INSTALLATION
Install in the reverse order of removal.
Scheme 8
- Disconnect the ground cable from battery.
- Remove the gusset cover.
- Remove the tweeter mounting screws. (Scheme 8): Locating Tweeter Mounting Screws
- Disconnect the harness connector and remove the tweeter.
Install in the reverse order of removal.
Scheme 9
- Disconnect the ground cable from battery.
- Remove the front door trim. REMOVAL Front Door Trim. >
- Remove the front speaker mounting screws. (Scheme 9): Locating Front Speaker Mounting Screws
- Disconnect the harness connector and remove the front speaker.
Install in the reverse order of removal.
Scheme 10
- Disconnect the ground cable from battery.
- Remove the rear door trim. REMOVAL Rear Door Trim. >
- Remove the rear speaker mounting screws. (Scheme 10): Locating Rear Speaker Mounting Screws
- Disconnect the harness connector and remove the rear speaker.
Install in the reverse order of removal.
Scheme 11
- Disconnect the ground cable from battery.
- Remove the rear seat belt, rear seat, rear quarter upper, rear quarter lower, insulator and luggage floor mat.
- Remove the woofer trim.
- Remove the woofer mounting screws and clip (A). (Scheme 11): Locating Woofer Mounting Screws And Clip
- Disconnect the harness connector and detach the woofers.
Install in the reverse order of removal.
REMOVAL
- Disconnect the ground cable from battery.
- Remove the rear quarter upper trim. REMOVAL Rear Quarter Trim. >
- Disconnect the harness connectors and terminals.
- Remove the mounting screw and detach the antenna amplifier.
Locating Antenna Amplifier Mounting Screw. Scheme 12
Install in the reverse order of removal.
- Disconnect the ground cable from battery.
- Remove the front cover. REMOVAL Console Box. >
- Disconnect the harness connectors and remove the front accessory power supply socket.
Removing Front Accessory Power Supply Socket. Scheme 13
Install in the reverse order of removal.
Install in the reverse order of removal.
