Removal & Installation
Remove washer tank attaching bolts. Pull washer tank far enough to disconnect wiring harness connector and washer hose. Remove washer tank. To install, reverse removal procedure.
- Detach weatherstrip and cowl net. Apply silicone oil or soapy water to both sides of cowl net to facilitate removal. Disconnect electrical connector. Remove motor mounting bolts. (Scheme 13)
- Remove nut securing motor link on back side of motor and remove motor. Remove nuts securing left sleeve unit. Separate left and right wiper links at center joint. (Scheme 14)
- Remove nuts securing right sleeve unit. Remove wiper link from service hole in front panel. To install, reverse removal procedure.
Scheme 13
Scheme 14
- Open rear liftgate. Remove screws, clips and retainers from left rear quarter trim panel. Remove screws and clips from left of rear edge. Disconnect washer hose.
- While pulling rear quarter panel trim, remove attaching bolts. Pull washer tank out far enough to disconnect wiring harness connector and washer hose (from joint). Remove washer tank. To install, reverse removal procedure.
- Remove cap and special nut from rear liftgate glass. Remove rear liftgate inside trim. Unfasten clips securing harness.
- Disconnect wiper motor harness connector. Separate washer hoses at joint. Remove attaching screws. Remove wiper motor assembly. To install, reverse removal procedure.
Remove right inside wheelwell trim cover that houses right rear speaker. Disconnect relay harness connector. Remove screws securing relay. Remove relay. To install, reverse removal procedure.
- Remove steering wheel using steering wheel puller. Remove lower steering column cover. Remove bracket cover. Disconnect harness connectors.
- Unfasten hold-down band. Remove combination switch from steering column. Remove slip ring from combination switch. Remove wiper/washer assembly from combination switch. To install, reverse removal procedure.
