COMPUTERIZED ENGINE CONTROLS
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See appropriate COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
For removal and installation procedures (Scheme 1)
Scheme 1
For removal and installation procedures (Scheme 2) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 2
For removal and installation procedures (Scheme 3) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 3
For removal and installation procedures (Scheme 4) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 4
If oxygen sensor is difficult to remove, use rust penetrant to avoid damaging exhaust threads. Disconnect wiring from sensor. Unscrew sensor from exhaust manifold.
If old sensor is reused, apply anti-seize compound to sensor threads. Keep anti-seize compound away from sensor body. New sensors are coated with anti-seize compound. DO NOT remove anti-seize compound from sensor. Tighten to 13-18 ft. lbs. (18-24 N.m).
For removal and installation procedures (Scheme 5) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 5
For removal and installation procedures (Scheme 6) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 6
For removal and installation procedures (Scheme 7) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 7
Disconnect wire harness connector. Remove Throttle Position (TP) sensor-to-throttle body screws. Remove TP sensor. To install, reverse removal procedure. Adjust to specification. See THROTTLE POSITION (TP) SENSOR in ON VEHICLE ADJUSTMENTS article. Tighten screws to specification. See TORQUE SPECIFICATIONS .
For removal and installation procedures (Scheme 8) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 8
For removal and installation procedures (Scheme 9)
Scheme 9
For removal and installation procedures (Scheme 10) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 10
For removal and installation procedures (Scheme 11)
Scheme 11
FUEL SYSTEM
| WARNING | Always relieve fuel pressure before disconnecting any fuel injection-related component. DO NOT allow fuel to contact engine or electrical components. |
FUEL SYSTEM PRESSURE RELEASE
Unplug fuel pump relay harness connector, located at left kick panel. Start and run engine until it stalls. After engine stalls, operate starter for about 5 seconds. Turn ignition off.
For removal and installation procedures (Scheme 12), (Scheme 13) and (Scheme 14). Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 12
Scheme 13
Scheme 14
For removal and installation procedures (Scheme 15)- (Scheme 19). Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
FUEL FILTER
For removal and installation procedures (Scheme 20) For location, see FUEL FILTER LOCATION table. Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 20
| Application | Location |
|---|---|
| All Models | Mounted To Left Front Strut Tower, By Brake Master Cylinder |
FUEL FILTER LOCATION
FUEL INJECTORS
| CAUTION | Do not pry on injectors with a screwdriver, or pinch injector pin with pliers during removal. |
For removal and installation procedures (Scheme 21)- (Scheme 25). Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
For removal and installation procedures (Scheme 26)and (Scheme 27). Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 26
Scheme 27
For removal and installation procedures (Scheme 28)- (Scheme 30). Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 28
Scheme 29
Scheme 30
For removal and installation procedures (Scheme 31) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 31
For removal and installation procedures (Scheme 32) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 32
For removal and installation procedures (Scheme 33) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 33
For removal and installation procedures (Scheme 34) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 34
Note. When replacing fuel temperature sensor, fuel level sensor must also be replaced.
Fuel temperature sensor is built into fuel pump assembly. See FUEL PUMP .
For removal and installation procedures (Scheme 35) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 35
For removal and installation procedures (Scheme 36) Tighten fasteners to specification. See TORQUE SPECIFICATIONS.
Scheme 36
For removal and installation procedures (Scheme 37)
Scheme 37
For removal and installation procedures (Scheme 38)
