CAUTION

  1. Before removing or installing parts, always disconnect the battery ground cable from battery. When replacing the radio, control unit, and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
  2. Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
  3. Adjust parts to the given specifications.
  4. Connect the connectors and hoses securely during reassembly.
  5. After reassembly, make sure functional parts operate smoothly.
WARNINGThe air bag system wiring harness is routed near electrical parts and switches. All airbag system wiring harnesses and connectors are colored yellow. Do not use the electrical test equipment on these circuits. Be careful not to damage the air bag system wiring harness when servicing electrical parts and switches.

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance and voltage.

GENERAL TOOL DESCRIPTION

HEADLIGHT

HEADLIGHTS in SYSTEM WIRING DIAGRAM . >

CLEARANCE LIGHT AND ILLUMINATION LIGHT

SYSTEM WIRING DIAGRAMS . >

HEADLIGHT SWITCH

INSPECTION COMBINATION SWITCH (LIGHT). >

HEADLIGHT RELAY

Measure the headlight relay resistance between terminals when connecting terminal No. 4 to the battery positive terminal and terminal No. 3 to the battery ground terminal.

Scheme 20

Scheme 20: HEADLIGHT RELAY
Scheme 20: HEADLIGHT RELAY
CurrentTerminal No.Standard
Yes1 and 2Less than 1 ohms
No1 Mohms or more

TERMINALS REFERENCE

TAIL AND ILLUMINATION RELAY

Measure the resistance between tail and illumination relay terminals when connecting terminal No. 4 to the battery positive terminal and terminal No. 3 to the battery ground terminal.

CurrentTerminal No.Standard
Yes1 and 2Less than 1 ohms
No1 Mohms or more

TERMINALS REFERENCE

FRONT FOG LIGHT SWITCH

Measure the front fog light switch resistance.

Scheme 21

Scheme 21: FRONT FOG LIGHT SWITCH
Scheme 21: FRONT FOG LIGHT SWITCH
Switch positionTerminal No.Standard
OFF3 and 51 Mohms or more
ONLess than 1 ohms

TERMINALS REFERENCE

FRONT FOG LIGHT RELAY

Connect terminal No. 4 to battery positive terminal and terminal No. 3 to battery ground terminal, and measure the front fog light relay resistance between terminals.

CurrentTerminal No.Standard
Yes1 and 2Less than 1 ohms
No1 Mohms or more

TERMINALS REFERENCE

TURN SIGNAL LIGHT AND HAZARD LIGHT

SYSTEM WIRING DIAGRAMS . >

TURN SIGNAL SWITCH

INSPECTION COMBINATION SWITCH (LIGHT). >

HAZARD SWITCH

Measure the hazard switch resistance.

Scheme 22

Scheme 22: HAZARD SWITCH
Scheme 22: HAZARD SWITCH
Switch positionTerminal No.Standard
OFF6 and 7Less than 1 ohms
ON1,3 and 4Less than 1 ohms
7 and 8Less than 1 ohms

TERMINALS REFERENCE

TURN SIGNAL AND HAZARD MODULE

Connect the battery and the turn signal light bulb to the module, as shown in the figure. The module is properly functioning if it blinks when power is supplied to the circuit.

Scheme 23

Scheme 23: TURN SIGNAL AND HAZARD MODULE
Scheme 23: TURN SIGNAL AND HAZARD MODULE

BACK-UP LIGHT SWITCH (MT MODEL)

Measure the back-up light switch resistance.

Scheme 24

Scheme 24: BACK-UP LIGHT SWITCH (MT MODEL)
Scheme 24: BACK-UP LIGHT SWITCH (MT MODEL)
Switch positionTerminal No.Standard
When shift lever is set in reverse positionNon-turbo model: land 2 Turbo model: 2 and 4Less than 1 ohms
Other positions1 Mohms or more

TERMINALS REFERENCE

INHIBITOR SWITCH (AT MODEL)

Measure the inhibitor switch resistance.

Scheme 25

Scheme 25: INHIBITOR SWITCH (AT MODEL)
Scheme 25: INHIBITOR SWITCH (AT MODEL)
Switch positionTerminal No.Standard
When the shift lever is in "R" range1 and 2Less than 1 ohms
Other positions1 Mohms or more

TERMINALS REFERENCE

STOPLIGHT

SYSTEM WIRING DIAGRAMS . >

STOP LIGHT SWITCH

Measure the stop light switch resistance.

Scheme 26

Scheme 26: STOP LIGHT SWITCH
Scheme 26: STOP LIGHT SWITCH
Switch positionTerminal No.Standard
When brake pedal is depressed1 and 2: Model without cruise control 2 and 3: Model with cruise controlLess than 1 ohms
When brake pedal is released1 Mohms or more

TERMINALS REFERENCE

ROOM LIGHT

SYSTEM WIRING DIAGRAMS . >

DOOR SWITCH

Measure the door switch resistance.

Scheme 27

Scheme 27: DOOR SWITCH
Scheme 27: DOOR SWITCH
Switch positionTerminal No.Standard
When door is opened1 and 3Less than 1 ohms
When door is closed1 Mohms or more

TERMINALS REFERENCE

REAR GATE LATCH SWITCH

Measure the rear gate latch switch resistance.

Switch positionTerminal No.Standard
When rear gate is opened1 and 2Less than 1 ohms
When rear gate is closed1 Mohms or more

TERMINALS REFERENCE

Scheme 28

Scheme 28: REMOVAL
Scheme 28: REMOVAL
  1. Disconnect the ground cable from battery.
  2. Remove the instrument panel lower cover. REMOVAL Instrument Panel Assembly. >
  3. Remove the screws which secure upper column cover to lower column cover.
  4. Disconnect the connector from combination switch.
  5. Remove the screws which secure the switch, then remove the switch.

Scheme 29

Scheme 29
Scheme 29

LIGHTING SWITCH

Switch positionTerminal No.Standard
OFF1 Mohms or more
Tail14 and 16Less than 1 ohms
Head13, 14 and 16Less than 1 ohms

TERMINALS REFERENCE

DIMMER AND PASSING SWITCH

Switch positionTerminal No.Standard
Passing7, 8 and 16Less than 1 ohms
Low beam16 and 17Less than 1 ohms
High beam7 and 16Less than 1 ohms

TERMINALS REFERENCE

Switch positionTerminal No.Standard
Left1 and 2Less than 1 ohms
Neutral1 Mohms or more
Right2 and 3Less than 1 ohms

TERMINALS REFERENCE

PARKING SWITCH

Switch positionTerminal No.Standard
OFF2 and 4Less than 1 ohms
ON1 and 4Less than 1 ohms

TERMINALS REFERENCE

LENS

CAUTIONDo not touch the bulb glass portion. Do not touch inside the lens (extension portion) or reflector portion. Replace the packing with a new one.

Scheme 30

Scheme 30
Scheme 30
  1. Remove the headlight assembly. REMOVAL HEADLIGHT ASSEMBLY. >
  2. Disconnect the headlight bulb connector.
  3. Remove the back cover and then remove the bulb.
  4. Use a drier to warm up the area around the seal through the bulb installation hole. CAUTION: Avoid heating one specific point of the seal portion and heating the headlight assembly to 120°C(248°F) or more.
  5. Remove the hook, and then take the lens off the headlight assembly.
  6. Remove the packing (A) from seal groove.
CAUTIONCompletely remove the packing not to leave any residue behind.

Scheme 31

Scheme 31
Scheme 31

HID HEADLIGHT BALLAST

CAUTIONDo not operate with wet hands. As the lightening circuit on the HID headlights uses high voltage, be sure to confirm that the power supply is turned off before working on it. Do not leave the headlight without a ballast for a long time. Dust, moisture, etc. entering the headlight may affect its performance.

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Disconnect the ground cable from battery.
  2. Remove the headlight assembly. REMOVAL HEADLIGHT ASSEMBLY. >
  3. Remove the back cover.
  4. Disconnect the harness connector.
  5. Loosen the screws to remove ballast.
  6. Disconnect the connector from the headlight ballast. CAUTION: Be careful because the notch is easily bent.
  7. Turn the beam adjustment screw so that the beam is facing upward, then create space for the socket portion to pass through the inside of the lamp. CAUTION: The reflector should not interfere with the extension case.
  8. Place the socket portion toward the front side of the reflector bracket.
  9. Turn the beam adjustment screw so that the beam is facing downward, then create space for the socket portion to pass under the reflector bracket. CAUTION: The reflector should not interfere with the extension case.
  10. Remove the socket from headlight from below the housing. CAUTION: The socket should not get sandwiched between the reflector and the lamp housing.

Scheme 36

Scheme 36: LENS
Scheme 36: LENS

Scheme 37

Scheme 37
Scheme 37
  1. Cut the tip of packing (A) at an angle of 45°.
  2. With the cut end facing upward, insert packing (A) into the seal groove. CAUTION: If the packing protrudes, slowly take it off the groove. Do not stretch the packing. If the packing is stretched, seal fails.
  3. After making a round of the seal, cut its tip at an angle of 45°, with its length 10 mm (0.39 in) longer than the circumference of seal so that the tip overlaps the other. Then, press it onto the seal, using a screwdriver.
  4. Match the positions of the lens and headlight assembly, and then insert the lens into the headlight assembly.
  5. Engage the hooks.
  6. Put the seal portion of headlight assembly into the water and check that water does not enter inside the headlight.
CAUTIONBe sure that water does not enter inside the headlight through the bulb socket and ventilation hole.

HEADLIGHT AIMING

CAUTIONTurn off the light before adjusting the headlight aiming. If it is necessary to inspect the aiming, do not turn on the lamp for more than two minutes.

Before checking the headlight beam level, be sure of the following

Note. The area around the headlight does not have any scratch, damage or other type of deformation. Vehicle is parked on a level surface. The inflation pressure of tires is correct. Vehicle's fuel tank is full. Bounce the vehicle several times to normalize the suspension. Make certain that someone is seated in the driver's seat.

  1. Cover the headlight that is not being adjusted with a cloth.
  2. Turn the headlights on and then adjust the low beam while displaying the beam on the screen.

Note. Adjust the vertical beam level (A) first, then horizontal beam level (B) using a screwdriver.

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
W mm (in)H mm (in)H mm (in) at 3 m (10 ft)
1,235(48.6)7601 (29.9)21 (0.83)

AIMING ADJUSTMENT DIMENSION CHART

HALOGEN TYPE

CAUTIONBecause the halogen bulb operates at a high temperature, dirt and oil on the bulb surface reduces the bulb's service life. Hold the flange portion when replacing the bulb and never touch the glass portion. Dust, moisture, etc. entering the headlight may mal-affect its performance. Therefore, never leave the headlight without a bulb for extended periods of time.

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41
  1. Disconnect the ground cable from battery.
  2. Remove the air intake duct (when right side headlight is removed).
  3. Disconnect the harness connector.
  4. Remove the rubber cap.
  5. Remove the light bulb retaining spring to remove the bulb.

HID TYPE

CAUTIONDo not operate with wet hands. As the lightening circuit uses high voltage, be sure to confirm that the power supply is turned off before working on it. When replacing the bulb, hold the flange portion and never touch the glass portion. Do not leave the headlight without a bulb for a long time. Dust, moisture, etc. entering the headlight may affect its performance.

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43
  1. Disconnect the ground cable from battery.
  2. Remove the headlight assembly. HID TYPE REMOVAL, HEADLIGHT BULB. >
  3. Remove the back cover.
  4. Disconnect the harness connector.
  5. Remove the light bulb retaining spring to remove the bulb.
  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
  3. If NG, replace the bulb with a new one.
CAUTIONDo not operate with wet hands. Do not touch the harness, inner headlight, or any metallic portion of the headlight when the light is illuminated (when the lighting switch is turned on). When performing a lighting test, make sure that the headlight is mounted on the vehicle, and the power supply is connected to the connector on the vehicle's side.
  1. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
  2. Install a specified HID bulb for headlight lighting test.
  3. If the headlight does not illuminate, replace the bulb with a new one.
  4. Check the HID ballast. Check the ballast in the following methods and judge if it can be reused or not. Perform the cold start (turning on the lights after the headlights is gone off for more than 10 minutes) and hot start (turning on the headlights for more than 15 minutes --> turning off the lights for one minute --> turning on the lights again) several times and check if the headlights are lit surely. Check the lighting condition from immediately after the cold start until the stable condition (approx. 5 min.), to make sure that the unstable condition (flicker etc.) does not occur. Attach the two bulbs having been used for the same period of time to the right and left headlights and keep the headlights for approx. 30 minutes lit. Check the difference of brightness between right and left headlights.
  5. If NG, replace the ballast with a new one.

Scheme 44

Scheme 44: REMOVAL
Scheme 44: REMOVAL

Scheme 45

Scheme 45
Scheme 45
  1. Disconnect the ground cable from battery.
  2. Remove the three clips holding the mud guard.
  3. Turn over the mud guard and turn the socket and then remove the bulb.

STANDARD TYPE

  1. Disconnect the ground cable from battery.
  2. Push a screwdriver into the end part and remove the cap (a) by prying it.
  3. Remove the screws (b) and then detach the cover (c).
  4. Remove the screws (d) and then detach the high-mounted stop light while disconnecting the connector.

Scheme 46

Scheme 46
Scheme 46

SPOT MAP LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
  3. If NG, replace the bulb with a new one.

SPOT MAP LIGHT SWITCH

Measure the spot map light switch resistance.

Switch positionTerminal No.Standard
OFF1 Mohms or more
ON1 and 218±5.4ohms

TERMINALS REFERENCE

Scheme 47

Scheme 47: REMOVAL
Scheme 47: REMOVAL
  1. Disconnect the ground cable from battery.
  2. Remove the lens (A) and mounting screws (B).
  3. Disconnect the harness connector and remove the room light.

ROOM LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
  3. If NG, replace the bulb with a new one.

ROOM LIGHT SWITCH

Measure the room light switch resistance.

Scheme 48

Scheme 48: ROOM LIGHT SWITCH
Scheme 48: ROOM LIGHT SWITCH
Switch positionTerminal No.Standard
OFF1 Mohms or more
ON1 and 31.5±0.5ohms
DOOR1 and 21.5±0.5ohms

TERMINALS REFERENCE

Scheme 49

Scheme 49: REMOVAL
Scheme 49: REMOVAL
  1. Disconnect the ground cable from battery.
  2. Remove the lens (A) and mounting screws (B) of the cargo room light.
  3. Disconnect the harness connectors and remove the luggage room light.

LUGGAGE ROOM LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. SPECIFICATION GENERAL DESCRIPTION. >
  3. If NG, replace the bulb with a new one.

LUGGAGE ROOM LIGHT SWITCH

Measure the luggage room light switch resistance.

Scheme 50

Scheme 50: LUGGAGE ROOM LIGHT SWITCH
Scheme 50: LUGGAGE ROOM LIGHT SWITCH
Switch positionTerminal No.Standard
OFF1 Mohms or more
ON1 and 31.5±0.5ohms
DOOR1 and 21.5±0.5ohms

TERMINALS REFERENCE
