Power Control System: Removal & Installation Subaru BRZ ZC

Body Electrical 3 illustrations ~163 words

Installation

  1. Install the battery current sensor assembly. Install the battery current sensor assembly in place. Tighten the nut. Standard value: T=6.0N.m {61kgf.cm} {4.4 ft.lbf} Connect the engine wire to the battery current sensor assembly with the nut. Standard value: T=7.5N.m {77kgf.cm} {5.5 ft.lbf} Connect the connector.

Scheme 20

Scheme 20: Unit Inspection

Scheme 21

Scheme 21
  1. Inspect the battery current sensor assembly. Resistance check (Battery current sensor assembly). Measure the resistance between the terminals. RESISTANCE Inspection terminals Tester positive - Tester negative Inspection conditions Standard value 1(VIN) - 3(GND) Always 3 - 10 kohms 1(VIN) - 4(VOUT) Always 0.5 kohms or less 3(GND) - 4(VOUT) Always 3 - 10 kohms Resistance check (Battery thermometer sensor). Measure the resistance between the terminals. RESISTANCE Inspection terminals Inspection conditions Standard value 2(TEMP) - 3(GND) 20 - 30°C {68 - 86°F} 1.5 - 2.6 kohms NOTE: The standard value expresses the temperature of the sensor surroundings, rather than the temperature of the temperature sensor unit.

Scheme 22

Scheme 22: Exploded View
