PRECAUTIONS
- Before removing and installing parts, always disconnect the battery ground cable. When replacing radio, control module, and other parts provided with memory functions, record memory contents before disconnecting the battery ground cable. Otherwise, the memory will be erased.
- Reassemble in reverse order of disassembly, unless otherwise indicated.
- Adjust parts to the given specifications.
- Connect the connectors and hoses securely during reassembly.
Scheme 29
- After reassembly, make sure functional parts operate smoothly.
| WARNING | Airbag system wiring harness is routed near electrical parts and switches. All airbag system wiring harnesses and connectors are yellow. Do not use electric test equipment on these circuits. Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches. |
HEADLIGHT
Refer to HEADLIGHTS .
CLEARANCE LIGHT AND ILLUMINATION LIGHT
Refer to EXTERIOR LIGHTS .
HEADLIGHT SWITCH
Refer to INSPECTION , Combination Switch (Light).
HEADLIGHT RELAY
Measure the headlight relay resistance between terminals when connecting terminal No. 4 to battery positive terminal and terminal No. 3 to battery ground terminal.
Scheme 30
Scheme 31
TAIL AND ILLUMINATION RELAY
Measure the tail and illumination relay resistance between terminals when connecting terminal No. 4 to battery positive terminal and terminal No. 3 to battery ground terminal.
Scheme 32
Scheme 33
FRONT FOG LIGHT
Refer to INTERIOR LIGHTS .
FRONT FOG LIGHT SWITCH
Measure the resistance of front fog light switch.
Scheme 34
Scheme 35
FRONT FOG LIGHT RELAY
Measure the front fog light relay resistance between terminals when connecting terminal No. 4 to battery positive terminal and terminal No. 3 to battery ground terminal.
Scheme 36
Scheme 37
TURN SIGNAL LIGHT AND HAZARD LIGHT
Refer to EXTERIOR LIGHTS .
TURN SIGNAL SWITCH
Refer to INSPECTION , Combination Switch (Light).
HAZARD SWITCH
Measure the hazard switch resistance.
Scheme 38
Scheme 39
TURN SIGNAL AND HAZARD MODULE
Connect the battery and turn signal light bulb to the module, as shown in the figure. The module is properly functioning if it blinks when power is supplied to the circuit.
Scheme 40
BACK-UP LIGHT
Refer to EXTERIOR LIGHTS .
BACK-UP LIGHT SWITCH (M/T)
Measure the back-up light switch resistance.
Scheme 41
Scheme 42
INHIBITOR SWITCH (A/T)
Measure the inhibitor switch resistance.
Scheme 43
Scheme 44
STOP LIGHT
Refer to EXTERIOR LIGHTS .
STOP LIGHT SWITCH
Measure the stop light switch resistance.
Scheme 45
Scheme 46
INTERIOR LIGHT
Refer to INTERIOR LIGHTS .
DOOR SWITCH
Measure the door switch resistance.
Scheme 47
Scheme 48
REAR GATE LATCH SWITCH
Measure the rear gate latch switch resistance.
Scheme 49
Scheme 50
Scheme 51
- Disconnect the ground cable from battery.
- Remove the instrument panel lower cover. Refer to «REMOVAL»(ref-200811-S29558660072005102300000) , Instrument Panel Assembly.
- Remove the screws which secure upper column cover to lower column cover.
- Disconnect the connector from combination switch.
- Remove the screws which secure switch, and then remove the switch.
HEADLIGHT AIMING
Note. As this headlight is the "VISUAL AIMING TYPE", it is possible to adjust aiming only in the vertical direction. It cannot be adjusted in the horizontal direction.
| CAUTION | Turn off the light before adjusting headlight aiming. If the light is necessary to check aiming, do not turn on for more than two minutes. |
Note. Before checking the headlight aiming, be sure of the following: The area around the headlight has not sustained any accident, damage or other type of deformation. Vehicle is parked on level ground. The inflation pressure of tires is correct. Vehicle's gas tank is fully charged. Bounce the vehicle several times to normalize the suspension. Make certain that someone is seated in the driver's seat.
- Place a cloth over the headlight that does not require aiming adjustment.
- Turn the headlight on and then adjust the low beam pattern to the following positions on the screen.
| CAUTION | Do not perform lateral headlight aiming adjustment. |
Note. Adjust the headlight aiming by turning the adjusting screw (A).
Scheme 52
Scheme 53
Scheme 54
SPOT LIGHT BULB
- Visually check the bulb for blow out.
- Check the bulb specification. Refer to «SPECIFICATIONS»(ref-200804-S34740492822005102300000) , General Description.
- If NG, replace the bulb with a new one.
SPOT LIGHT SWITCH
Measure the spot light switch resistance.
Scheme 55
Scheme 56
- Disconnect the ground cable from battery.
- Remove the lens (A) and room light mounting screws (B).
- Disconnect the harness connectors and remove the light.
ROOM LIGHT BULB
- Visually check the bulb for blow out.
- Check the bulb specification. Refer to «SPECIFICATIONS»(ref-200804-S34740492822005102300000) , General Description.
- If NG, replace the bulb with a new one.
ROOM LIGHT SWITCH
Measure the room light switch resistance.
Scheme 57
Scheme 58
Scheme 59
- Disconnect the ground cable from battery.
- Remove the lens (A) and luggage room light mounting screws (B).
- Disconnect the harness connectors and remove the luggage room light.
LUGGAGE ROOM LIGHT BULB
- Visually check the bulb for blow out.
- Check the bulb specification. Refer to «SPECIFICATIONS»(ref-200804-S34740492822005102300000) , General Description.
- If NG, replace the bulb with a new one.
LUGGAGE ROOM LIGHT SWITCH
Measure the luggage room light switch resistance.
