Engine Cooling System (H4DOTC): Overhaul Subaru Baja I

ASSEMBLY

Assemble in the reverse order of disassembly.

Tightening torque

4.4 N.m (0.45 kgf-m, 3.3 ft-lb)

Scheme 165

Tightening torque

3.4 N.m (0.35 kgf-m, 2.5 ft-lb)

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

1. Disconnect the ground cable from battery.
2. Lift-up the vehicle.
3. Remove the under cover.
4. Disconnect the connector of sub fan motor (B).
5. Lower the vehicle.
6. Remove the air intake duct.
7. Remove the bolts which hold the sub fan shroud to radiator.
8. Remove the overflow pipe.
9. Remove the radiator sub fan shroud through the under side of vehicle.

Assemble in the reverse order of disassembly.

Tightening torque

4.4 N.m (0.45 kgf-m, 3.3 ft-lb)

Scheme 171

Tightening torque

3.4 N.m (0.35 kgf-m, 2.5 ft-lb)

Scheme 172

Scheme 173

1. Disconnect the overflow hose from the radiator filler neck position.
2. Pull out the reservoir tank to direction of arrow while pushing the pawl (A).
