Electrical System - Engine (Coupe): Wiring Smart Fortwo II

Engine Control Systems 4 illustrations

Legend of wiring diagram for starter, alternator - PE15.00-P-2000-60MCU

ENGINE 132 in MODEL 451

CodeDesignationCoordinates
F58Starter/alternator fuse15G
F91SAM prefuse17G
G1Battery17L
G2Alternator6L
M1Starter13L
N3/10ME-SFI [ME] control unit7A
N10/10SAM control unit3A 19A
N10/10f1Fuse 114A
N10/10f33Fuse 3317A
N10/10k3Starter relay14B
S2/1Ignition/starter switch20L
W10Ground (battery)18G
X26Interior/engine connector3E 13H

Wiring diagram for starter, alternator - PE15.00-P-2000-97MCU

CodeDesignationPosition
F58Xxx15G
F91SAM prefuse17G
G1Battery17L
G2Generator6L
M1Starter13L
N10/10SAM control unit19A
N10/10SAM control unit3A
N10/10f1Fuse 114A
N10/10f33Fuse 33
N10/10k3Starter relay
N3/10ME-SFI [ME] control module7A
S2/1Ignition/starter switch20L
W10Ground (battery)18G
X26Interior-engine connector13H
X26Interior-engine connector4E

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Wiring diagram for starter, alternator - PE15.00-P-2000MCU

ENGINE 132 in MODEL 451

PE15.00-P-2000-99MCUWiring diagram Starter, alternatorPE15.00-P-2000-99MCU
PE15.00-P-2000-60MCULegend of wiring diagram for starter, alternatorPE15.00-P-2000-60MCU
OV00.01-P-1901-03MCCUse of wiring diagramsOV00.01-P-1901-03MCC
OV00.01-P-1901MCUSearch aid for all wiring diagram groupsOV00.01-P-1901MCU
OV00.01-P-1001-27MCAbbreviations for wiring diagramsOV00.01-P-1001-27MC
OV00.01-P-1001-28MCAbbreviations of signal and circuit designations for wiring diagramsOV00.01-P-1001-28MC
GF00.19-P-1000MCULocation and assignment of line and connectorsGF00.19-P-1000MCU
GF00.19-P-2000MCULocation and assignment of ground pointsGF00.19-P-2000MCU
GF00.19-P-3000MCULocation and assignment of Z connector sleeves (line connectors in wiring harness)GF00.19-P-3000MCU
PE07.00-P-1100MCUFurther wiring diagramsPE07.00-P-1100MCU
PE54.00-P-1100MCUFurther wiring diagramsPE54.00-P-1100MCU

Wiring diagram for starter, alternator - PE15.00-P-2000-99MCU

CodeDesignationPosition
F58Xxx15 G
F91SAM prefuse16 G
G1Battery17 L
G2Generator6 L
M1Starter13 L
N10/10SAM control unit3 A
N10/10SAM control unit19 A
N10/10f1Fuse 114 A
N10/10f33Fuse 3317 A
N10/10k3Starter relay14 B
N3/10ME-SFI [ME] control module7 A
S2/1Ignition/starter switch20 L
W10Ground (battery)18 G
X26Interior-engine connector3 E
X26Interior-engine connector13 H

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25
