Glass - Window - Mirrors: Diagnosis Subaru Forester SG рестайлинг

Windows 23 illustrations ~772 words

INSPECTION

SymptomRepair order
All power windows do not operate.Fuse (SBF-6) (F/B No. 18) Power window circuit breaker Power window relay Wiring harness
Particular window does not operate.Power window main switch Power window sub switch Power window motor Wiring harness
"Window Lock" does not operate.Power window main switch

SYMPTOM CHART

Scheme 22

Scheme 22: MAIN SWITCH
Scheme 22: MAIN SWITCH

Scheme 23

Scheme 23
Scheme 23
  1. Disconnect the ground cable from battery.
  2. Remove the screw cover by using a flat tip screwdriver.
  3. Loosen the screw to remove power window main switch.
  4. Disconnect the connector.

Scheme 24

Scheme 24: SUB-SWITCH
Scheme 24: SUB-SWITCH

Scheme 25

Scheme 25
Scheme 25
  1. Disconnect the ground cable from battery.
  2. Remove the screw securing the switch panel.
  3. Remove the switch panel.
  4. Disconnect the connector.
SymptomRepair order
All function does not operate.Fuse (F/B No. 4) (F/B No. 13) (F/B No. 17) (F/B No. 18) Mirror switch Wiring harness
One side of the mirror motor does not operate.Mirror switch Mirror motor Wiring harness
Mirror heater does not operate.Mirror switch Mirror heater Wiring harness

SYMPTOM CHART

Scheme 26

Scheme 26: Outer mirror with side turn signal light
Scheme 26: Outer mirror with side turn signal light

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Remove the mirror. REPLACEMENT OUTER MIRROR. >
  2. Press-in the upper side clips (A) from inside of outer mirror.
  3. Pull the scalp cap frontward of outer mirror, remove the upper side clips (A) and lower side hooks (B), and then remove the scalp cap.
  4. Insert the lower hooks (B) of scalp cap to the outer mirror and push the upper clips (A) in.
  5. Install the scalp cap securely. CAUTION: Do not remove the scalp cap forcibly. The lower hooks may be damaged.

Scheme 29

Scheme 29: Standard size outer mirror
Scheme 29: Standard size outer mirror

Scheme 30

Scheme 30
Scheme 30
  1. Put the mirror side down.
  2. Insert a thin screw driver, push the clip part of scalp cap, and then remove the scalp cap.
  3. Insert the claw at the lower side of scalp cap to the door mirror.
  4. Install the scalp cap securely.

Scheme 31

Scheme 31: REMOVAL
Scheme 31: REMOVAL

Scheme 32

Scheme 32
Scheme 32
  1. Remove the door trim. REMOVAL Front Door Trim. >
  2. Remove the mirror gusset cover.
  3. Disconnect the outer mirror connector.
  4. Remove the grommet, and loosen the screws to remove the outer mirror assembly.

Move the remote control mirror switch to each position and check continuity between terminals.

Scheme 33

Scheme 33: INSPECTION
Scheme 33: INSPECTION

Switch the change over switch to the right side

Switch positionTerminal No.Standard
OFF1 Mohms or more
UP8 and 3, 6 and 7Less than 1 ohms
DOWN8 and 6, 3 and 7Less than 1 ohms
LEFT8 and 2, 6 and 7Less than 1 ohms
RIGHT8 and 6, 2 and 7Less than 1 ohms

SWITCH POSITION TERMINAL REFERENCE

Switch the change over switch to the left side

Switch positionTerminal No.Standard
OFF1 Mohms or more
UP8 and 4, 6 and 7Less than 1 ohms
DOWN8 and 6, 4 and 7Less than 1 ohms
LEFT8 and 5, 6 and 7Less than 1 ohms
RIGHT8 and 6, 5 and 7Less than 1 ohms

SWITCH POSITION TERMINAL REFERENCE

If NG, replace the switch.

Scheme 34

Scheme 34: REMOVAL
Scheme 34: REMOVAL

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37
  1. Remove the front door trim. REMOVAL Front Door Trim. >
  2. Remove the front speaker. REMOVAL Front Speaker. >
  3. Remove the sealing cover. REMOVAL Front Sealing Cover. >
  4. Remove the outer mirror assembly. REMOVAL OUTER MIRROR ASSEMBLY. >
  5. Remove the front end of door weather strip and gusset.
  6. Remove the stabilizers.
  7. Remove the rear end of door weather strip and weather strip outer.
  8. Operate the power window switch to move glass to position shown in the figure, and then remove the three nuts from the service holes.
  9. Remove the door glass. CAUTION: Since the gear may be disengaged, do not turn regulator in the closing direction after removing glass. Avoid impact and damage to the glass.
  1. Make sure that the power window motor rotates properly when the battery voltage is applied to the terminals of motor connector.
  2. Change polarity of battery connection to terminals to ensure that the motor rotates in reverse direction.

Scheme 38

Scheme 38: REMOVAL
Scheme 38: REMOVAL

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41
  1. Remove the rear door trim. REMOVAL Rear Door Trim. >
  2. Remove the front speaker. REMOVAL Front Speaker. >
  3. Remove the sealing cover. REMOVAL Rear Sealing Cover. >
  4. Remove the stabilizers.
  5. Remove the door weather strip.
  6. Loosen two screws to remove the weather strip outer.
  7. Operate the power window switch to move the glass to the position as shown in the figure, and remove two nuts.
  8. Take out the door glass. CAUTION: Avoid impact and damage to the glass.
  1. Make sure that the power window motor rotates properly when the battery voltage is applied to the terminals of motor connector.
  2. Change polarity of battery connection to terminals to ensure that the motor rotates in reverse direction.

Check that the mirror is not damaged.

Check that the spring is not damaged.

SymptomRepair order
Rear window defogger does not operate.Fuse (M/B No. 1) (F/B No. 17) Rear defogger relay Rear defogger timer Defogger switch Rear defogger condenser Deffogger wire Wiring harness

SYMPTOM CHART

CAUTIONWhen wiping off the stain on glass with cloth, use a dry and soft cloth and move it in the direction of the heat wire extension to avoid damage to the heat wire.

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43
  1. Turn the ignition switch to ON.
  2. Turn the defogger switch to ON.
  3. Wrap the tips of tester probe with aluminum foil to avoid damage to heat wire.
  4. Measure the voltage at heat wire center (1) with DC voltmeter. Standard voltage: Approx. 6 V VOLTAGE CHART Voltage Criteria Approx. 6 V Normal Approx. 12 V or 0 V Open NOTE: If the measured value is 12 V, the circuit is open between heat wire center and positive (+) terminal of tester probe. If it is 0 V, the circuit is open between heat wire center and ground.
  5. Connect the tester probe of positive lead of voltmeter to positive terminal of heat wire and move tester probe of negative lead along the heat wire up to the negative terminal end. If voltage changes from zero to several volts during movement of tester probe, heat wire is open at the voltage change point.

Scheme 44

Scheme 44: REPAIR
Scheme 44: REPAIR
  1. Clean the broken portion with alcohol or white gasoline.
  2. Mask both side of wire with thin film.
  3. Apply the conductive silver composition (DU-PONT No. 4817) to the broken point.
  4. After repair, check the wire.
