Automatic Transaxle (Diagnostic Codes & Circuit Tests): Diagnosis Scion tC II

INSPECTION PROCEDURE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 406

1. CHECK DTC OUTPUT (SFI SYSTEM DTC P0560) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / DTC. Read the DTCs using the Techstream. RESULT Result Proceed to DTCs are not output A P0560 is output (SFI system) B B --> See step 4 A: Go to next step
2. CHECK TCM (POWER SOURCE, BODY GROUND) Disconnect the TCM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B31-1 (BATT) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B31-8 (E1) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (TCM - BATTERY, BODY GROUND) OK --> See step 3
3. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
4. GO TO SFI SYSTEM (DTC P0560). Refer to «DTC P0560: System Voltage»(ref-451172-S29913378472012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

The following troubleshooting flowchart is based on the premise that the engine can be cranked normally. If the engine does not crank, proceed to the problem symptoms table. Refer to PROBLEM SYMPTOMS TABLE .

Scheme 407

Scheme 408

1. READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. Read the value displayed on the Techstream. Crank the engine. Read the value displayed on the Techstream. ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note Starter Signal Starter signal/ Open or Close Open: Starter operating Close: Starter not operating - OK Starter Signal is only ON when the engine is being started (during cranking). NG --> See step 3 OK --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-451050-S39599463712012020700000)
3. CHECK TCM (STA VOLTAGE) Disconnect the TCM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B31-10 (STA) - B31-8 (E1) Ignition switch ON and shift lever in P or N Below 2 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Disconnect the park/neutral position switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 4 (B) - 9 (L) Shift lever in P Below 1 ohms 4 (B) - 9 (L) Shift lever in N Below 1 ohms 4 (B) - 9 (L) Shift lever not in P 10 kohms or higher 4 (B) - 9 (L) Shift lever not in N 10 kohms or higher 1 (RB) - 9 (L) Shift lever in P, R, N, D or S 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Park/Neutral Position Switch) NG --> See step 6 OK --> See step 5
5. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
6. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-451170-S34996445972012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR . There is a possibility that the DTC P062F is issued from the ECUs of the ECM and TCM. Use Techstream to conduct a health check to confirm which ECU the DTC is issued from and then inspect the related system.

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. According to the display on the Techstream, read the Data List. ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note Neutral Position SW Signal PNP switch status/ ON or OFF ON: Shift lever in P or N OFF: Shift lever not in P or N When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. Shift SW Status (P Range) PNP switch status/ ON or OFF ON: Shift lever in P OFF: Shift lever not in P When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. Shift SW Status (R Range) PNP switch status/ ON or OFF ON: Shift lever in R OFF: Shift lever not in R When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. Shift SW Status (N Range) PNP switch status/ ON or OFF ON: Shift lever in N OFF: Shift lever not in N When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. Shift SW Status (D Range) PNP switch status/ ON or OFF ON: Shift lever in D or S OFF: Shift lever not in D or S When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect.

Scheme 409

Scheme 410

Scheme 411

Scheme 412

1. CHECK PARK/NEUTRAL POSITION SWITCH ASSEMBLY (POWER SOURCE) Disconnect the park/neutral position switch connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B14-1 (RB) - Body ground Ignition switch ON 11 to 14 V B14-1 (RB) - Body ground Ignition switch off Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Park/Neutral Position Switch) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (PARK/NEUTRAL POSITION SWITCH - BATTERY) OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TCM OUTPUT SIGNAL) Disconnect the park/neutral position switch connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B14-4 (B) - Body ground Ignition switch ON 11 to 14 V B14-4 (B) - Body ground Ignition switch off Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Park/Neutral Position Switch) NG --> See step 6 OK: Go to next step
3. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Disconnect the park/neutral position switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 4 (B) - 9 (L) Shift lever in P Below 1 ohms 1 (RB) - 2 (RL) Shift lever in R Below 1 ohms 4 (B) - 9 (L) Shift lever in N Below 1 ohms 1 (RB) - 7 (DL) Shift lever in D, S, "+" or "-" Below 1 ohms 4 (B) - 9 (L) Shift lever not in P 10 kohms or higher 1 (RB) - 2 (RL) Shift lever not in R 10 kohms or higher 4 (B) - 9 (L) Shift lever not in N 10 kohms or higher 1 (RB) - 7 (DL) Shift lever not in D, S, "+" or "-" 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Park/Neutral Position Switch) NG --> See step 8 OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - TCM) Disconnect the TCM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B31-16 (D) - Body ground Ignition switch ON Shift lever in D 11 to 14 V B31-15 (R) - Body ground Ignition switch ON Shift lever in R 11 to 14 V* B31-16 (D) - Body ground Ignition switch ON Shift lever not in D Below 1 V B31-15 (R) - Body ground Ignition switch ON Shift lever not in R Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) HINT: *: The voltage will drop slightly due to the illumination of the back-up light. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
5. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
6. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - TCM) Disconnect the park/neutral position switch connector. Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B14-4 (B) - B31-11 (NSW) Always Below 1 ohms B14-4 (B) or B31-11 (NSW) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 7
7. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
8. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-451170-S34996445972012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR . If DTCs P0711 and P2610 are output simultaneously, confirm that the ATF temperature is as specified in "Normal Condition" using the Techstream first. When the ATF temperature is as specified in "Normal Condition", perform troubleshooting for DTC P2610. Refer to DTC P2610: ECM / PCM Internal Engine Off Timer Performance .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. According to the display on the Techstream, read the Data List. ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note A/T Oil Temperature 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approx. 80°C (176°F) Equal to ambient temperature after cold soak If the value is "-40°C (-40°F)" or "150°C (302°F)", the ATF temperature sensor circuit is open or shorted. HINT: When DTC P0712 is output and the Techstream indicates 150°C (302°F) or higher, there is a short circuit. When DTC P0713 is output and the Techstream indicates -40°C (-40°F), there is an open circuit. Check the temperature displayed on the Techstream in order to check if a malfunction exists. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or higher Short circuit If a circuit related to the ATF temperature sensor becomes open, P0713 is immediately stored (in 0.5 seconds). When P0713 is stored, P0711 cannot be stored. It is not necessary to inspect the circuit when P0711 is stored.

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. According to the display on the Techstream, read the Data List. ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note A/T Oil Temperature 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approx. 80°C (176°F) Equal to ambient temperature after cold soak If the value is "-40°C (-40°F)" or "150°C (302°F)", the ATF temperature sensor circuit is open or shorted. HINT: When DTC P0712 is output and the Techstream indicates 150°C (302°F) or higher, there is a short circuit. When DTC P0713 is output and the Techstream indicates -40°C (-40°F), there is an open circuit. Check the temperature displayed on the Techstream in order to check if a malfunction exists. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or higher Short circuit If a circuit related to the ATF temperature sensor becomes open, P0713 is immediately stored (in 0.5 seconds). When P0713 is stored, P0711 cannot be stored. It is not necessary to inspect the circuit when P0711 is stored.

Scheme 413

1. INSPECT TRANSMISSION WIRE (ATF TEMPERATURE SENSOR) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 18 (THO1) - 17 (E2) Always 79 ohms to 156 kohms 18 (THO1) - Body ground Always 10 kohms or higher 17 (E2) - Body ground Always 10 kohms or higher HINT: If the resistance is out of the specified range at any of the ATF temperatures shown in the table below, the driveability of the vehicle may decrease. Resistance (Reference) ATF Temperature Specified Condition 10°C (50°F) 5 to 8 kohms 25°C (77°F) 2.5 to 4.5 kohms 110°C (230°F) 0.22 to 0.28 kohms TEXT IN ILLUSTRATION *a Component without TCM connected (Transmission Wire) NG --> See step 3 OK --> See step 2
2. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
3. REPLACE ATF TEMPERATURE SENSOR (TRANSMISSION WIRE). Refer to «REMOVAL»(ref-451170-S34683550842012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. According to the display on the Techstream, read the Data List. ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note SPD (NT) Input turbine speed (speed sensor NT)/ Min.: 0 rpm Max.: 12750 rpm Lock-up on (after warming up the engine): Value from speed sensor NT equal to engine speed Lock-up off (idling with shift lever in N): Value from speed sensor NT nearly equal to engine speed The data is displayed in increments of 50 rpm. NT Sensor Voltage Input turbine speed sensor (speed sensor NT) output voltage/ Min.: 0 V Max.: 5 V Engine idling: 0.1 to 1.9 V - HINT: SPD (NT) is always 0 while driving: Open or short in the sensor or circuit. SPD (NT) is always more than 0 and less than 300 rpm while driving the vehicle at 50 km/h (31 mph) or more: Sensor trouble, improper installation, or intermittent connection trouble of the circuit.

Scheme 414

Scheme 415

1. INSPECT SPEED SENSOR NT INSTALLATION Make sure that the connector is properly connected, and then check the speed sensor installation. OK The installation bolts are tightened properly and there is no clearance between the sensor and transaxle case. NG --> See step 6 OK: Go to next step
2. INSPECT TRANSMISSION WIRE Disconnect the speed sensor connector. Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition NTB speed sensor side - 1 (NTB) TCM side Always Below 1 ohms NTO speed sensor side - 2 (NTO) TCM side Always Below 1 ohms NTB speed sensor side - Body ground Always 10 kohms or higher NTO speed sensor side - Body ground Always 10 kohms or higher NTB speed sensor side - All other terminals except 1 (NTB) TCM side Always 10 kohms or higher NTO speed sensor side - All other terminals except 2 (NTO) TCM side Always 10 kohms or higher TEXT IN ILLUSTRATION *1 Transmission Wire *a Speed Sensor Side *b TCM Side NG --> See step 7 OK: Go to next step
3. REPLACE SPEED SENSOR NT (SPEED SENSOR) Replace the speed sensor. Refer to «REMOVAL»(ref-451170-S39152689282012020700000) . NEXT: Go to next step
4. CHECK IF DTC OUTPUT RECURS (DTC P0715 OR P0717) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes / Clear. HINT: Write down the currently output DTCs before clearing them. Perform the monitor drive pattern. Refer to «MONITOR DRIVE PATTERN»(ref-451062-S11386049922012020700000) . Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0715 or P0717 is output A DTCs are not output B B --> END A --> See step 5
5. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
6. SECURELY INSTALL OR REPLACE SPEED SENSOR NT. Refer to «REMOVAL»(ref-451170-S39152689282012020700000)
7. REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-451170-S34683550842012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. According to the display on the Techstream, read the Data List. ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note Stop Light Switch Stop light switch status/ ON or OFF ON: Brake pedal depressed OFF: Brake pedal released

Scheme 416

Scheme 417

1. INSPECT STOP LIGHT SWITCH ASSEMBLY Remove the stop light switch assembly. Refer to «REMOVAL»(ref-451186-S12977845582012020700000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 1 - 2 Pin not pushed Below 1 ohms 3 - 4 Pin pushed Below 1 ohms 1 - 2 Pin pushed 10 kohms or higher 3 - 4 Pin not pushed 10 kohms or higher TEXT IN ILLUSTRATION *1 Pin *a Component without harness connected (Stop Light Switch Assembly) *b Not pushed *c Pushed NG --> See step 4 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (BATTERY - TCM) Disconnect the TCM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B31-12 (STP) - Body ground Brake pedal depressed 7.5 to 14 V B31-12 (STP) - Body ground Brake pedal released Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 3
3. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
4. REPLACE STOP LIGHT SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-451186-S12977845582012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 418

1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Active Test. According to the display on the Techstream, perform the Active Test. ECT Tester Display Test Part Control Range Diagnostic Note Activate the Lock Up Control shift solenoid valve SLU and SL to set the automatic transaxle to lock-up ON or OFF Can be used to check shift solenoid valve SLU and SL operation. [Vehicle Condition] Vehicle speed: 60 km/h (37 mph) or more Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: When depressing the accelerator pedal while driving, if the engine speed does not change abruptly, lock-up is on. When decelerating, slowly release the accelerator pedal, but do not fully release it (fully releasing the pedal will close the throttle valve and lock-up may be turned off).

Scheme 419

Scheme 420

Scheme 421

1. CHECK DTC OUTPUT (IN ADDITION TO DTC P0741) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0741 is output A P0741 and other DTCs are output B HINT: If any other codes besides P0741 are output, perform troubleshooting for those DTCs first. B --> See step 9 A: Go to next step
2. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 6 (SL) - Body ground 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *a Component without TCM connected (Transmission Wire) NG --> See step 7 OK: Go to next step
3. INSPECT SHIFT SOLENOID VALVE SL (OPERATION) Remove shift solenoid valve SL. Apply 12 V battery voltage to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) --> Shift solenoid valve SL connector Battery negative (-) --> Shift solenoid valve SL body Valve moves and makes an operating noise TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SL) NG --> See step 10 OK: Go to next step
4. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «DISASSEMBLY»(ref-451170-S33336223122012020700000) . OK There are no foreign objects on any valve. NG --> See step 11 OK: Go to next step
5. INSPECT TORQUE CONVERTER ASSEMBLY Check the torque converter assembly. Refer to «INSPECTION»(ref-451170-S40563817042012020700000) . OK The torque converter operates normally. NG --> See step 12 OK --> See step 6
6. REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY. Refer to «REMOVAL»(ref-451170-S42626861182012020700000)
7. INSPECT SHIFT SOLENOID VALVE SL (RESISTANCE) Remove shift solenoid valve SL. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve SL connector terminal - Shift solenoid valve SL body 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SL) NG --> See step 13 OK --> See step 8
8. REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-451170-S34683550842012020700000)
9. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451062-S04491015252012020700000)
10. REPLACE SHIFT SOLENOID VALVE SL. Refer to «DISASSEMBLY - Step 3»(ref-451170-S35926904202012020700000)
11. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-451170-S13458606402012020700000)
12. REPLACE TORQUE CONVERTER ASSEMBLY. Refer to «REMOVAL»(ref-451170-S42626861182012020700000)
13. REPLACE SHIFT SOLENOID VALVE SL. Refer to «DISASSEMBLY - Step 3»(ref-451170-S35926904202012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 422

1. CHECK DTC OUTPUT (IN ADDITION TO DTC P0746) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to P0746 and other DTCs are output A Only P0746 is output B HINT: If shift solenoid valve SL1 is stuck off, DTCs for several shift solenoid valves including the malfunctioning shift solenoid valve will be stored. B --> See step 6 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (DRIVING TEST) NOTE: This test should always be performed with at least 2 people. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Active Test. According to the display on the Techstream, perform the Active Test. HINT: Comparing the gear commanded by the Active Test with the actual gear enables confirmation of the problem. Refer to «FAIL-SAFE CHART»(ref-451062-S06339415892012020700000) . ECT Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate the shift solenoid valves and set each shift position Press "-->" button: Shift up Press "<--" button: Shift down Can be used to check the operation of the shift solenoid valves. A 10-second interval is required between gear changes. Do not down-shift at high speeds. Doing so will damage the automatic transaxle. [Vehicle Condition] 50 km/h (30 mph) or less NOTE: This test can be conducted when the vehicle is stopped. When shifting gears using the Active Test function, do not operate the accelerator pedal for 2 seconds before and after shifting gears. HINT: The gear commanded by the TCM is shown in the Data List / Shift Status display on the Techstream. Check the vehicle speed and gear when the engine speed is 1000 rpm. HINT: Because the torque converter has not engaged, it may be difficult to obtain the speeds specified in 4th, 5th and 6th gear, however a difference of speed should still be evident following each gear change. STANDARD 1st 2nd 3rd 4th 5th 6th 8 to 12 km/h (5 to 7.5 mph) 15 to 19 km/h (9.3 to 11.8 mph) 21 to 25 km/h (13.0 to 15.5 mph) 31 to 35 km/h (19.3 to 21.7 mph) 44 to 48 km/h (27.3 to 29.8 mph) 52 to 56 km/h (32.3 to 34.8 mph) Compare the TCM commanded gear and the actual gear. Result System Condition TCM Gear Shift Command Proceed to 1st 2nd 3rd 4th 5th 6th Malfunction Shift solenoid valve SL1 Stuck ON 1st 2nd 3rd 4th 4th 4th A Stuck OFF N*1 N*1 N*1 N*1 5th 6th Shift solenoid valve SL2 Stuck ON 4th 4th 4th 4th 5th 6th B Stuck OFF 1st 2nd 3rd 1st N*1 N*1 Shift solenoid valve SL3 Stuck ON 2nd 2nd 3rd 4th 5th 6th C Stuck OFF 1st 1st 3rd 4th 5th N*1 Shift solenoid valve SL4 Stuck ON*3 3rd 3rd 3rd 4th 5th 5th D Stuck OFF 1st 2nd 1st 4th N*1 6th Shift solenoid valve SLT Stuck ON N*2 N*2 N*2 N*2 N*2 N*2 E Stuck OFF*3 1st 2nd 3rd 4th 5th 6th HINT: *1: Neutral *2: If shift solenoid valve SLT is stuck on, the line pressure will be low. Therefore, the amount of torque that can be transmitted by each gear is lower than the normal limit. When the engine power exceeds this lowered limit, the engine speed will increase freely. *3: When shift solenoid valve SLT is stuck off, gear shifting is normal. B --> See step 9 C --> See step 10 D --> See step 11 E --> See step 12 A: Go to next step
3. INSPECT SHIFT SOLENOID VALVE SL1 Remove shift solenoid valve SL1. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Apply 12 V battery voltage to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) with a 21 W bulb --> Terminal 1 Battery negative (-) --> Terminal 2 Valve moves and makes an operating noise TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SL1) NG --> See step 13 OK: Go to next step
4. INSPECT TRANSMISSION VALVE BODY ASSEMBLY See step 4 NG --> See step 14 OK --> See step 5
5. REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY. Refer to «REMOVAL»(ref-451170-S42626861182012020700000)
6. INSPECT SHIFT SOLENOID VALVE SL1 Remove shift solenoid valve SL1. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Apply 12 V battery voltage to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) with a 21 W bulb --> Terminal 1 Battery negative (-) --> Terminal 2 Valve moves and makes an operating noise TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SL1) NG --> See step 15 OK: Go to next step
7. INSPECT TRANSMISSION VALVE BODY ASSEMBLY See step 4 NG --> See step 16 OK --> See step 8
8. REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY. Refer to «REMOVAL»(ref-451170-S42626861182012020700000)
9. GO TO DTC P0776. Refer to «DTC P0776: Pressure Control Solenoid "B" Performance (Shift Solenoid Valve SL2)»(ref-451187-S04507879402012020700000)
10. GO TO DTC P0796. Refer to «DTC P0796: Pressure Control Solenoid "C" Performance (Shift Solenoid Valve SL3)»(ref-451187-S36891089002012020700000)
11. GO TO DTC P2808. Refer to «DTC P2808: Pressure Control Solenoid "G" Performance (Shift Solenoid Valve SL4)»(ref-451187-S38464293442012020700000)
12. GO TO DTC P2714. Refer to «DTC P2714: Pressure Control Solenoid "D" Performance (Shift Solenoid Valve SLT)»(ref-451187-S03466197552012020700000)
13. REPLACE SHIFT SOLENOID VALVE SL1. Refer to «DISASSEMBLY - Step 5»(ref-451170-S35926904202012020700000)
14. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-451170-S13458606402012020700000)
15. REPLACE SHIFT SOLENOID VALVE SL1. Refer to «DISASSEMBLY - Step 5»(ref-451170-S35926904202012020700000)
16. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-451170-S13458606402012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

The following table shows the normal operation of shift solenoid valve SL1 when the shift lever is in D

Scheme 423

1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL1) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 14 (SL1+) - 13 (SL1-) 20°C (68°F) 5.0 to 5.6 ohms 14 (SL1+) - Body ground Always 10 kohms or higher 13 (SL1-) - Body ground Always 10 kohms or higher 14 (SL1+) - All other terminals except 13 (SL1-) Always 10 kohms or higher 13 (SL1-) - All other terminals except 14 (SL1+) Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without TCM connected (Transmission Wire) NG --> See step 3 OK --> See step 2
2. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
3. INSPECT SHIFT SOLENOID VALVE SL1 See step 3 NG --> See step 5 OK --> See step 4
4. REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-451170-S34683550842012020700000)
5. REPLACE SHIFT SOLENOID VALVE SL1. Refer to «DISASSEMBLY - Step 5»(ref-451170-S35926904202012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

The following table shows the normal operation of shift solenoid valve SL2 when the shift lever is in D

Scheme 424

1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL2) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 9 (SL2+) - 8 (SL2-) 20°C (68°F) 5.0 to 5.6 ohms 9 (SL2+) - Body ground Always 10 kohms or higher 8 (SL2-) - Body ground Always 10 kohms or higher 9 (SL2+) - All other terminals except 8 (SL2-) Always 10 kohms or higher 8 (SL2-) - All other terminals except 9 (SL2+) Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without TCM connected (Transmission Wire) NG --> See step 3 OK --> See step 2
2. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
3. INSPECT SHIFT SOLENOID VALVE SL2 See step 4 NG --> See step 5 OK --> See step 4
4. REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-451170-S34683550842012020700000)
5. REPLACE SHIFT SOLENOID VALVE SL2. Refer to «DISASSEMBLY - Step 4»(ref-451170-S35926904202012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. According to the display on the Techstream, read the Data List. ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note SPD (NC) Counter gear speed (speed sensor NC)/ Min.: 0 rpm Max.: 12750 rpm Vehicle stopped: 0 km/h (0 mph) The data is displayed in increments of 50 rpm. NC Sensor Voltage Counter gear speed sensor (speed sensor NC) output voltage/ Min.: 0 V Max.: 5 V Engine idling: 0.1 to 1.9 V

Scheme 425

1. INSPECT SPEED SENSOR NC INSTALLATION See step 1 NG --> See step 6 OK: Go to next step
2. INSPECT TRANSMISSION WIRE Disconnect the speed sensor connector. Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition NCB speed sensor side - 4 (NCB) TCM side Always Below 1 ohms NCO speed sensor side - 3 (NCO) TCM side Always Below 1 ohms NCB speed sensor side - Body ground Always 10 kohms or higher NCO speed sensor side - Body ground Always 10 kohms or higher NCB speed sensor side - All other terminals except 4 (NCB) TCM side Always 10 kohms or higher NCO speed sensor side - All other terminals except 3 (NCO) TCM side Always 10 kohms or higher TEXT IN ILLUSTRATION *1 Transmission Wire *a Speed Sensor Side *b TCM Side NG --> See step 7 OK: Go to next step
3. REPLACE SPEED SENSOR NC (SPEED SENSOR) See step 3 NEXT: Go to next step
4. CHECK IF DTC OUTPUT RECURS (DTC P0791 OR P0793) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes / Clear. HINT: Write down the currently output DTCs before clearing them. Perform the monitor drive pattern. Refer to «MONITOR DRIVE PATTERN»(ref-451062-S11386049922012020700000) . Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0791 or P0793 is output A DTCs are not output B B --> END A --> See step 5
5. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
6. SECURELY INSTALL OR REPLACE SPEED SENSOR NC. Refer to «REMOVAL»(ref-451170-S39152689282012020700000)
7. REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-451170-S34683550842012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

The following table shows the normal operation of shift solenoid valve SL3 when the shift lever is in D

Scheme 426

1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL3) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 16 (SL3+) - 15 (SL3-) 20°C (68°F) 5.0 to 5.6 ohms 16 (SL3+) - Body ground Always 10 kohms or higher 15 (SL3-) - Body ground Always 10 kohms or higher 16 (SL3+) - All other terminals except 15 (SL3-) Always 10 kohms or higher 15 (SL3-) - All other terminals except 16 (SL3+) Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without TCM connected (Transmission Wire) NG --> See step 3 OK --> See step 2
2. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
3. INSPECT SHIFT SOLENOID VALVE SL3 See step 4 NG --> See step 5 OK --> See step 4
4. REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-451170-S34683550842012020700000)
5. REPLACE SHIFT SOLENOID VALVE SL3. Refer to «DISASSEMBLY - Step 8»(ref-451170-S35926904202012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 427

1. CHECK DTC OUTPUT (IN ADDITION TO DTC P2714) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to P2714 and other DTCs are output A Only P2714 is output B HINT: If shift solenoid valve SLT is stuck on, DTCs for several shift solenoid valves including the malfunctioning shift solenoid valve will be stored. B --> See step 5 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test while the ATF temperature is 50 to 80°C (122 to 176°F). Be careful to prevent the hose of SST from interfering with the exhaust pipe. This check must be conducted after checking and confirming that the engine is normal. Perform the test with the A/C off. HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Remove the test plug from the transaxle case and connect SST. SST: 09992-00095 09992-00231 09992-00271 Connect the Techstream to the DLC3. Start the engine and warm it up. Measure the line pressure when the engine is idling. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Active Test. According to the display on the Techstream, perform the Active Test. Measure the line pressure with SST. ECT Tester Display Test Part Control Range Diagnostic Note Activate the Solenoid (SLT)* Operate shift solenoid valve SLT and raise line pressure ON or OFF HINT: ON: No action (normal operation) OFF: Line pressure up (When Active Test "Activate the Solenoid (SLT)" is performed, TCM commands shift solenoid valve SLT to turn off). [Vehicle Condition] Vehicle stopped Engine idling HINT: *: The "Activate the Solenoid (SLT)" Active Test is performed to confirm that the line pressure changes. The line pressure changes are confirmed using the same SST that is used for the Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-451062-S01437332642012020700000) . Note that the pressure readings for the Active Test and Hydraulic Test are different. OK The line pressure changes as specified when performing the Active Test. NG --> See step 8 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (DRIVING TEST) See step 2 B --> See step 14 C --> See step 15 D --> See step 16 E --> See step 11 A --> See step 4
4. GO TO DTC P0746. Refer to «DTC P0746: Pressure Control Solenoid "A" Performance (Shift Solenoid Valve SL1)»(ref-451187-S31295266812012020700000)
5. INSPECT SHIFT SOLENOID VALVE SLT Remove shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Apply 12 V battery voltage to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) with a 21 W bulb --> Terminal 1 Battery negative (-) --> Terminal 2 Valve moves and makes an operating noise TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SLT) NG --> See step 17 OK: Go to next step
6. INSPECT TRANSMISSION VALVE BODY ASSEMBLY See step 4 NG --> See step 18 OK --> See step 7
7. REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY. Refer to «REMOVAL»(ref-451170-S42626861182012020700000)
8. INSPECT SHIFT SOLENOID VALVE SLT Remove shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Apply 12 V battery voltage to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) with a 21 W bulb --> Terminal 1 Battery negative (-) --> Terminal 2 Valve moves and makes an operating noise TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SLT) NG --> See step 19 OK: Go to next step
9. INSPECT TRANSMISSION VALVE BODY ASSEMBLY See step 4 NG --> See step 20 OK --> See step 10
10. REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY. Refer to «REMOVAL»(ref-451170-S42626861182012020700000)
11. INSPECT SHIFT SOLENOID VALVE SLT Remove shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Apply 12 V battery voltage to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) with a 21 W bulb --> Terminal 1 Battery negative (-) --> Terminal 2 Valve moves and makes an operating noise TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SLT) NG --> See step 21 OK: Go to next step
12. INSPECT TRANSMISSION VALVE BODY ASSEMBLY See step 4 NG --> See step 22 OK --> See step 13
13. REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY. Refer to «REMOVAL»(ref-451170-S42626861182012020700000)
14. GO TO DTC P0776. Refer to «DTC P0776: Pressure Control Solenoid "B" Performance (Shift Solenoid Valve SL2)»(ref-451187-S04507879402012020700000)
15. GO TO DTC P0796. Refer to «DTC P0796: Pressure Control Solenoid "C" Performance (Shift Solenoid Valve SL3)»(ref-451187-S36891089002012020700000)
16. GO TO DTC P2808. Refer to «DTC P2808: Pressure Control Solenoid "G" Performance (Shift Solenoid Valve SL4)»(ref-451187-S38464293442012020700000)
17. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «DISASSEMBLY - Step 6»(ref-451170-S35926904202012020700000)
18. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-451170-S13458606402012020700000)
19. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «DISASSEMBLY - Step 6»(ref-451170-S35926904202012020700000)
20. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-451170-S13458606402012020700000)
21. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «DISASSEMBLY - Step 6»(ref-451170-S35926904202012020700000)
22. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-451170-S13458606402012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 428

1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SLT) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 12 (SLT+) - 7 (SLT-) 20°C (68°F) 5.0 to 5.6 ohms 12 (SLT+) - Body ground Always 10 kohms or higher 7 (SLT-) - Body ground Always 10 kohms or higher 12 (SLT+) - All other terminals except 7 (SLT-) Always 10 kohms or higher 7 (SLT-) - All other terminals except 12 (SLT+) Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without TCM connected (Transmission Wire) NG --> See step 3 OK --> See step 2
2. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
3. INSPECT SHIFT SOLENOID VALVE SLT See step 5 NG --> See step 5 OK --> See step 4
4. REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-451170-S34683550842012020700000)
5. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «DISASSEMBLY - Step 6»(ref-451170-S35926904202012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Active Test. According to the display on the Techstream, perform the Active Test. ECT Tester Display Test Part Control Range Diagnostic Note Activate the Lock Up Control shift solenoid valve SLU and SL to set the automatic transaxle to lock-up ON or OFF Can be used to check shift solenoid valve SLU and SL operation. [Vehicle Condition] Vehicle speed: 60 km/h (37 mph) or more Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: When depressing the accelerator pedal while driving, if the engine speed does not change abruptly, lock-up is on. When decelerating, slowly release the accelerator pedal, but do not fully release it (fully releasing the pedal will close the throttle valve and lock-up may be turned off).

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 429

1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SLU) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 11 (SLU+) - 5 (SLU-) 20°C (68°F) 5.0 to 5.6 ohms 11 (SLU+) - Body ground Always 10 kohms or higher 5 (SLU-) - Body ground Always 10 kohms or higher 11 (SLU+) - All other terminals except 5 (SLU-) Always 10 kohms or higher 5 (SLU-) - All other terminals except 11 (SLU+) Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without TCM connected (Transmission Wire) NG --> See step 3 OK --> See step 2
2. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
3. INSPECT SHIFT SOLENOID VALVE SLU See step 2 NG --> See step 5 OK --> See step 4
4. REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-451170-S34683550842012020700000)
5. REPLACE SHIFT SOLENOID VALVE SLU. Refer to «DISASSEMBLY - Step 7»(ref-451170-S35926904202012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 430

1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL) See step 2 NG --> See step 3 OK --> See step 2
2. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
3. INSPECT SHIFT SOLENOID VALVE SL Remove shift solenoid valve SL. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve SL connector terminal - Shift solenoid valve SL body 20°C (68°F) 11 to 15 ohms Apply 12 V battery voltage to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) --> Shift solenoid valve SL connector Battery negative (-) --> Shift solenoid valve SL body Valve moves and makes an operating noise TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SL) NG --> See step 5 OK --> See step 4
4. REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-451170-S34683550842012020700000)
5. REPLACE SHIFT SOLENOID VALVE SL. Refer to «DISASSEMBLY - Step 3»(ref-451170-S35926904202012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

The following table shows the normal operation of shift solenoid valve SL4 when the shift lever is in D

Scheme 431

1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL4) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 22 (SL4+) - 21 (SL4-) 20°C (68°F) 5.0 to 5.6 ohms 22 (SL4+) - Body ground Always 10 kohms or higher 21 (SL4-) - Body ground Always 10 kohms or higher 22 (SL4+) - All other terminals except 21 (SL4-) Always 10 kohms or higher 21 (SL4-) - All other terminals except 22 (SL4+) Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without TCM connected (Transmission Wire) NG --> See step 3 OK --> See step 2
2. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)
3. INSPECT SHIFT SOLENOID VALVE SL4 See step 4 NG --> See step 5 OK --> See step 4
4. REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-451170-S34683550842012020700000)
5. REPLACE SHIFT SOLENOID VALVE SL4. Refer to «DISASSEMBLY - Step 9»(ref-451170-S35926904202012020700000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

1. Refer to the inspection procedure for the CAN communication system.
2. If the CAN communication malfunctions, the TCM cannot receive current data from the ECM. In this case, the freeze frame data output from the TCM has not been updated, so the data will not be useful for the inspection. However, reading the Data List as the first step in troubleshooting is an effective way to find malfunctions.
3. The malfunctioning area can be confirmed using the Bus Check function of the Techstream. Refer to «DIAGNOSIS SYSTEM»(ref-451206-S32661733752012020700000) .

Scheme 432

1. CHECK TCM (POWER SOURCE, BODY GROUND) Disconnect the TCM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B31-18 (+B) - Body ground Ignition switch ON 11 to 14 V Turn the ignition switch off. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B31-8 (E1) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (TCM - BATTERY, BODY GROUND) OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (ECM - TCM) Disconnect the ECM connector. Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B30-24 (CAN+) - B31-6 (CAN+) Always Below 1 ohms B30-1 (CAN-) - B31-7 (CAN-) Always Below 1 ohms B30-24 (CAN+) or B31-6 (CAN+) - Body ground or other terminals Always 10 kohms or higher B30-1 (CAN-) or B31-7 (CAN-) - Body ground or other terminals Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK IF DTC OUTPUT RECURS (DTC U0100) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes / Clear. Replace the TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000) . HINT: Replace the TCM with the TCM of a normally functioning vehicle of the same model. Start the engine. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to U0100 is output A DTCs are not output B B --> See step 5 A --> See step 4
4. REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)
5. REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 433

1. CHECK TCM (TCM - BODY GROUND) Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B31-8 (E1) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (INTEGRATION RELAY - TCM) Remove the integration relay from the engine room relay block. Refer to «ON-VEHICLE INSPECTION»(ref-451166-S20720226562012020700000) . Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1B-4 - B31-18 (+B) Always Below 1 ohms 1B-4 or B31-18 (+B) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 3
3. GO TO SFI SYSTEM (ECM POWER SOURCE CIRCUIT). Refer to «ECM Power Source Circuit»(ref-451172-S01002187532012020700000)
