Ignition (H4DOTC): Removal & Installation Subaru Forester SG рестайлинг

Ignition System 7 illustrations ~144 words

REMOVAL

CAUTIONAll spark plugs installed on an engine must be of the same heat range.

Spark plug: NGK: ILFR6B

Scheme 29

Scheme 29: RH SIDE
Scheme 29: RH SIDE

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31
  1. Disconnect the ground cable from battery.
  2. Remove the collector cover.
  3. Remove the air cleaner lower case. REMOVAL Air Cleaner Case. >
  4. Disconnect the connector from ignition coil.
  5. Remove the ignition coil.
  6. Remove the spark plug with a spark plug socket.

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34
  1. Disconnect the ground cable from battery and remove the battery and battery carrier.
  2. Remove the collector cover.
  3. Remove the secondary air pump. REMOVAL Secondary Air Pump. >
  4. Disconnect the connector from ignition coil.
  5. Remove the ignition coil.
  6. Remove the spark plug with a spark plug socket.

Scheme 35

Scheme 35
Scheme 35

Direct ignition type has been adopted. Refer to "Removing Spark Plugs" for removal procedures.

REMOVAL SPARK PLUG. >

INSTALLATION

Install in the reverse order of removal.

Tightening torque: 16 N.m (1.6 kgf-m, 11.7 ft-lb)
