Legend of wiring diagram for starter, alternator - PE15.00-P-2000-60MCU
ENGINE 132 in MODEL 451
| Code | Designation | Coordinates |
|---|---|---|
| F58 | Starter/alternator fuse | 15G |
| F91 | SAM prefuse | 17G |
| G1 | Battery | 17L |
| G2 | Alternator | 6L |
| M1 | Starter | 13L |
| N3/10 | ME-SFI [ME] control unit | 7A |
| N10/10 | SAM control unit | 3A 19A |
| N10/10f1 | Fuse 1 | 14A |
| N10/10f33 | Fuse 33 | 17A |
| N10/10k3 | Starter relay | 14B |
| S2/1 | Ignition/starter switch | 20L |
| W10 | Ground (battery) | 18G |
| X26 | Interior/engine connector | 3E 13H |
Wiring diagram for starter, alternator - PE15.00-P-2000-97MCU
Document number
Document title
| Code | Designation | Position |
|---|---|---|
| F58 | Xxx | 15G |
| F91 | SAM prefuse | 17G |
| G1 | Battery | 17L |
| G2 | Generator | 6L |
| M1 | Starter | 13L |
| N10/10 | SAM control unit | 19A |
| N10/10 | SAM control unit | 3A |
| N10/10f1 | Fuse 1 | 14A |
| N10/10f33 | Fuse 33 | |
| N10/10k3 | Starter relay | |
| N3/10 | ME-SFI [ME] control module | 7A |
| S2/1 | Ignition/starter switch | 20L |
| W10 | Ground (battery) | 18G |
| X26 | Interior-engine connector | 13H |
| X26 | Interior-engine connector | 4E |
Scheme 51
Scheme 52
Wiring diagram for starter, alternator - PE15.00-P-2000-99MCU
| Code | Designation | Position |
|---|---|---|
| F58 | Xxx | 15 G |
| F91 | SAM prefuse | 16 G |
| G1 | Battery | 17 L |
| G2 | Generator | 6 L |
| M1 | Starter | 13 L |
| N10/10 | SAM control unit | 3 A |
| N10/10 | SAM control unit | 19 A |
| N10/10f1 | Fuse 1 | 14 A |
| N10/10f33 | Fuse 33 | 17 A |
| N10/10k3 | Starter relay | 14 B |
| N3/10 | ME-SFI [ME] control module | 7 A |
| S2/1 | Ignition/starter switch | 20 L |
| W10 | Ground (battery) | 18 G |
| X26 | Interior-engine connector | 3 E |
| X26 | Interior-engine connector | 13 H |
Scheme 53
Scheme 54
Wiring diagram for starter, alternator - PE15.00-P-2000MCU
ENGINE 132 in MODEL 451
| Wiring diagram Starter, alternator | PE15.00-P-2000-99MCU |
|---|---|
| Legend of wiring diagram for starter, alternator | PE15.00-P-2000-60MCU |
| Use of wiring diagrams | OV00.01-P-1901-03MCC |
| Search aid for all wiring diagram groups | OV00.01-P-1901MCU |
| Abbreviations for wiring diagrams | OV00.01-P-1001-27MC |
| Abbreviations of signal and circuit designations for wiring diagrams | OV00.01-P-1001-28MC |
| Location and assignment of line and connectors | GF00.19-P-1000MCU |
| Location and assignment of ground points | GF00.19-P-2000MCU |
| Location and assignment of Z connector sleeves (line connectors in wiring harness) | GF00.19-P-3000MCU |
| Further wiring diagrams | PE07.00-P-1100MCU |
| Further wiring diagrams | PE54.00-P-1100MCU |
