INSTALLATION
Install in the reverse order of removal.
Install in the reverse order of removal.
REMOVAL
| CAUTION | Because the halogen bulb operates at a high temperature, dirt and oil on the bulb surface reduces the bulb's service life. Hold the flange portion when replacing the bulb. Never touch the glass portion. Do not leave the headlight without a bulb for a long time. Dust, moisture, etc. entering the headlight may affect its performance. |
Scheme 24
Scheme 25
- Disconnect the ground cable from battery.
- Remove the air intake duct (when right side headlight is removed).
- Disconnect the harness connector.
- Remove the rubber cap.
- Remove the light bulb retaining spring to remove the bulb.
Install in the reverse order of removal.
| CAUTION | Attach the rubber cap with letters TOP on the top so the drain hole will be on the lower side. |
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
Scheme 26
Scheme 27
- Remove the front fog light assembly. Refer to «REMOVAL»(ref-200804-S10531809872005102300000) , Front Fog Light Assembly.
- Remove the back cover.
- Remove the spring retainer, and then detach the fog light bulb.
Install in the reverse order of removal.
Install in the reverse order of removal.
Scheme 28
- Remove the rear combination light assembly. Refer to «REMOVAL»(ref-200804-S37849039032005102300000) , Rear Combination Light Assembly.
- Turn the socket and remove the bulb.
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
Install in the reverse order of removal.
