Precautions

Note. Reset memory operation is not completed just by disconnecting the battery cable.

1. Precautions for removal and installation procedures Since the automatic transmission consists of parts with a very precise finish, careful inspection is required before assembling these parts. Even a small scratch may cause liquid leakage or affect the performance. Instructions in this chapter are organized so that the work for only 1 component group is performed at a time. This is to avoid confusion which can occur when parts having similar appearance but for different SUB-ASSY exist in the same workbench at the same time. Inspect and repair the component group from the converter housing side. Try to complete the inspection, repair, or assembly work before proceeding to the next component group. If any defect is found in a specific component group during assembly, immediately check and repair the group. When a component group cannot be assembled due to the parts order, be sure to store all parts of the group in another container while another component group is being disassembled, checked, and assembled. The auto fluid (ATF) WS is recommended. Wash all of the removed parts and blow through all of the liquid passages and holes with compressed air. Dry all parts with compressed air. Never dry the parts using rugs and cloths in the work area. When using compressed air, do not point the air outlet toward you to prevent auto fluid and detergent from being blown to your face by mistake. Use only the recommended automatic transmission fluid or appropriate detergent for cleaning. After washing, arrange the parts in the correct order for efficient inspection, repair, and assembly. When removing the valve body, be sure to keep each valve with the corresponding spring. Soak new discs (for replacement) of the brake and clutch in ATF for at least 15 minutes before the assembly. Before the assembly, apply ATF to all of the oil seal rings, clutch discs, clutch plates, rotating parts, and sliding surfaces. Replace all gaskets and rubber O-rings with new parts. Do not apply adhesive cement to gaskets and similar parts. Check that the both ends of the snap ring do not overlap the notch and the snap ring is installed in the groove correctly. When replacing a worn bushing, be sure to replace the SUB-ASSY including the bushing. Check for wear and damage of the thrust bearing and race. Replace them as required. Observe the following precautions when handling FIPG material. Completely remove the old sealant (FIPG) material from the gasket surface using a razor or gasket scraper. Carefully clean all the components and remove materials that are coming off. Clean the both surfaces of the seal with appropriate detergent. The parts must be assembled within 10 minutes after sealant (FIPG) is applied. If it is impossible, remove the sealant (FIPG) material and apply it again.

Definitions Of Terms

Scheme 15

Scheme 16

1. Check of shift lock operation Shift the select lever to the P position. Check that the select lever cannot be shifted to ranges other than P position when it is operated. Check that the select lever can be shifted to ranges other than P position with IG ON and the brake pedal depressed.
2. Check of shift lock release button operation Remove the button cover. Use a driver or other tool to check that the select lever can be shifted to ranges other than P position when it is operated with the shift lock release button pressed.
3. Time lag check CAUTION: Always perform the inspection after the engine check and adjustment. Perform the inspection at an oil temperature (60 to 90°C {140 to 194°F}) in normal driving temperature. Perform the inspection with the A/C OFF. Apply the parking brake and set the wheel stoppers. Start the engine. Shift from N position to D or R position with idling while depressing the brake pedal, and measure the time until a small shock is felt. Standard value: N-->D position 1.2 seconds or less N-->R position 1.5 seconds or less CAUTION: Make measurements 3 times and take the average value. Allow 1 minute interval when performing consecutive measurements.
4. Stall speed check CAUTION: Always perform the inspection after the engine check and adjustment. Perform the inspection at an oil temperature (60 to 90°C {140 to 194°F}) in normal driving temperature. Perform the inspection with the A/C OFF. Do not perform the operation continuously for 5 seconds or more. (Working time for the sequence from the accelerator full close, full open, stall speed reading, to the accelerator full close) Ignoring this instruction causes engine oil and ATF deterioration which has adverse effect on the clutch and brake. Perform in a place with high μ(friction coefficient) such as on asphalt to prevent the tires from spinning. After performing the stall test, be sure to cool down the engine for at least 1 minute with the select lever set in P or N position, and at an idle speed of 1200 rpm or less. If the stall speed is higher than the specified range, finish the stall test in as short a time as possible, in order to prevent the automatic transmission from being damaged. Perform the stall test in normal mode. Firmly apply the parking brake and set the wheel stoppers. Start the engine. Firmly depress the parking brake with left foot, shift to D position, and quickly read the maximum engine speed when the accelerator pedal is fully depressed with right foot. STANDARD VALUE Stall speed [r/min] 2350±250
5. Line pressure check CAUTION: Wash the equipment and hoses with appropriate detergent before and after measurement. Always perform the inspection after the engine check and adjustment. Perform the inspection at an oil temperature (60 to 90°C {140 to 194°F}) in normal driving temperature. Perform the inspection with the A/C OFF. Do not perform the inspection continuously for 5 seconds or more at stall. (Working time for the sequence from the accelerator full close, full open, stall speed reading, to the accelerator full close) Ignoring this instruction causes engine oil and ATF deterioration which has adverse effect on the clutch and brake. After performing the stall test, be sure to cool down the engine for at least 1 minute with the select lever set in P or N position, and at an idle speed of 1200 rpm or less. If the stall speed is higher than the specified range, finish the stall test in as short a time as possible, in order to prevent the automatic transmission from being damaged. Perform the stall test in normal mode. Remove the under cover front AL. Remove the under cover COMPL T/M. Remove the exhaust pipe ASSY FR. Attach the SST on the transmission. SST 18681AA040, 498897700, 498575400 CAUTION: Use 18681AA040 with genuine O-ring (17006AA000) attached. Route the hose so that it does not contact the exhaust pipe. Captions in illustration Install the exhaust pipe ASSY FR. Firmly apply the parking brake and set the wheel stoppers. Start the engine. Firmly depress the brake pedal with left foot and shift to D or R position, then check the hydraulic pressure at idling and stalling. STANDARD VALUE Shift position While idling [MPa {kgf/cm 2 }] While stalling [MPa {kgf/cm 2 }] D position 0.35 to 0.43 {3.6 to 4.4} 1.20 to 1.38 {12.2 to 14.0} R position 0.76 to 0.95 {7.7 to 9.7} 1.41 to 1.63 {14.4 to 16.6} NOTE: When there is an open or short circuit in the line pressure control solenoid ASSY (SLT) system, the line pressure reaches the maximum.
6. Shift table WARNING: Observe the legal speed limit and confirm the safety on the road. CAUTION: Always perform the inspection after the engine check and adjustment. Perform the inspection at an oil temperature (40 to 110°C {104 to 230°F}) in normal driving temperature. Perform the inspection at an engine coolant temperature of 60 to 90°C {140 to 194°F}. Turn the A/C and the cruise control OFF. NOTE: The values equal to or higher than the maximum speed are for reference because they cannot be achieved. Do not shift to 6th gear when the AT oil temperature is less than 20°C {68°F}. Lockup is prohibited when the AT oil temperature is less than 20°C {68°F}. Lockup does not occur at 1st gear of manual mode. Acceleration slipping lock-up is prohibited when the AT oil temperature is less than 40°C {104°F} or 110°C {230°F} or more. Reduction slipping lock-up is prohibited when the AT oil temperature is less than 20°C {68°F} or 110°C {230°F} or more. Shift table Use SSM3 to select [Current Data Display & Save]-->[Normal sampling], and then select [AT Speed], [Control the Shift Position], [Accel. Opening Angle], [A/T Oil Temperature], and [Coolant Temp]. Confirm [AT Speed] when [Control the Shift Position] is up-shifted. Throttle opening angle 100% 5 to 10 % Shift point 1-->2 2-->3 3-->4 4-->5 5-->6 1-->2 2-->3 3-->4 4-->5 5-->6 D position (km/h {MPH}) 47 to 53 {29 to 33} 96 {60} 142 {88} 201 {125} 282 {175} 12 {7} 20 {12} 30 {19} 48 {30} 59 {37} Lock-up Use SSM3 to select [Current Data Display & Save]-->[Normal sampling], and then select [AT Speed], [Control the Shift Position], [Accel. Opening Angle], [Engine Speed], [Turbine Revolution Speed], [Coolant Temp.], and [Lock up status]. Confirm that the difference between [Engine Speed] and [Turbine Revolution Speed] is 50 r/min or less. Throttle opening angle 5 to 10 % Lock-up ON Gear position 6th D position (km/h {MPH}) 57 {35} or more Manual downshift permission vehicle speed Shift position M6-->M5 M5-->M4 M4-->M3 M3-->M2 M2-->M1 Vehicle speed (km/h {MPH}) 284 {176} 201 {125} 142 {88} 95 {59} 53 {33}
7. Driving test WARNING: Observe the legal speed limit and confirm the safety on the road. CAUTION: Always perform the inspection after the engine check and adjustment. Perform the inspection at an oil temperature (60 to 90°C {140 to 194°F}) in normal driving temperature. Turn the A/C and the cruise control OFF. DRIVING TEST LIST Check item Inspection and confirmation procedure D position shift function Check shifting of 1st <---->2nd <---->3rd <---->4th <---->5th <---->6th during normal driving on city streets. Shift shock level during D position driving Check the shock level at each up-shifting during normal driving. Kick-down function Perform kick-down operation in each gear and check for the down-shifting. Check the shock level at kick down. Engine brake operation Shift the select lever to "-" while driving in M position 6th gear (approx. 70 to 80 km/h {43 to 50 MPH}) and check the engine brake operation in 5th gear. Shift the select lever to "-" while driving in M position 5th gear (approx. 55 to 65 km/h {34 to 40 MPH}) and check the engine brake operation in 4th gear. Shift the select lever to "-" while driving in M position 4th gear (approx. 40 to 50 km/h {25 to 31 MPH}) and check the engine brake operation in 3rd gear. Shift the select lever to "-" while driving in M position 3rd gear (approx. 25 to 35 km/h {16 to 22 MPH}) and check the engine brake operation in 2nd gear. Shift the select lever to "-" while driving in M position 2nd gear (approx. 10 to 20 km/h {6 to 12 MPH}) and check the engine brake operation in 1st gear. Shift point at accelerator pedal in full throttle Start in D position with the accelerator pedal in full throttle and check that the up-shifting speed of 1st -->2nd conforms to the shift point. (Refer to the shift table for shift point speeds) Lock-up function When the accelerator is lightly depressed while driving on a flat road at a constant speed within the lock-up speed range, check that the engine speed does not change greatly. P position operation Stop the vehicle on an uphill grade (approx. 5° or more) and shift to P position, then check that the vehicle does not move when the parking brake is released. Noise and vibration Check for noise and vibration during driving and shifting. Hill climb/down control function Check that up-shifting is performed at higher engine speed than driving on a level road when climbing a hill in D position. Check that down-shifting is performed at higher engine speed than driving on a level road when descending a hill in D position. Oil leakage Check that there is no oil leakage after the driving test.
8. Manual driving test Disconnect the harness connector (24 pins) equipped with a lever on the upper part of the transmission. Check that gear shift conforming to each position occurs during driving. Criteria Select lever position Gear position P position P R position R D position 4th Clear diagnostic codes after the manual driving test. (Refer to «CHECKING/CLEARING DIAGNOSTIC CODES»(ref-619150-S03396316552014053000000) )
9. Check of solenoid operation SSM3-system operation check mode Turn the ignition switch to OFF. Connect SSM3 to the data link connector. Turn the ignition switch to ON with the engine stopped. Display the [System Operation Check Mode] screen according to the screen display. Perform the following active tests. SSM3 SCREEN: [WORK SUPPORT] -->[SYSTEM OPERATION CHECK MODE] Item name Description Restriction [Activate the Solenoid(S1)] Turning ON<---->OFF of transmission 3 way solenoid ASSY (S1) is possible. Vehicle speed 0 km/h {0 MPH} P or N position Engine speed: 0 r/min [Activate the Solenoid(S2)] Turning ON<---->OFF of transmission 3 way solenoid ASSY (S2) is possible. Vehicle speed 0 km/h {0 MPH} P or N position Engine speed: 0 r/min [Activate the Solenoid(S3)] Turning ON<---->OFF of transmission 3 way solenoid ASSY (S3) is possible. Vehicle speed 0 km/h {0 MPH} P or N position Engine speed: 0 r/min [Activate the Solenoid(S4)] Turning ON<---->OFF of transmission 3 way solenoid ASSY (S4) is possible. Vehicle speed 0 km/h {0 MPH} P or N position Engine speed: 0 r/min [Activate the Solenoid(SL1)] MIN current <---->MAX current of clutch control solenoid No. 1 (SL1) is possible. Vehicle speed 0 km/h {0 MPH} P or N position Engine speed: 0 r/min [Activate the Solenoid(SL2)] MIN current <---->MAX current of clutch control solenoid No. 1 (SL2) is possible. Vehicle speed 0 km/h {0 MPH} P or N position Engine speed: 0 r/min [Activate the Solenoid(SLU)] MIN current <---->MAX current of lock-up control solenoid (SLU) is possible. Vehicle speed 0 km/h {0 MPH} P or N position Engine speed: 0 r/min [Activate the Solenoid(SR)] Turning ON<---->OFF of transmission 3 way solenoid ASSY (SR) is possible. Vehicle speed 0 km/h {0 MPH} P or N position Engine speed: 0 r/min [Activate the Solenoid(SLT)] MIN current <---->MAX current of line pressure control solenoid ASSY (SLT) is possible. (MAX current -->duty ratio 100% (line pressure at idling)) (MIN current -->duty ratio 0% (line pressure at stall)) Vehicle speed 0 km/h {0 MPH} P or N position Engine speed: 0 r/min SOLENOID CONDITION AT SHIFTING Symbol Operating condition o Continuity status (ON) x Non-continuity status (OFF) AT NORMAL CONDITION Select lever position Gear position Transmission 3 way solenoid ASSY (S1) Transmission 3 way solenoid ASSY (S2) Transmission 3 way solenoid ASSY (S3) Transmission 3 way solenoid ASSY (S4) Transmission 3 way solenoid ASSY (SR) Clutch control solenoid No. 1 (SL1) Clutch control solenoid No. 1 (SL2) D position 1st x o o x o x o 2nd o o o o o x x 3rd o x o x o x x 4th o x x x o x o 5th o x x o x o x 6th o o x o x o x

Scheme 17

Scheme 18

Freeze Frame Data

1. Freeze data table Use SSM3 to select [Freeze Frame Data Display] on the [Transmission Control System] screen according to the screen display. NOTE: The transmission condition (TCM data) when a diagnostic code is detected and 2 seconds before a diagnostic code is detected can be checked at intervals of 0.5 seconds. (Refer to «TROUBLESHOOTING PROCEDURES FOR ECM CONTROL SYSTEM»(ref-619149-S12540931392014053000000) ) Check the consistency of the interviewed trouble phenomenon and the list of diagnostic codes. After repair, perform a confirmation test by referring to the driving condition checked above. Item name [Coolant Temp.] [Shift SW Status History (P Range)] [Engine Speed] [Shift SW Status History (R Range)] [Vehicle Speed] [Shift SW Status History (N Range)] [Time Since Engine Start] [Shift SW Status History (D Range)] [Number of warm-ups] [Manual SW History] [Meter since DTC cleared] [Up SW History] [Time since DTC cleared] [Down SW History] [Control module voltage] [Snow Mode History] [Freeze frame data] [Snow SW History] [Engine Speed] [Sport SW History] [Coolant Temp.] [A/C Switch History] [Accel. Opening Angle] [TC Terminal] [Throttle Opening Angle] [Turbine Revolution Speed] [Stop Light Switch] [AT Speed] [Shift SW Status (P Range)] [ATF Temp.] [Shift SW Status (R Range)] [Shift Indicator Lamp UP Shift] [Shift SW Status (N Range)] [Shift Indicator Lamp Down Shift] [Shift SW Status (D Range)] [Sport Mode] [Manual SW] [Control the Shift Position] [Up SW] [Lock up status] [Down SW] [SLT Solenoid Status] [Snow Mode] [Activate the Lock Up (SLT)] [Snow SW] [# Codes(Include History)] [Sport SW] [Number Of ALL DTCs] [A/C Switch] [Trip Count] [Stop Light Switch History] [Count] [Time Count]

Checking Problems That Do Not Constantly Occur

1. Check mode (wiring harness and connector instantaneous interruption check) NOTE: When a defective system is found by diagnostic codes output in DTC (check mode) check, narrow down defective part by the following procedure. Use SSM3 to display the [Transmission Control System/Work Support] screen according to the screen display. Select [Test Mode Change] to switch to the check mode. After reading diagnostic codes in the check mode, clear the diagnostic codes memory. Select the check mode and start the engine. With the vehicle idling, swing the wiring harness and connector of the defective system which is output in DTC (check mode) check. When the check engine warning light is illuminated, the wiring harness or connector at the point may have poor contact. After check, be sure to select [Test Mode Change] to switch to the normal mode.

Work Support

1. AT learning values initialization CAUTION: Execute [Clear the AT learned information] when any of transmission ASSY, valve body ASSY, transmission wire, engine ASSY, transmission control computer is replaced. Wait for 1 minute or more after connecting the battery terminal when performing AT learning value initialization. NOTE: The learning value is not initialized (cleared) only by removing the ground terminal of the battery. Check that the shift is in P position and connect SSM3 to DLC3 to turn IG and the power of SSM3 ON. CAUTION: Do not start engine. Execute AT learning value initialization. Select [Transmission Control System/Work Support] -->[Clear the AT learned information] from the main menu according to SSM3 screen display and execute them to initialize AT learning value.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. Transmission control computer NOTE: Check the voltage and continuity between terminals. Terminal No. (Terminal symbol) Input/output Item Measuring condition Criteria A18-34 (IG1) <---->A18-33 (E01) Input Voltage IG ON 11 to 14V A18-35 (IG2) <---->A18-33 (E01) Input Voltage IG ON 11 to 14V A18-26 (BM) <---->A18-33 (E01) Input Voltage Always 11 to 14V A19-18 (SP2+) <---->A19-7 (SP2-) Input Waveform When vehicle speed is approx. 20 km/h {12 MPH}. Waveform 1 A19-17 (NT+) <---->A19-28 (NT-) Input Waveform When engine is idling (select lever in P or N position). Waveform 2 A19-3 (P) <---->A18-33 (E01) Input Voltage IG ON Select lever in P position 11 to 14V Input Voltage IG ON Select lever in any other than P position Less than 1 V A19-10 (R) <---->A18-33 (E01) Input Voltage IG ON Select lever in R position 11 to 14V Input Voltage IG ON Select lever in any other than R position Less than 1 V A19-21 (N) <---->A18-33 (E01) Input Voltage IG ON Select lever in N position 11 to 14V Input Voltage IG ON Select lever in any other than N position Less than 1 V A19-9 (D) <---->A18-33 (E01) Input Voltage IG ON Select lever in D position 11 to 14V Input Voltage IG ON Select lever in any other than D position Less than 1 V A19-8 (M) <---->A18-33 (E01) Input Voltage IG ON Manual mode switch ON 11 to 14V Input Voltage IG ON Manual mode switch OFF Less than 1 V A19-2 (SFTU) <---->A18-33 (E01) Input Voltage IG ON Shift manual mode switch ON --> "+" Less than 1 V A19-1 (SFTD) <---->A18-33 (E01) Input Voltage IG ON Shift manual mode switch ON --> "-" Less than 1 V A18-22 (OIL) <---->A18-23 (EOIL) Input Voltage Transmission oil temperature 115°C or more Less than 1 V A18-16 (SL1+) <---->A18-12 (SL1-) Output Waveform 5th or 6th gear Waveform 3 A18-5 (SL2+) <---->A18-11 (SL2-) Output Waveform While engine idling Waveform 4 A18-4 (SLT+) <---->A18-9 (SLT-) Output Waveform While engine idling Waveform 5 A18-13 (SLU+) <---->A18-1 (SLU-) Output Waveform In M position 2nd to 6th gear (when lock-up is operating) Waveform 6 A18-7 (S1) <---->A18-33 (E01) Output Voltage 1st gear Less than 1 V Output Voltage Any other than 1st gear 11 to 14V A18-17 (S2) <---->A18-33 (E01) Output Voltage 1st, 2nd or 6th gear 11 to 14V Output Voltage 3rd, 4th or 5th gear Less than 1 V A18-6 (S3) <---->A18-33 (E01) Output Voltage 1st, 2nd or 3rd gear 11 to 14V Output Voltage 4th, 5th or 6th gear Less than 1 V A18-14 (S4) <---->A18-33 (E01) Output Voltage 5th or 6th gear 11 to 14V Output Voltage 1st, 2nd, 3rd or 4th gear Less than 1 V A18-15 (SR) <---->A18-33 (E01) Output Voltage 1st, 2nd, 3rd or 4th gear 11 to 14V Output Voltage 5th or 6th gear Less than 1 V A18-29 (CANH) <---->A18-33 (E01) - Waveform IG ON Engine stop Waveform 7 A18-28 (CANL) <---->A18-33 (E01) - Waveform IG ON Engine stop Waveform 8 A18-33 (E01) <---->chassis ground - Resistance Always Less than 1 ohms A18-3 (E02) <---->chassis ground - Resistance Always Less than 1 ohms A19-13 (SPORT) <---->chassis ground Input Voltage IG ON Pattern select switch "SPORT" ON Less than 1 V Input Voltage IG ON Pattern select switch "SPORT" OFF 11 to 14V A19-24 (SNOW) <---->chassis ground Input Voltage IG ON Pattern select switch "SNOW" ON Less than 1 V Input Voltage IG ON Pattern select switch "SNOW" OFF 11 to 14V Waveform 1 Item Contents Measuring terminal A19-18 (SP2+) <---->A19-7 (SP2-) Equipment setting 1 V/DIV, 2 ms/DIV Measuring condition When vehicle speed is approx. 20 km/h {12 MPH}. Waveform 2 Item Contents Measuring terminal A19-17 (NT+) <---->A19-28 (NT-) Equipment setting 5 V/DIV, 2 msec./DIV Measuring condition When engine is idling (select lever in P or N position). Waveform 3 Item Contents Measuring terminal A18-16 (SL1+) <---->A18-12 (SL1-) Equipment setting 5 V/DIV, 1 ms/DIV Measuring condition 5th or 6th gear Waveform 4 Item Contents Measuring terminal A18-5 (SL2+) <---->A18-11 (SL2-) Equipment setting 5 V/DIV, 1 msec./DIV Measuring condition While engine running Waveform 5 Item Contents Measuring terminal A18-4 (SLT+) <---->A18-9 (SLT-) Equipment setting 5 V/DIV, 1 msec./DIV Measuring condition While engine idling Waveform 6 Item Contents Measuring terminal A18-13 (SLU+) <---->A18-1 (SLU-) Equipment setting 5 V/DIV, 1 msec./DIV Measuring condition M position: in 2nd to 6th gear (when lock-up is operating) Waveform 7 Item Contents Measuring terminal A18-29 (CANH) <---->A18-33 (E01) Equipment setting 1 V/DIV, 10 msec./DIV Measuring condition Engine stop, IG ON Waveform 8 Item Contents Measuring terminal A18-28 (CANL) <---->A18-33 (E01) Equipment setting 1 V/DIV, 10 msec./DIV Measuring condition Engine stop, IG ON
2. Instrument panel junction block ASSY, main body ECM (multiplex network body computer) NOTE: Measure the voltage between the terminals.

Failsafe List

WHEN FOLLOWING CODES ARE RECORDED ON TRANSMISSION CONTROL COMPUTER ASSY, FAIL SAFE MODE IS INITIATED

TABLE OF SOLENOID CONTINUITY STATUS AT NORMAL CONDITION

Note. ON: continuity status OFF: non-continuity status

TABLE OF GEAR RANGE WHEN SHIFT SOLENOID IS ABNORMAL (AT D POSITION)

TABLE OF GEAR RANGE WHEN SHIFT SOLENOID IS ABNORMAL (IN MANUAL MODE)

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

Either of the following conditions must be satisfied: condition (A) or (B)

CONDITION (A)

CONDITION (B)

TYPICAL MALFUNCTION THRESHOLDS

TYPICAL ENABLING CONDITIONS - P0707: TRANSMISSION RANGE SENSOR "A" CIRCUIT LOW

TYPICAL ENABLING CONDITIONS - P0708: TRANSMISSION RANGE SENSOR "A" CIRCUIT HIGH

TYPICAL MALFUNCTION THRESHOLDS - P0707: TRANSMISSION RANGE SENSOR "A" CIRCUIT LOW

TYPICAL MALFUNCTION THRESHOLDS - P0708: TRANSMISSION RANGE SENSOR "A" CIRCUIT HIGH

Scheme 33

TYPICAL ENABLING CONDITIONS - ALL

Scheme 34

TYPICAL ENABLING CONDITIONS - P0712: TRANSMISSION FLUID TEMPERATURE SENSOR "A" CIRCUIT LOW

TYPICAL ENABLING CONDITIONS - P0713: TRANSMISSION FLUID TEMPERATURE SENSOR "A" CIRCUIT HIGH

ALL OF FOLLOWING CONDITIONS ARE ESTABLISHED

TYPICAL MALFUNCTION THRESHOLDS - P0712: TRANSMISSION FLUID TEMPERATURE SENSOR "A" CIRCUIT LOW

TYPICAL MALFUNCTION THRESHOLDS - P0713: TRANSMISSION FLUID TEMPERATURE SENSOR "A" CIRCUIT HIGH

Scheme 35

Scheme 36

Scheme 37

The following items are common to the all conditions below.

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed. When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

When both of the following conditions are established: condition (C) and (D)

CONDITION (C)

CONDITION (D)

GEAR POSITIONS WHEN MECHANICAL PROBLEMS OCCUR IN REVERSE SEQUENCE VALVE

Scheme 38

1. Read the diagnostic code Follow the SSM3 on-screen instructions to check the diagnostic codes. (Refer to «CHECKING/CLEARING DIAGNOSTIC CODES»(ref-619150-S03396316552014053000000) ) RESULT Result Go to Only P0729 and P2714 are output. A P0729, P2714 and other diagnostic codes are output. B B: Related DTC chart (refer to «LIST OF DIAGNOSTIC CODES»(ref-619150-S00681233852014053000000) ) A: Go to Next Step
2. Shift position check CAUTION: Perform the inspection at an oil temperature (60-90°C) in normal driving condition. Turn the A/C and the cruise control OFF. Drive in manual mode and check the shift position. WARNING: Confirm the safety on the road. Gear position of transmission control computer ASSY 1st 2nd 3rd 4th 5th 6th Gear positions when problems occur 1st 2nd 3rd 4th 5th 4th Criteria: Shift position changes. NG: Repair or replacement of transmission valve body ASSY (refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) OK: Go to Next Step
3. Line pressure check CAUTION: Wash the equipment and hoses with appropriate detergent before and after measurement. Always perform the inspection after the engine check and adjustment. Perform the inspection at an oil temperature (60 to 90°C) in normal driving condition. Perform the inspection with the A/C OFF. Do not perform the inspection continuously for 5 seconds or more at stall. (Time from the accelerator full close to full open, stall speed reading and the accelerator full close) After performing the stall test, be sure to cool down the engine for at least 1 minute with the select lever set in P or N position, and at an idle speed of 1200 rpm or less. If the stall speed is higher than the specified range, finish the stall test in as short a time as possible, in order to prevent the automatic transmission from being damaged. Perform the stall test in normal mode. Remove the under cover No. 1. Remove the under cover No. 2. Remove the exhaust pipe ASSY FR. Attach the SST on the transmission. SST 18681AA040, 498897700, 498575400 CAUTION: Use 18681AA040 with genuine O-ring (17006AA000) attached. Route the hose so that it does not contact the exhaust pipe. Install the center exhaust pipe. Firmly apply the parking brake and set the wheel stoppers. Remove the test plug, install the gauge and start the engine. Firmly depress the brake pedal with left foot and shift to D or R position, then check the hydraulic pressure at idling and stalling. STANDARD VALUE Shift position While idling [MPa {kgf/cm 2 }] While stalling [MPa {kgf/cm 2 }] D position 0.35 to 0.43 {3.6 to 4.4} 1.20 to 1.38 {12.2 to 14.0} R position 0.76 to 0.95 {7.7 to 9.7} 1.41 to 1.63 {14.4 to 16.6} NOTE: When there is an open or short circuit in the line pressure control solenoid ASSY (SLT) system, the line pressure reaches the maximum. NG: Repair or replacement of transmission valve body ASSY (refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) OK: Go to Next Step
4. Diagnostic codes clear and driving test Follow the SSM3 on-screen instructions to clear the diagnostic codes. (Refer to «CHECKING/CLEARING DIAGNOSTIC CODES»(ref-619150-S03396316552014053000000) ) Perform driving test. WARNING: Confirm the safety on the road. Follow the SSM3 on-screen instructions to check the diagnostic codes. (Refer to «CHECKING/CLEARING DIAGNOSTIC CODES»(ref-619150-S03396316552014053000000) ) Criteria: Diagnostic codes are not output. NG: Repair or replacement of transmission valve body ASSY (refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) OK: Complete

The following items are common to the all conditions below.

P0751: Shift Solenoid "A" Performance/Stuck Off

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed.

When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

When both of the following conditions are established: condition (C) and (D)

CONDITION (C)

CONDITION (D)

P0752: Shift Solenoid "A" Stuck On

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed.

When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

When both of the following conditions are established: condition (C) and (D)

CONDITION (C)

CONDITION (D)

Scheme 39

The following items are common to the all conditions below.

P0756: Shift Solenoid "B" Performance/Stuck Off

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed.

When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

When both of the following conditions are established: condition (C) and (D)

CONDITION (C)

CONDITION (D)

P0757: Shift Solenoid "B" Stuck On

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed.

When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

When both of the following conditions are established: condition (C) and (D)

CONDITION (C)

CONDITION (D)

Scheme 40

P0761: Shift Solenoid "C" Performance/Stuck Off

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed.

When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

When both of the following conditions are established: condition (C) and (D)

CONDITION (C)

CONDITION (D)

When both of the following conditions are established: condition (E) and (F)

CONDITION (E)

CONDITION (F)

P0762: Shift Solenoid "C" Stuck On

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed.

When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

When both of the following conditions are established: condition (C) or (D)

CONDITION (C)

CONDITION (D)

P0781: 1-2 Shift

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed.

When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

When both of the following conditions are established: condition (C) or (D)

CONDITION (C)

CONDITION (D)

Scheme 41

The following items are common to the all conditions below.

P0766: Shift Solenoid "D" Performance/Stuck Off

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed.

When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

When both of the following conditions are established: condition (C) and (D)

CONDITION (C)

CONDITION (D)

P0767: Shift Solenoid "D" Stuck On

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed.

When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

P0776: Pressure Control Solenoid "B" Performance/Stuck Off

Compare the target gear specified by TCM and the gear ratio calculated from turbine shaft speed and vehicle speed.

When both of the following conditions are established: condition (A) and (B)

CONDITION (A)

CONDITION (B)

When both of the following conditions are established: condition (C) and (D)

CONDITION (C)

CONDITION (D)

Scheme 42

TYPICAL ENABLING CONDITIONS - P0961: PRESSURE CONTROL SOLENOID "A" CONTROL CIRCUIT RANGE/PERFORMANCE

TYPICAL ENABLING CONDITIONS - P0962: PRESSURE CONTROL SOLENOID "A" CONTROL CIRCUIT LOW

TYPICAL ENABLING CONDITIONS - P0963: PRESSURE CONTROL SOLENOID "A" CONTROL CIRCUIT HIGH

TYPICAL MALFUNCTION THRESHOLDS - P0961: PRESSURE CONTROL SOLENOID "A" CONTROL CIRCUIT RANGE/PERFORMANCE

TYPICAL MALFUNCTION THRESHOLDS - P0962: PRESSURE CONTROL SOLENOID "A" CONTROL CIRCUIT LOW

TYPICAL MALFUNCTION THRESHOLDS - P0963: PRESSURE CONTROL SOLENOID "A" CONTROL CIRCUIT HIGH

Scheme 43

TYPICAL ENABLING CONDITIONS - P0965: PRESSURE CONTROL SOLENOID "B" CONTROL CIRCUIT RANGE/PERFORMANCE

TYPICAL ENABLING CONDITIONS - P0966: PRESSURE CONTROL SOLENOID "B" CONTROL CIRCUIT LOW

TYPICAL ENABLING CONDITIONS - P0967: PRESSURE CONTROL SOLENOID "B" CONTROL CIRCUIT HIGH

TYPICAL MALFUNCTION THRESHOLDS - P0965: PRESSURE CONTROL SOLENOID "B" CONTROL CIRCUIT RANGE/PERFORMANCE

TYPICAL MALFUNCTION THRESHOLDS - P0966: PRESSURE CONTROL SOLENOID "B" CONTROL CIRCUIT LOW

TYPICAL MALFUNCTION THRESHOLDS - P0967: PRESSURE CONTROL SOLENOID "B" CONTROL CIRCUIT HIGH

Scheme 44

TYPICAL MALFUNCTION THRESHOLDS - P0973: SHIFT SOLENOID "A" CONTROL CIRCUIT LOW

TYPICAL MALFUNCTION THRESHOLDS - P0974: SHIFT SOLENOID "A" CONTROL CIRCUIT HIGH

Scheme 45

TYPICAL MALFUNCTION THRESHOLDS - P0976: SHIFT SOLENOID "B" CONTROL CIRCUIT LOW

TYPICAL MALFUNCTION THRESHOLDS - P0977: SHIFT SOLENOID "B" CONTROL CIRCUIT HIGH

Scheme 46

TYPICAL MALFUNCTION THRESHOLDS - P0979: SHIFT SOLENOID "C" CONTROL CIRCUIT LOW

TYPICAL MALFUNCTION THRESHOLDS - P0980: SHIFT SOLENOID "C" CONTROL CIRCUIT HIGH

Scheme 47

TYPICAL MALFUNCTION THRESHOLDS - P0982: SHIFT SOLENOID "D" CONTROL CIRCUIT LOW

TYPICAL MALFUNCTION THRESHOLDS - P0983: SHIFT SOLENOID "D" CONTROL CIRCUIT HIGH

Scheme 48

TYPICAL MALFUNCTION THRESHOLDS - P0985: SHIFT SOLENOID "E" CONTROL CIRCUIT LOW

TYPICAL MALFUNCTION THRESHOLDS - P0986: SHIFT SOLENOID "E" CONTROL CIRCUIT HIGH

Scheme 49

The following items are common to the all conditions below.

P2714: Pressure Control Solenoid "D" Performance/Stuck Off

Either of the following conditions must be satisfied: ON malfunction (A), (B), (C), (D), (E), (F), (G), (H) or (I)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

ON MALFUNCTION (D)

ON MALFUNCTION (E)

ON MALFUNCTION (F)

ON MALFUNCTION (G)

ON MALFUNCTION (H)

ON MALFUNCTION (I)

P0894: Transmission Component Slipping

When both of the following conditions are established: AT slip (A) or (B)

AT SLIP (A)

AT SLIP (B)

Scheme 50

Scheme 51

1. Read the diagnostic code Follow the SSM3 on-screen instructions to check the diagnostic codes. (Refer to «CHECKING/CLEARING DIAGNOSTIC CODES»(ref-619150-S03396316552014053000000) ) RESULT Result Go to P2714 and P0894, or only P0894 is output. A P2714 or P0894 and other diagnostic codes are output. B B: Related DTC chart (refer to «LIST OF DIAGNOSTIC CODES»(ref-619150-S00681233852014053000000) ) A: Go to Next Step
2. Line pressure check CAUTION: Wash the equipment and hoses with appropriate detergent before and after measurement. Always perform the inspection after the engine check and adjustment. Perform the inspection at an oil temperature (60 to 90°C) in normal driving condition. Perform the inspection with the A/C OFF. Do not perform the inspection continuously for 5 seconds or more at stall. (Time from the accelerator full close to full open, stall speed reading and the accelerator full close) After performing the stall test, be sure to cool down the engine for at least 1 minute with the select lever set in P or N position, and at an idle speed of 1200 rpm or less. If the stall speed is higher than the specified range, finish the stall test in as short a time as possible, in order to prevent the automatic transmission from being damaged. Perform the stall test in normal mode. Remove the under cover No. 1. Remove the under cover No. 2. Remove the exhaust pipe ASSY FR. Attach the SST on the transmission. SST 18681AA040, 498897700, 498575400 CAUTION: Use 18681AA040 with genuine O-ring (17006AA000) attached. Route the hose so that it does not contact the exhaust pipe. Install the center exhaust pipe. Firmly apply the parking brake and set the wheel stoppers. Remove the test plug, install the gauge and start the engine. Firmly depress the brake pedal with left foot and shift to D or R position, then check the hydraulic pressure at idling and stalling. STANDARD VALUE Shift position While idling [MPa {kgf/cm 2 }] While stalling [MPa {kgf/cm 2 }] D position 0.35 to 0.43 {3.6 to 4.4} 1.20 to 1.38 {12.2 to 14.0} R position 0.76 to 0.95 {7.7 to 9.7} 1.41 to 1.63 {14.4 to 16.6} NOTE: When there is an open or short circuit in the line pressure control solenoid ASSY (SLT) system, the line pressure reaches the maximum. NG: Step 16 OK: Go to Next Step
3. Shift position check CAUTION: Perform the inspection at an oil temperature (60 to 90°C) in normal driving condition. Turn the A/C and the cruise control OFF. Drive in M position and check the shift position. WARNING: Confirm the safety on the road. Criteria: Shift position changes. RESULT System status Gear indication position of transmission control computer ASSY Go to 1st 2nd 3rd 4th 5th 6th Transmission 3 way solenoid ASSY (S1) Stuck OFF 1st 2nd 3rd 4th 5th Neutral A Transmission 3 way solenoid ASSY (S2) Stuck OFF 3rd 3rd 3rd 4th 5th 5th B Transmission 3 way solenoid ASSY (S3) Stuck ON 1st 2nd 3rd 3rd Neutral Neutral C Stuck OFF 3rd 6th 4th 4th 5th 6th Transmission 3 way solenoid ASSY (S4) Stuck ON (1) 1st 2nd 3rd 4th 5th 6th D Stuck OFF 1st 2nd 3rd 4th 4th 4th E Normal 1st 2nd 3rd 4th 5th 6th D (1) When transmission 3 way solenoid ASSY (S4) sticks to ON, the shift is normal. B: Step 7 C: Step 10 D: Step 16 E: Step 13 A: Go to Next Step
4. Check of transmission 3 way solenoid ASSY (S1) unit Remove the transmission 3 way solenoid ASSY (S1). (Refer to «DISASSEMBLY»(ref-619159-S11716910952014053000000) ) Check the transmission 3 way solenoid ASSY (S1) unit. (Refer to «NEUTRAL START SWITCH ASSY»(ref-619159-S10737292672014053000000) ) NG: Replacement of the transmission 3 way solenoid ASSY (S1) (Refer to «DISASSEMBLY»(ref-619159-S11716910952014053000000) ) OK: Go to Next Step
5. Check of transmission valve body ASSY unit Check the transmission valve body ASSY. (Refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) Criteria: There is no malfunction and foreign objects on the solenoid installation portions. NG: Replacement of transmission valve body ASSY (refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) OK: Go to Next Step
6. Check of torque converter ASSY unit Check the torque converter ASSY. (Refer to «TORQUE CONVERTER & DRIVE PLATE»(ref-619159-S37407197352014053000000) ) Criteria: There is no malfunction and foreign objects on the solenoid installation portions. NG: Replacement of torque converter ASSY (refer to «REMOVAL»(ref-619159-S07969847722014053000000) ) OK: Replacement of automatic transmission ASSY (refer to «REMOVAL»(ref-619159-S07969847722014053000000) )
7. Check of transmission 3 way solenoid ASSY (S2) unit Remove the transmission 3 way solenoid ASSY (S2). (Refer to «DISASSEMBLY»(ref-619159-S11716910952014053000000) ) Check the transmission 3 way solenoid ASSY (S2) unit. (Refer to «ASSEMBLY»(ref-619159-S34056789642014053000000) ) NG: Replacement of the transmission 3 way solenoid ASSY (S2) (Refer to «DISASSEMBLY»(ref-619159-S11716910952014053000000) ) OK: Go to Next Step
8. Check of transmission valve body ASSY unit Check the transmission valve body ASSY. (Refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) Criteria: There is no malfunction and foreign objects on the solenoid installation portions. NG: Replacement of transmission valve body ASSY (refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) OK: Go to Next Step
9. Check of torque converter ASSY unit Check the torque converter ASSY. (Refer to «TORQUE CONVERTER & DRIVE PLATE»(ref-619159-S37407197352014053000000) ) Criteria: Torque converter ASSY is normal. NG: Replacement of torque converter ASSY (refer to «REMOVAL»(ref-619159-S07969847722014053000000) ) OK: Replacement of automatic transmission ASSY (refer to «REMOVAL»(ref-619159-S07969847722014053000000) )
10. Check of transmission 3 way solenoid ASSY (S3) unit Remove the transmission 3 way solenoid ASSY (S3). (Refer to «ASSEMBLY»(ref-619159-S34056789642014053000000) ) Check the transmission 3 way solenoid ASSY (S3) unit. (Refer to «NEUTRAL START SWITCH ASSY»(ref-619159-S10737292672014053000000) ) NG: Replacement of the transmission 3 way solenoid ASSY (S3) (Refer to «ASSEMBLY»(ref-619159-S34056789642014053000000) ) OK: Go to Next Step
11. Check of transmission valve body ASSY unit Check the transmission valve body ASSY. (Refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) Criteria: There is no malfunction and foreign objects on the solenoid installation portions. NG: Replacement of transmission valve body ASSY (refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) OK: Go to Next Step
12. Check of torque converter ASSY unit Check the torque converter ASSY. (Refer to «REMOVAL»(ref-619159-S07969847722014053000000) ) Criteria: Torque converter ASSY is normal. NG: Replacement of torque converter ASSY (refer to «REMOVAL»(ref-619159-S07969847722014053000000) ) OK: Replacement of automatic transmission ASSY (refer to «REMOVAL»(ref-619159-S07969847722014053000000) )
13. Check of transmission 3 way solenoid ASSY (S4) unit Remove the transmission 3 way solenoid ASSY (S4). (Refer to «DISASSEMBLY»(ref-619159-S11716910952014053000000) ) Check the transmission 3 way solenoid ASSY (S4) unit. (Refer to «NEUTRAL START SWITCH ASSY»(ref-619159-S10737292672014053000000) ) NG: Replacement of the transmission 3 way solenoid ASSY (S4) (Refer to «DISASSEMBLY»(ref-619159-S11716910952014053000000) ) OK: Go to Next Step
14. Check of transmission valve body ASSY unit Check the transmission valve body ASSY. (Refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) Criteria: There is no malfunction and foreign objects on the solenoid installation portions. NG: Replacement of transmission valve body ASSY (refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) OK: Go to Next Step
15. Check of torque converter ASSY unit Check the torque converter ASSY. (Refer to «TORQUE CONVERTER & DRIVE PLATE»(ref-619159-S37407197352014053000000) ) Criteria: Torque converter ASSY is normal. NG: Replacement of torque converter ASSY (refer to «REMOVAL»(ref-619159-S07969847722014053000000) ) OK: Replacement of automatic transmission ASSY (refer to «REMOVAL»(ref-619159-S07969847722014053000000) )
16. Check of line pressure control solenoid ASSY (SLT) unit Check the line pressure control solenoid ASSY (SLT) unit. (Refer to «NEUTRAL START SWITCH ASSY»(ref-619159-S10737292672014053000000) ) NG: Repair or replacement of transmission valve body ASSY (refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) OK: Go to Next Step
17. Check of transmission valve body ASSY unit Check the transmission valve body ASSY. (Refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) Criteria: There is no malfunction and foreign objects on the solenoid installation portions. NG: Replacement of transmission valve body ASSY (refer to «TRANSMISSION VALVE BODY ASSY»(ref-619159-S03062166412014053000000) ) OK: Go to Next Step
18. Check of torque converter ASSY unit Check the torque converter ASSY. (Refer to «TORQUE CONVERTER & DRIVE PLATE»(ref-619159-S37407197352014053000000) ) Criteria: Torque converter ASSY is normal. NG: Replacement of torque converter ASSY (refer to «REMOVAL»(ref-619159-S07969847722014053000000) ) OK: Replacement of automatic transmission ASSY (refer to «REMOVAL»(ref-619159-S07969847722014053000000) )

TYPICAL ENABLING CONDITIONS - P2719: PRESSURE CONTROL SOLENOID "D" CONTROL CIRCUIT RANGE/PERFORMANCE

P2720: PRESSURE CONTROL SOLENOID "D" CONTROL CIRCUIT LOW

P2721: PRESSURE CONTROL SOLENOID "D" CONTROL CIRCUIT HIGH

TYPICAL MALFUNCTION THRESHOLDS - P2719: PRESSURE CONTROL SOLENOID "D" CONTROL CIRCUIT RANGE/PERFORMANCE

P2720: PRESSURE CONTROL SOLENOID "D" CONTROL CIRCUIT LOW

P2721: PRESSURE CONTROL SOLENOID "D" CONTROL CIRCUIT HIGH

Scheme 52

The following items are common to the all conditions below.

TYPICAL MALFUNCTION THRESHOLDS - P2757: TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL CIRCUIT PERFORMANCE/STUCK OFF

MAP A

P2758: TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL CIRCUIT STUCK ON

MAP B

Scheme 53

TYPICAL ENABLING CONDITIONS - P2762: TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL CIRCUIT RANGE/PERFORMANCE

P2763: TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL CIRCUIT HIGH

P2764: TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL CIRCUIT LOW

TYPICAL MALFUNCTION THRESHOLDS - P2762: TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL CIRCUIT RANGE/PERFORMANCE

P2763: TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL CIRCUIT HIGH

P2764: TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL CIRCUIT LOW

Scheme 54

TYPICAL ENABLING CONDITIONS - U0073: CONTROL MODULE COMMUNICATION BUS "A" OFF

U0401: INVALID DATA RECEIVED FROM ECM/PCM "A"

U0416: INVALID DATA RECEIVED FROM VEHICLE DYNAMICS CONTROL MODULE

TYPICAL MALFUNCTION THRESHOLDS - U0073: CONTROL MODULE COMMUNICATION BUS "A" OFF

U0401: INVALID DATA RECEIVED FROM ECM/PCM "A"

U0416: INVALID DATA RECEIVED FROM VEHICLE DYNAMICS CONTROL MODULE
