Removal & Installation
Remove door trim panel. Remove window glass from regulator assembly. Remove front and rear sash/guides. (Scheme 5) Remove regulator assembly mounting bolts. Remove window regulator assembly. To install, reverse remove procedure. Lubricate regulator pivot points.
Scheme 5
Scheme 5: Removal & Installation
Power Window System Wiring Diagram (Forester). Scheme 6
Scheme 6: Power Window System Wiring Diagram (Forester)
Power Window System Wiring Diagram (Impreza - Coupe). Scheme 7
Scheme 7: Power Window System Wiring Diagram (Impreza - Coupe)
Power Window System Wiring Diagram (Impreza - Sedan & Wagon). Scheme 8
Scheme 8: Power Window System Wiring Diagram (Impreza - Sedan & Wagon)
Power Window System Wiring Diagram (Legacy & Outback). Scheme 9
Scheme 9: Power Window System Wiring Diagram (Legacy & Outback)
