heavy impact for at least three days.

REMOVAL Sunroof Lid. >

INSTALLATION Sunroof Lid. >
