CAUTION

1. Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the radio, control unit, and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
2. Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
3. Adjust parts to the given specifications.
4. Connect the connectors and hoses securely during reassembly.
5. After reassembly, make sure functional parts operate smoothly.

GENERAL TOOL

GENERAL TOOL DESCRIPTION

RADIO BODY

RADIO in SYSTEM WIRING DIAGRAM article. . >

FRONT ACCESSORY POWER SUPPLY SOCKET

SYSTEM WIRING DIAGRAMS in SYSTEM WIRING DIAGRAMS article. . >

REAR ACCESSORY POWER SUPPLY SOCKET

SYSTEM WIRING DIAGRAMS in SYSTEM WIRING DIAGRAMS article. . >

Scheme 14

Scheme 15

Scheme 16

1. Disconnect the ground cable from battery.
2. Remove the front cover. REMOVAL Console Box. >
3. Affix the thick protective tape (A) to the instrument panel pad to protect the surface. NOTE: Affix the protective tape so that it covers the vertical wall in the back of the gap between the panel center and the pad. (Scheme 14): Identifying Protective Tape
4. Remove the screws. (Scheme 15): Locating Screws
5. While pulling on the lower portion of the center console panel, insert a flat tip screwdriver into the portion (A) to remove the claw. CAUTION: Be very careful because it is possible to damage the instrument panel if the flat tip screwdriver is inserted into any other area than specified. (Scheme 16): Identifying Claw
6. Disconnect the connector.
7. Remove the fitting screws, and slightly pull the radio out from the center console.
8. Disconnect the harness connectors and antenna feeder cord.

FRONT

1. Disconnect the ground cable from battery.
2. Remove the console cover. REMOVAL Console Box. >
3. Disconnect the harness connector, and remove the accessory power supply socket.

Locating Harness Connectors. Scheme 17

REAR

1. Disconnect the ground cable from battery.
2. Remove the rear quarter lower trim. REMOVAL Rear Quarter Trim. >
3. Disconnect the harness connector, and remove the accessory power supply socket.

Locating Accessory Power Supply Socket. Scheme 18
