INSTALLATION
Install in the reverse order of removal.
REMOVAL
- Disconnect the ground cable from battery.
- Remove the air intake duct (when right side headlight is removed). REMOVAL Air Cleaner Case. >
- Remove the front bumper. REMOVAL Front Bumper. >
- Remove the four bolts and disconnect the connectors, and then detach the headlight assembly.
Scheme 15
Install in the reverse order of removal.
Install in the reverse order of removal.
| CAUTION | Install the rubber cap so that the letters TOP face upward. The drain hole should be facing downward. |
Install in the reverse order of removal.
Install in the reverse order of removal.
- Disconnect the ground cable from battery.
- Remove the three clips holding the mud guard.
- Turn over the mud guard, turn the socket and then remove the bulb.
Install in the reverse order of removal.
Install in the reverse order of removal.
Scheme 16
- Disconnect the ground cable from battery.
- Disengage the three clips, and then turn over the mud guard.
- Remove the spring retainer then detach the fog light bulb.
Install in the reverse order of removal.
Install in the reverse order of removal.
Scheme 17
- Remove the rear combination light assembly. REMOVAL REAR COMBINATION LIGHT ASSEMBLY. >
- Turn the socket and remove the bulb.
Install in the reverse order of removal.
- Remove the rear combination light assembly. REMOVAL REAR COMBINATION LIGHT ASSEMBLY. >
- Turn the socket and remove the bulb.
Scheme 18
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
- Disconnect the ground cable from battery.
- Remove the scalp cap. REPLACEMENT Scalp Cap. >
- Disconnect the harness connector, remove the 3 mounting screws and then remove the side turn signal light assembly.
Scheme 19
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
