Diagnostic Trouble Code (DTC) Detecting Criteria (H4DOTC): Other Subaru Forester SG рестайлинг

LIST

DIAGNOSTIC TROUBLE CODE CHART

ENABLE CONDITION

1. Crankshaft Timing Diagnosis ENABLE CONDITION CHART Secondary Parameters Enable Conditions Battery voltage > or = 10.9V Engine coolant temperature >60°C (140°F) Target timing advance = 0°CA Engine speed > or = 500 rpm AVCS Uncontrolled
2. Slow Response Diagnosis

ENABLE CONDITION CHART

GENERAL DRIVING CYCLE

1. Crankshaft Timing Diagnosis Perform the diagnosis continuously after starting engine and while AVCS is not operating.
2. Slow Response Diagnosis

Perform the diagnosis continuously after starting engine and while AVCS is operating.

MALFUNCTION INDICATOR LIGHT CLEAR CONDITION

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

FAIL SAFE

Make the oil flow control solenoid valve drive duty a predetermined value.

ENABLE CONDITION CHART

Perform the diagnosis continuously after 30 seconds or more have passed since the engine started.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Front oxygen sensor (A/F) sensor main learning compensation: Not allowed to calculate.
2. Correction when re-starting at high temperature: Normally minimum value 0.3 --> 0.
3. Purge control: Not allowed to purge.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
2. A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
3. Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
4. Purge control: Not allowed to purge.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
2. A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
3. Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
4. Purge control: Not allowed to purge.

ENABLE CONDITION CHART

Perform the diagnosis continuously after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Sub feedback control: Not allowed

ENABLE CONDITION CHART

Perform the diagnosis continuously after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Sub feedback control: Not allowed

ENABLE CONDITION CHART

Perform the diagnosis continuously after idling.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Intake manifold pressure sensor process: Estimate the pressure from engine load.
2. ISC feedback: Not allowed to calculate the amount of feedback.
3. Heavy fuel judgment: Not allowed to carry out the heavy judgment.
4. Fuel cut control: Not allowed to cut the over pressure charged fuel.

ENABLE CONDITION CHART

Perform the diagnosis continuously after idling.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Air flow meter: Engine load is normally calculated by manifold pressure and engine speed; however, calculated only by manifold pressure.
2. EVAP cone, learning (fuel): Not allowed to learn.
3. Knock compensation: Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value. When normal: Knock compensation value = Fixed at 0°CA. Failure: Knock compensation value does not equal to Fixed at 0°CA. (When knock: Max. 12°CA retard) Whole learning compensation coefficient update not allowed. Portional learning zone compensation value calculation not allowed.
4. ISC control: Open loop compensation is set to (1 g/s). Stop calculation of throttle sensor temperature compensation. (Hold the previous value.)
5. Purge control: Not allowed to purge.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Air flow meter: Engine load is normally calculated by manifold pressure and engine speed; however, calculated only by manifold pressure.
2. EVAP cone, learning (fuel): Not allowed to learn.
3. Knock compensation: Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value. When normal: Knock compensation value = Fixed at 0°CA. Failure: Knock compensation value * Fixed at 0°CA. (When knock: Max. 12°CA retard) Whole learning compensation coefficient update not allowed. Portional learning zone compensation value calculation not allowed.
4. ISC control: Open loop compensation is set to (1 g/s). Stop calculation of throttle sensor temperature compensation. (Hold the previous value.)
5. Purge control: Not allowed to purge

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Air flow meter: Engine load is normally calculated by manifold pressure and engine speed; however, calculated only by manifold pressure.
2. EVAP cone, learning (fuel): Not allowed to learn.
3. Knock compensation: Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value. When normal: Knock compensation value = Fixed at 0°CA. Failure: Knock compensation value does not equal to Fixed at 0°CA. (When knock: Max. 12°CA retard) Whole learning compensation coefficient update not allowed. Portional learning zone compensation value calculation not allowed. ISC control: Open loop compensation is set to (1 g/s). Stop calculation of throttle sensor temperature compensation. (Hold the previous value.) Purge control: Not allowed to purge.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Intake manifold pressure sensor process: Estimate the pressure from engine load.
2. ISC feedback: Not allowed to calculate the amount of feedback.
3. Heavy fuel judgment: Not allowed to carry out the heavy judgment.
4. Fuel cut control: Not allowed to cut the over pressure charged fuel.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Intake manifold pressure sensor process: Estimate the pressure from engine load.
2. ISC feedback: Not allowed to calculate the amount of feedback.
3. Heavy fuel judgment: Not allowed to carry out the heavy judgment.
4. Fuel cut control: Not allowed to cut the over pressure charged fuel.

ENABLE CONDITION CHART

Perform the diagnosis when the vehicle speed condition is completed after idling from starting the cooled engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Intake air temperature sensor process: Intake air temperature is fixed at 20°C (68°F).

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Intake air temperature sensor process: Intake air temperature is fixed at 20°C (68°F).

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Intake air temperature sensor process: Intake air temperature is fixed at 20°C (68°F).

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Engine coolant temperature sensor process: Engine coolant temperature is fixed at 70°C (158°F).
2. ISC Feedback: Calculate target engine RPM as engine coolant temperature 70°C (158°F).
3. ISC learning: Not allowed to learn.
4. Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
5. Air conditioner control: Not allowed to turn the air conditioner to ON.
6. Radiator fan control: Both main and sub fan are in High driving.
7. High water temperature expansion compensation coefficient: Normally, mass expands with high water temperature and other conditions, but this ignores water temperature conditions and expands when other conditions are established.
8. AVCS Control: Oil flow control solenoid valve drive output duty = 0 %.
9. Tumble generator valve control: Open the tumble generator valve.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Engine coolant temperature sensor process: Engine coolant temperature is fixed at 70°C (158°F).
2. ISC Feedback: Calculate target engine RPM as engine coolant temperature 70°C (158°F).
3. ISC learning: Not allowed to learn.
4. Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
5. Air conditioner control: Not allowed to turn the air conditioner to ON.
6. Radiator fan control: Both main and sub fan are in High driving.
7. High water temperature expansion compensation coefficient: Normally, mass expands with high water temperature and other conditions, but this ignores water temperature conditions and expands when other conditions are established.
8. AVCS Control: Oil flow control solenoid valve drive output duty = 0 %.
9. Tumble generator valve control: Open the tumble generator valve.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

Perform the diagnosis only once after engine starting.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Engine coolant temperature sensor process: Engine coolant temperature is fixed at 70°C (158°F).
2. ISC Feedback: Calculate target engine RPM as engine coolant temperature 70°C (158°F).
3. ISC learning: Not allowed to learn.
4. Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
5. Air conditioner control: Not allowed to turn the air conditioner to ON.
6. Radiator fan control: Both main and sub fan are in High driving.
7. High water temperature expansion compensation coefficient: Normally, mass expands with high water temperature and other conditions, but this ignores water temperature conditions and expands when other conditions are established.
8. AVCS Control: Oil flow control solenoid valve drive output duty = 0 %.
9. Tumble generator valve control: Open the tumble generator valve.

ENABLE CONDITION CHART

Perform the diagnosis only once after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
2. A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
3. Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
4. Purge control: Not allowed to purge.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
2. A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
3. Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
4. Purge control: Not allowed to purge.

ENABLE CONDITION CHART

Perform diagnosis only once, at a constant speed of 10 to 120 km/h (6.21 to 74.6 MPH) in 120 seconds or more after warming up the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Front oxygen sensor (A/F) sensor main learning compensation: Not allowed to calculate.
2. Correction when re-starting at high temperature: Normally minimum value 0.3 --> 0.
3. Purge control: Not allowed to purge.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
2. A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
3. Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
4. Purge control: Not allowed to purge.

Used only for malfunction judgement

ENABLE CONDITION CHART

Used only for normality judgement

ENABLE CONDITION CHART

After starting the engine, perform the diagnosis in series while the engine is in a constant operating condition.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Sub feedback control: Not allowed.

1. Rich --> lean diagnosis response

ENABLE CONDITION CHART

Perform the diagnosis only once when deceleration fuel cut occurs after rapid acceleration. (Pay attention to the oxygen sensor voltage for the timing of the deceleration.)

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Sub feedback control: Not allowed.

1. Lean --> rich response diagnosis

ENABLE CONDITION CHART

Perform the diagnosis only once when deceleration fuel cut occurs after rapid acceleration. (Pay attention to the oxygen sensor voltage for the timing of the deceleration.)

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Sub feedback control: Not allowed.

ENABLE CONDITION CHART

Perform the diagnosis only once after engine warm-up.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Map 5

DIAGNOSIS PROCEDURE

Perform the diagnosis continuously at idling or at a constant speed after warming up the engine.

1. When similar driving conditions are repeated 3 times and the result is OK.
2. When "Clear Memory" is performed

Rich side malfunction

1. Purge control solenoid valve control: Not allowed to purge.
2. Heavy fuel judgment control: Not allowed to carry out the heavy judgment.

ENABLE CONDITION CHART

Map 5

DIAGNOSIS PROCEDURE

Perform the diagnosis continuously at idling or at a constant speed after warming up the engine.

1. When similar driving conditions are repeated 3 times and the result is OK.
2. When "Clear Memory" is performed

Rich side malfunction

1. Purge control solenoid valve control: Not allowed to purge.
2. Heavy fuel judgment control: Not allowed to carry out the heavy judgment.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

ENABLE CONDITION CHART

Always perform diagnosis continuously after 20 seconds or more have passed since the engine started.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

OFF setting may be needed depending on the NG portion.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Perform the diagnosis continuously after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Perform the diagnosis continuously after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Map3

MT model

Vehicle Speed < 64.4 km/h (40 MPH)

VEHICLE SPEED CHART

Vehicle Speed > or = 64.4 km/h (40 MPH)

VEHICLE SPEED CHART

AT model

VEHICLE SPEED CHART

1. If conditions are met, detect misfire from idling to high rotation.
2. Perform the diagnosis continuously.

Identifying ECM, Diagnosis Circuit And Crankshaft Position Sensor. Scheme 213

When a misfire occurs, the engine RPM will decreased and the crankshaft position speed will change. Calculate the interval difference value (diagnostic value) from crankshaft position speed by the following formula, and judge whether a misfire is occurring or not comparing the calculated result with judgment value. Counting the number of misfires, if the misfire ratio is higher during 1000 rev. or 200 rev., Judge corresponding cylinders as NG.

DIAGNOSIS PROCEDURE

As shown in the following figure, pick a cylinder as the standard and name it omg 0. And the former crankshaft position speed is named omg 1, the second former crankshaft position speed is named omg 2, the third is named omg 3, etc.

Identifying Crankshaft Position Speed Chart. Scheme 214

180° Interval Difference Method

DIAGNOSIS PROCEDURE

Judgment Value Graph - 180° Interval Difference Method. Scheme 215

360° Interval Difference Method

DIAGNOSIS PROCEDURE

Judgment Value Graph. Scheme 216

720° Interval Difference Method

DIAGNOSIS PROCEDURE

Judgment Value Graph - 720° Interval Difference Method. Scheme 217

FTP 1.5 times misfire (Misfire occurrence level which influences exhaust gas)

Judgment Value (Judge that malfunction occurs when the misfire ratio is high in 1000 engine revs.)

JUDGMENT VALUE CHART

Time Needed for Diagnosis: 1000 engine revs.

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

Catalyst damage misfire (Misfire occurrence level damaging catalyst)

Judgment Value (Judge that malfunction occurs when the misfire ratio is high in 200 engine revs. (400 ignitions))

JUDGMENT VALUE CHART

Map 1 Fault criteria threshold for misfire which would result in catalyst damage

Map 1 Fault criteria threshold for misfire which would result in catalyst damage. Scheme 218

These figures indicate the misfire rate (%) in 400 ignitions; for example, 22.5 (%) means 400 (ignition) x 22.5 (%) = 90 (ignition) misfires. This value or more is judged as a misfire.

Time Needed for Diagnosis: 200 engine revs.

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

1. When a similar driving cycle is established 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Knock compensation

1. Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value.
2. When normal: Knock compensation value = Fixed at 0°CA.
3. Failure: Knock compensation value = -5°CA. (5°CA retard)
4. Whole learning compensation coefficient update not allowed.
5. Portional learning zone compensation value calculation not allowed.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Knock compensation

1. Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value.
2. When normal: Knock compensation value = Fixed at 0°CA.
3. Failure: Knock compensation value = -5°CA. (5°CA retard)
4. Whole learning compensation coefficient update not allowed.
5. Portional learning zone compensation value calculation not allowed.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Perform the diagnosis continuously under 3000 rpm engine speed.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment from abnormality judgment, and then make the whole learning incomplete.
2. Ignition timing partial learning compensation: Enter the initial value (0°CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of the partial learning zone when making a normality judgment --> abnormality judgment.
3. AVCS control

1. Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced.
2. =--> ISC feedback compensation: Do not perform the AVCS actual timing advance compensation.
3. Make the OCV driving Duty to be the given value (9.36%).

ENABLE CONDITION CHART

Perform diagnosis while secondary pump is operating

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Map 2

Add the following value every 512 milliseconds.

Catalyst warm-up counters 9000

AMOUNT OF INTAKE AIR

Catalyst warm-up counter> 9000

AMOUNT OF INTAKE AIR

After warm-up, perform the diagnosis only once at a constant 75 km/h (47 MPH).

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

0.04-inch Diagnosis

ENABLE CONDITION CHART

0.02-inch Diagnosis

ENABLE CONDITION CHART

Map

FUEL LEVEL CHART

0.04-inch Diagnosis

1. Perform the diagnosis only once in 856 seconds or more after starting the engine, at a constant speed of 32 km/h (19.9 MPH) or more.
2. Pay attention to the fuel temperature and fuel level.

0.02-inch Diagnosis

1. Perform the diagnosis after 770 seconds or more after starting the engine, at a constant engine RPM of 68 km/h (42 MPH) or higher, to judge as NG or OK.
2. If judgement cannot be made, repeat the diagnosis.
3. Be careful of the remaining fuel level.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Pressure control solenoid valve control: Open the pressure control solenoid valve.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Pressure control solenoid valve control: Open the pressure control solenoid valve.

ENABLE CONDITION CHART

1. Perform the diagnosis continuously after 60 seconds or more have passed since the engine started.
2. Be sure to check the fuel level and fuel temperature.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Purge control solenoid valve control: Not allowed to purge fixed mode.

ENABLE CONDITION (USED WITH HIGH SIDE NORMAL/ABNORMALITY JUDGMENT ONLY)

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Purge control solenoid valve control: Not allowed to purge fixed mode.

ENABLE CONDITION CHART

Perform the diagnosis continually when purging.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Purge control solenoid valve control: Not allowed to purge fixed mode.

ENABLE CONDITION CHART

Always perform the diagnosis after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

1. Always perform the diagnosis continuously at idle speed.
2. Pay attention to the fuel level.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

Diagnostic enable condition is established if the radiator fan changes from OFF --> ON when all of the conditions below are met.

When one of the conditions below is not met, the diagnostic enable condition is not established.

ENABLE CONDITION CHART

Always perform the diagnosis continuously at idle speed.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Perform diagnosis continually during a deceleration fuel cut, at less than 4000 rpm.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Accelerator sensor signal process: Not allowed fully closed point learning. (Hold previous value)
2. Vehicle speed sensor signal process: Vehicle speed = 10 km/h (6.21 MPH)
3. Fuel cut control: Not allowed vehicle speed 0 km/h (0 MPH) fuel cut. Normally the high vehicle speed fuel cut performs on "and" of vehicle speed condition and engine speed, but perform the fuel cut only on engine speed condition (4,800 rpm or more).
4. ISC control: Open loop compensation is set to (1 g/s). Not allowed ISC feedback volume calculation.
5. Air conditioner control: Not allowed air conditioner cut at accelerating.
6. Radiator fan control: Both main and sub fan are in High driving.
7. Gear ratio judgment: Control as fixed in sixth gear
8. Tumble generator valve control: Open the tumble generator valve.

ENABLE CONDITION CHART

Perform diagnosis continually during a deceleration fuel cut, at less than 4000 rpm

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Accelerator sensor signal process: Not allowed fully closed point learning. (Hold previous value)
2. Vehicle speed sensor signal process: Vehicle speed = 10 km/h (6.21 MPH)
3. Fuel cut control: Not allowed vehicle speed 0 km/h (0 MPH) fuel cut. Normally the high vehicle speed fuel cut performs on "and" of vehicle speed condition and engine speed, but perform the fuel cut only on engine speed condition (4,800 rpm or more).
4. ISC control: Open loop compensation is set to (1 g/s). Not allowed ISC feedback volume calculation.
5. Air conditioner control: Not allowed air conditioner cut at accelerating.
6. Radiator fan control: Both main and sub fan are in High driving.
7. Gear ratio judgment: Control as fixed in sixth gear
8. Tumble generator valve control: Open the tumble generator valve.

ENABLE CONDITION CHART

After 10 seconds from engine starting perform diagnosis continuously at idling after warming up.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Judgment of heavy fuel: Not allowed to make the judgment of heavy fuel.
2. Knock compensation

1. Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value
2. When normal: Knock compensation value = Fixed at 0°CA
3. Failure: Knock compensation value = Fixed at 0°CA (When knock: Max. 12°CA retard)
4. Whole learning compensation coefficient update not allowed
5. Portional learning zone compensation value calculation not allowed

ENABLE CONDITION CHART

After 10 seconds from engine starting, perform diagnosis continuously at idling after warming up.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Judgment of heavy fuel: Not allowed to make the judgment of heavy fuel.
2. Knock compensation

1. Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value
2. When normal: Knock compensation value = Fixed at O°CA
3. Failure: Knock compensation value & Fixed at 0°CA (When knock: Max. 12°CA retard)
4. Whole learning compensation coefficient update not allowed
5. Portional learning zone compensation value calculation not allowed

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

When starting the engine.

Perform the diagnosis only after starting the engine.

ENABLE CONDITION CHART

Perform the diagnosis continuously if the vehicle speed at less than 4 km/h (2.49 MPH).

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Fuel shut-off: Shut-off fuel for only #1 and #2 cylinder, or for all cylinder in accordance with vehicle speed, engine speed, throttle position.

ENABLE CONDITION CHART

Perform the diagnosis continuously after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Target throttle opening angle operation required by Accelerator pedal position sensor: Torque guard for AT protection is normally obtained through CAN communication and the predefined value is 408 Nm.

ENABLE CONDITION CHART

Diagnosis with the initial routine.

Perform the diagnosis as soon as the ignition switch is turned to ON.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

1. (4): Always perform the diagnosis continuously.
2. (5): Always perform the diagnosis continuously when idling.
3. (6): Perform the diagnosis when the brake pedal is depressed.
4. (7): Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

Always perform the diagnosis continuously when the electric throttle control is operating.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Perform the diagnosis continuously in 2 seconds after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Perform the diagnosis continuously in 2 seconds after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Cruise control: Not allowed to command cruise control.

ENABLE CONDITION CHART

Perform the diagnosis continuously in 2 seconds after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Perform the diagnosis continuously in 2 seconds after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Perform diagnosis continuously at a constant speed of 20 km/h (12 MPH) or more, from 60 seconds after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Front oxygen sensor (A/F) sensor main learning compensation: Not allowed to calculate.
2. Correction when re-starting at high temperature: Normally minimum value 0.3 --> 0.
3. Purge control: Not allowed to purge

ENABLE CONDITION CHART

Perform diagnosis continuously at a constant vehicle speed of 20 km/h (12 MPH) or more, from 60 seconds after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Front oxygen sensor (A/F) sensor main learning compensation: Not allowed to calculate.
2. Correction when re-starting at high temperature: Normally minimum value 0.3 --> 0.
3. Purge control: Not allowed to purge

ENABLE CONDITION CHART

1. Ignition switch ON --> OFF
2. Ignition switch OFF --> ON (Only after clearing memory)

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Throttle opening is fixed to 6°

ENABLE CONDITION CHART

Always perform the diagnosis after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Perform diagnosis continuously after engine start with the secondary air pump stopped and with a high air flow amount.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis after starting the engine.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Pressure control solenoid valve control: Open the pressure control solenoid valve.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generated valve opening

1. For tumble generated valve all closing points learning, not allowed to update to closing side.
2. For tumble generated valve all opening points learning, not allowed to update to opening side. Tumble generated valve control
3. Output the open signal.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generated valve opening

1. For tumble generated valve all closing points learning, not allowed to update to closing side.
2. For tumble generated valve all opening points learning, not allowed to update to opening side. Tumble generated valve control
3. Output the open signal.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generated valve opening

1. For tumble generated valve all closing points learning, not allowed to update to closing side.
2. For tumble generated valve all opening points learning, not allowed to update to opening side. Tumble generated valve control
3. Output the close signal.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generated valve opening

1. For tumble generated valve all closing points learning, not allowed to update to closing side.
2. For tumble generated valve all opening points learning, not allowed to update to opening side. Tumble generated valve control
3. Output the close signal.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generator valve control: Not allowed to move tumble generated valve.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generator valve control: Not allowed to move tumble generated valve.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generator valve control: Not allowed to move tumble generated valve.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generator valve control: Not allowed to move tumble generated valve.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generated valve opening

1. For tumble generated valve all closing points learning, not allowed to update to closing side.
2. For tumble generated valve all opening points learning, not allowed to update to opening side.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generated valve opening

1. For tumble generated valve all closing points learning, not allowed to update to closing side.
2. For tumble generated valve all opening points learning, not allowed to update to opening side.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generated valve opening

1. For tumble generated valve all closing points learning, not allowed to update to closing side.
2. For tumble generated valve all opening points learning, not allowed to update to opening side.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Tumble generated valve opening

1. For tumble generated valve all closing points learning, not allowed to update to closing side.
2. For tumble generated valve all opening points learning, not allowed to update to opening side.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment --> abnormality judgment, and then make the whole learning incomplete.
2. Ignition timing partial learning compensation: Enter the initial value (0°CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of partial learning zone when making a normality judgment --> abnormality judgment.
3. AVCS control: Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced. --> ISC feedback compensation: Do not perform the AVCS actual timing advance compensation. Make the oil flow control solenoid valve drive duty a predetermined value (9.36%).

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment --> abnormality judgment, and then make the whole learning incomplete.
2. Ignition timing partial learning compensation: Enter the initial value (0°CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of partial learning zone when making a normality judgment --> abnormality judgment.
3. AVCS control

1. Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced.
2. > ISC feedback compensation: Do not perform the AVCS actual timing advance compensation.
3. Make the oil flow control solenoid valve drive duty a predetermined value (9.36%).

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment -->abnormality judgment, and then make the whole learning incomplete.
2. Ignition timing partial learning compensation: Enter the initial value (0°CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of partial learning zone when making a normality judgment --> abnormality judgment.
3. AVCS control

1. Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced.
2. => ISC feedback compensation: Do not perform the AVCS actual timing advance compensation.
3. Make the oil flow control solenoid valve drive duty a predetermined value (9.36%).

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

1. Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment --> abnormality judgment, and then make the whole learning incomplete.
2. Ignition timing partial learning compensation: Enter the initial value (0°CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of partial learning zone when making a normality judgment --> abnormality judgment.
3. AVCS control

1. Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced.
2. ISC feedback compensation: Do not perform the AVCS actual timing advance compensation.
3. Make the oil flow control solenoid valve drive duty a predetermined value (9.36%).

ENABLE CONDITION CHART

Perform the diagnosis continuously at a constant speed of approx. 75 km/h (47 MPH) or higher.

1. When similar driving conditions are repeated 3 times and the result is OK.
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Perform the diagnosis continuously at a constant speed of approx. 75 km/h (47 MPH) or higher.

1. When similar driving conditions are repeated 3 times and the result is OK.
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

1. When ignition switch ON --> OFF
2. Ignition switch OFF --> ON (Only after clearing memory)

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

Perform the diagnosis at full closed point learning.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to the electronic control throttle motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

1. Single malfunction: Control with normal sensor
2. Simultaneous failure: Throttle opening is fixed to 6°.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

1. Single malfunction: Control with normal sensor
2. Simultaneous failure: Throttle opening is fixed to 6°.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

1. Single malfunction: Control with normal sensor
2. Simultaneous failure: Throttle opening is fixed to 6°.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

1. Single malfunction: Control with normal sensor
2. Simultaneous failure: Throttle opening is fixed to 6°.

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed (Only engine stop)

Stop the continuity to ETC motor. (Throttle opening is fixed to 6°.)

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Throttle opening is fixed to 6°.

ENABLE CONDITION CHART

Perform the diagnosis once before engine start with the ignition switch ON.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Atmospheric pressure sensor process: Fix the atmospheric pressure to 101.3 kPa (760 mmHg, 29.9 inHg).

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Atmospheric pressure sensor process: Fix the atmospheric pressure to 101.3 kPa (760 mmHg, 29.9 inHg).

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

Atmospheric pressure sensor process: Fix the atmospheric pressure to 101.3 kPa (760 mmHg, 29.9 inHg).

ENABLE CONDITION CHART

Perform the diagnosis with the ignition switch ON.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None

ENABLE CONDITION CHART

Always perform the diagnosis continuously.

1. When the OK driving cycle is completed 3 times in a row
2. When "Clear Memory" is performed

None
